Bently Nevada 330909-00-20-10-01-05 3300 NSV Proximity Probe 8mm | Replacement, Equivalent & Selection Guide
The Bently Nevada 330909-00-20-10-01-05 is an 8 mm eddy-current proximity probe from the 3300 NSV (Non-Standard Voltage) series, engineered for continuous shaft vibration and position monitoring in rotating machinery. This page provides full technical specifications, verified compatible replacements, a structured selection guide, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Part Number: 330909-00-20-10-01-05
- Series: Bently Nevada 3300 NSV (Non-Standard Voltage)
- Probe Type: Eddy-Current Proximity Probe
- Tip Diameter: 8 mm
- Cable Length: 2.0 m (integral cable)
- Thread: M10 × 1.0
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 0.25 – 2.54 mm (10 – 100 mil)
- Supply Voltage: −24 VDC (nominal)
- Operating Temperature: −35 °C to +121 °C
- Connector: Integral coaxial, mates with 3300 XL extension cable
- Housing Material: Stainless steel
- Weight: approx. 220 g
- HS Code: 9031.80
- Compliance: CE, RoHS compatible
Compatible Replacement & Equivalent Models
The table below lists verified drop-in and functionally equivalent alternatives for the 330909-00-20-10-01-05. Always confirm gap voltage, sensitivity, and cable length before substitution.
| Part Number | Brand | Series | Tip Dia. | Cable | Notes |
|---|---|---|---|---|---|
| 330909-00-20-10-02-05 | Bently Nevada | 3300 NSV | 8 mm | 2.0 m | Armored cable variant |
| 330905-00-20-10-01-05 | Bently Nevada | 3300 XL 8mm | 8 mm | 2.0 m | Standard voltage; verify driver compatibility |
| 330780-50-00 | Bently Nevada | 3300 5mm | 5 mm | — | Smaller tip; different linear range |
| PR6423/010-030 | Epro / Baker Hughes | PR6423 | 8 mm | 1.0 m | Functional equivalent; widely used retrofit |
| CWY-DO-810-05-00-G | CNPEC / Zhonghang | CWY-DO | 8 mm | 0.5 m | Cost-effective OEM-grade replacement |
| CS-1G-A05-02-00 | Metrix | CS-1 | 8 mm | 2.0 m | API 670 compliant alternative |
⚠ Disclaimer: Replacement compatibility must be validated against your specific driver/monitor system. Contact our engineers for confirmation.
Why Choose the Original Model
- Factory-calibrated sensitivity matched to Bently Nevada 3300 drivers and monitors
- NSV design eliminates interference in high-noise electrical environments
- API 670 compliant — meets machinery protection standards for turbines, compressors, and pumps
- Proven reliability in petrochemical, power generation, and LNG plant environments
- Seamless integration with existing 3300 XL extension cables and proximitor/oscillator drivers
Typical Applications
- Radial shaft vibration monitoring on steam and gas turbines
- Axial position measurement on centrifugal compressors
- Differential expansion monitoring in power plant turbines
- Eccentricity measurement on large rotating shafts
- Speed and phase reference (Keyphasor) in conjunction with 3300 monitors
System Compatibility
- Monitors: Bently Nevada 3300/16, 3300/20, 3500/42, 3500/45
- Drivers (Proximitors): 330180, 330185 NSV Proximitor
- Extension Cables: 330130 series (matched to 2.0 m probe cable for standard 5 m or 9 m total)
- DCS Integration: Compatible with Emerson DeltaV, Honeywell Experion, ABB 800xA via 4–20 mA or digital output from monitor
Selection Guide
Use the following criteria to confirm the correct probe for your application:
- Tip diameter: 8 mm suits shaft diameters 25–100 mm; use 5 mm probes for smaller shafts
- Cable length: 330909-00-20-10-01-05 = 2.0 m integral cable; match to your extension cable for total system length (5 m or 9 m)
- Voltage standard: NSV (Non-Standard Voltage) — confirm your proximitor is NSV-rated (330185); do not mix with standard 330180 without recalibration
- Environment: Standard housing suits most industrial environments; specify armored cable (-02-) for high-vibration conduit routing
- Certification: Confirm ATEX/IECEx requirements if installing in hazardous areas — contact us for certified variants
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified OEM-surplus channels
- Each probe inspected for physical integrity, connector condition, and cable continuity before shipment
- Traceability documentation (CoC, test reports) available on request
- Konmask.com specializes in industrial automation and machinery protection components — we stock both new and refurbished units
- Lead time: In-stock items ship within 2 business days; sourced items 7–15 business days
How to Order
- Confirm part number: 330909-00-20-10-01-05
- Specify quantity and required delivery date
- Request a quote via support@konmask.com or WhatsApp +0086 19859288691
- Receive proforma invoice with lead time confirmation
- Payment via T/T, PayPal, or credit card — shipment via DHL / FedEx with tracking
Replacement & Compatibility FAQ
Q: Can I use a 3300 XL 330905 probe as a direct replacement?
A: The 330905 is a standard-voltage probe. It is physically similar but requires a standard 330180 proximitor, not the NSV 330185. Mixing these without recalibration will produce incorrect gap voltage readings.
Q: Is the PR6423/010-030 (Epro) a true drop-in replacement?
A: Functionally yes for most 3300 monitor inputs, but sensitivity calibration should be verified. Contact us for a compatibility checklist.
Q: What is the difference between -01- and -02- in the part number?
A: The -01- denotes a standard PVC-jacketed cable; -02- denotes an armored (stainless braid) cable for mechanical protection in conduit installations.
Q: Do you supply ATEX-certified versions?
A: Yes. Please specify your hazardous area classification (Zone 1/2, Group IIC, etc.) when requesting a quote.
Q: Can Konmask.com provide calibration certificates?
A: Yes, factory calibration certificates are available for new units. Third-party calibration reports can be arranged on request.
