Bently Nevada 990-05-XX-01-00 165335-01 – Dual-Channel Vibration Transmitter | 3500 Series Platform
Engineering Background: The Bently Nevada 3500 Series is the industry benchmark for continuous online machinery protection in rotating equipment applications. Deployed across power generation, oil & gas, petrochemical, and heavy industrial facilities worldwide, the platform delivers real-time vibration, position, and dynamic measurement data to safeguard critical rotating assets.
Product Positioning: The 990-05-XX-01-00 (P/N 165335-01) is a dedicated vibration transmitter module within the 3500 rack-based monitoring system. It conditions raw transducer signals—typically from proximity probes or accelerometers—into standardized 4–20 mA or voltage outputs compatible with DCS, SCADA, and safety instrumented systems (SIS). This module is essential for engineers requiring certified, rack-integrated vibration monitoring without compromise on signal fidelity or system uptime.
Complete Technical Specifications
- Part Number: 990-05-XX-01-00
- Reference P/N: 165335-01
- Series / Platform: Bently Nevada 3500 Machinery Protection System
- Module Type: Vibration Transmitter
- Channels: Dual-channel signal conditioning
- Input: Compatible with Bently Nevada proximity probes (3300 XL, 7200 Series) and accelerometers
- Output: 4–20 mA analog / configurable voltage output
- Power Supply: Rack-powered via 3500 backplane (24 VDC nominal)
- Communication: Rack-integrated; compatible with 3500/20 Communication Gateway for Modbus, Profibus, or Ethernet/IP
- Measurement Parameters: Vibration (displacement, velocity, acceleration), gap/DC voltage
- Alarm Outputs: Configurable alert and danger relay outputs via rack I/O module
- Operating Temperature: 0°C to +65°C (32°F to 149°F)
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% RH, non-condensing
- Weight: 460 g (module only)
- Certifications: CE, cULus, SIL 2 capable (system-level)
- Compliance: API 670 compatible
- Country of Origin: USA
Proven Application Environments
- Gas turbines, steam turbines, and compressor trains in power generation plants
- Centrifugal and reciprocating compressors in LNG, refinery, and upstream oil & gas facilities
- Pumps, fans, and gearboxes in petrochemical and chemical processing
- Hydro turbines and large motor-driven equipment in utilities
- Pulp & paper, mining, and heavy industrial rotating machinery
- Any API 670-compliant machinery protection installation
Engineering Advantages
- API 670 Compliance: Meets the most stringent international standard for machinery protection systems, ensuring regulatory acceptance in critical installations.
- Rack-Integrated Architecture: Eliminates field-mounted transmitter enclosures; reduces wiring complexity and improves signal integrity.
- Configurable via System 1 / Rack Configuration Software: Full parameter configuration without hardware changes—alarm setpoints, measurement modes, and output scaling adjustable in software.
- Dual-Channel Design: Monitors two independent measurement points per module, maximizing rack density and reducing per-channel cost.
- High Signal Fidelity: Precision analog front-end with low noise floor, suitable for early fault detection in low-amplitude vibration regimes.
- Hot-Swap Capable: Designed for removal and insertion under power within the 3500 rack, minimizing maintenance downtime.
System Architecture & Signal Flow
The 990-05-XX-01-00 module installs into any standard 3500 rack slot. Transducer signals enter via the I/O module terminal block on the rear of the rack. The transmitter conditions the signal, applies configured filtering and scaling, and outputs a 4–20 mA loop signal to the plant DCS or SIS. Simultaneously, the module communicates measurement data over the rack backplane to the 3500/20 Communication Gateway for integration with historian and SCADA systems. Alarm relay outputs are routed through the rack’s relay output module for hardwired trip logic.
Sourcing & Quality Verification
- Source: Procured from authorized distributors and verified industrial surplus channels
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check prior to shipment
- Packaging: Anti-static ESD packaging with foam cushioning; original OEM packaging preserved where available
- Warranty: 12-month Konmask operational warranty against manufacturing defects
- Traceability: Serial number and firmware revision documented on request
Procurement Process
- Submit your RFQ or place order directly via Konmask.com product page
- Receive order confirmation and lead-time estimate within 1 business day
- Pre-shipment inspection report and packing list issued upon request
- Global shipping via DHL Express, FedEx, or UPS with full tracking
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is the 990-05-XX-01-00 compatible with all 3500 rack configurations?
A: Yes. The module is compatible with standard 3500 racks (3500/05, 3500/15, 3500/22M) and requires a corresponding I/O module for rear-panel signal termination.
Q: What transducer types are supported?
A: The module supports Bently Nevada 3300 XL and 7200 Series proximity probes, as well as compatible third-party eddy-current probes meeting the same sensitivity specification (typically 7.87 V/mm or 200 mV/mil).
Q: Can this module be used as a direct replacement for an existing 990-05 variant?
A: The 990-05-XX-01-00 designation covers the standard configuration. Confirm your existing module’s full part number and firmware revision with our technical team before substitution in a live system.
Q: Is SIL 2 certification available at the module level?
A: SIL 2 is achieved at the system level within a validated 3500 rack configuration. Contact Konmask for documentation support for your SIL assessment.
Q: What is the typical lead time?
A: In-stock units ship within 2–3 business days. For out-of-stock items, typical sourcing lead time is 2–4 weeks. Contact us for current availability.
