Bently Nevada 31000-16-10-15-063-03-02 – Proximity Probe Housing Assembly | 3300 XL Series Platform
Engineering Background: The Bently Nevada 3300 XL Series represents the industry benchmark for continuous vibration monitoring in rotating machinery. Designed for critical turbomachinery applications—including steam turbines, gas compressors, and centrifugal pumps—the 31000 series proximity probe system delivers non-contact, eddy-current-based displacement measurement with exceptional signal fidelity and long-term reliability in harsh industrial environments.
Product Positioning: The 31000-16-10-15-063-03-02 is a precision-engineered proximity probe housing assembly, purpose-built for integration into Bently Nevada 3300 XL monitoring systems. It provides the mechanical interface and environmental protection required for accurate shaft displacement and vibration measurement in API 670-compliant installations. This part is a direct OEM-equivalent replacement, sourced and verified for use in power generation, oil & gas, and petrochemical facilities.
Complete Technical Specifications
- Part Number: 31000-16-10-15-063-03-02
- Manufacturer: Bently Nevada (Baker Hughes)
- Series / Platform: 3300 XL Proximity Transducer System
- Component Type: Proximity Probe Housing Assembly
- Sensing Technology: Eddy-current (non-contact)
- Probe Tip Diameter: 16 mm (per part number encoding)
- Cable Length: 1.0 m (per part number encoding)
- Extension Cable: Compatible with 3300 XL extension cable series
- Operating Temperature: -35°C to +177°C (probe body)
- Target Material Compatibility: AISI 4140 steel (standard); other ferrous/non-ferrous per calibration
- Sensitivity: 7.87 V/mm (200 mV/mil) nominal
- Linear Range: 0.25 mm to 2.54 mm (10 to 100 mil)
- Supply Voltage: -24 VDC (via Proximitor® sensor)
- Output: -1 VDC to -21 VDC (linear range)
- Ingress Protection: IP67 (housing assembly)
- Approvals: CE, ATEX, IECEx (consult datasheet for zone classification)
- Weight: Approx. 1,200 g (complete assembly)
- Compliance: API 670 4th Edition
Proven Application Environments
- Steam turbine shaft radial and axial vibration monitoring
- Gas turbine and compressor train critical machinery protection
- Centrifugal pump and motor bearing displacement measurement
- Gearbox and expander vibration surveillance
- Power generation (nuclear, thermal, combined-cycle) plant machinery
- Offshore and onshore oil & gas processing facilities
- Petrochemical and refinery rotating equipment monitoring
- LNG liquefaction train critical service applications
Engineering Advantages
- Non-contact measurement: Zero mechanical wear, no lubrication required, infinite service life under normal conditions
- High-frequency response: Capable of capturing sub-synchronous, synchronous, and super-synchronous vibration events
- OEM-grade dimensional accuracy: Ensures drop-in replacement without re-calibration of the Proximitor® sensor
- Robust housing construction: Stainless steel body with hermetic sealing for corrosive and high-humidity environments
- API 670 compliance: Meets the mandatory protection system standard for critical rotating machinery in process industries
- Wide temperature range: Suitable for both cryogenic and high-temperature process environments
System Architecture & Signal Flow
The 31000-16-10-15-063-03-02 housing assembly integrates within the standard Bently Nevada 3300 XL signal chain:
- Probe (31000 series) → eddy-current field generation at shaft surface
- Extension Cable (3300 XL) → signal transmission from probe to Proximitor® sensor
- Proximitor® Sensor (3300 XL) → signal conditioning, -24 VDC supply, voltage output
- Monitor (3500/22M or equivalent) → alarm, trip, and data acquisition
- DCS / Safety System → 4–20 mA or relay output integration
The housing assembly provides the critical mechanical mounting and environmental sealing interface between the probe tip and the machinery casing, ensuring consistent gap setting and long-term measurement stability.
Sourcing & Quality Verification
- Source: Procured from authorized distributors and verified surplus channels with full traceability
- Inspection: Each unit undergoes visual inspection, dimensional verification, and functional continuity check prior to shipment
- Documentation: Certificate of conformance (CoC) available upon request; original manufacturer documentation provided where available
- Packaging: Anti-static, moisture-barrier packaging with individual part labeling and lot traceability
- Warranty: 12-month operational warranty against manufacturing defects
Procurement Process
- Submit RFQ – Contact support@konmask.com with your project requirements and required delivery date
- Receive Quote – Pricing, lead time, and availability confirmed within 24 business hours
- Order Confirmation – Purchase order accepted; proforma invoice issued
- Quality Check & Dispatch – Unit inspected, documented, and shipped via DHL / FedEx with tracking
- After-Sales Support – Technical assistance available post-delivery for installation and commissioning queries
Technical FAQ
Q: Is this a genuine Bently Nevada OEM part?
A: This is an OEM-equivalent or verified surplus part. Konmask.com sources from traceable supply chains. Contact us for CoC documentation.
Q: Can this probe be used with non-Bently Nevada Proximitor® sensors?
A: The 31000 series is optimized for Bently Nevada 3300 XL Proximitor® sensors. Cross-brand compatibility requires independent calibration verification.
Q: What is the recommended installation gap?
A: Nominal installation gap is 1.0 mm (40 mil), corresponding to the mid-point of the linear range (-12 VDC output). Refer to Bently Nevada installation manual 141536-01 for detailed procedures.
Q: Is expedited shipping available?
A: Yes. Express air freight (DHL Express / FedEx Priority) is available for urgent requirements. Contact us for lead time confirmation.
Q: Do you provide volume pricing for MRO or project procurement?
A: Yes. Volume discounts are available for orders of 5+ units. Submit your BOM or RFQ list to support@konmask.com.
