Precision Motion Control Solution – BERGER LAHR WDP3-014.0801 | WDP3 Series Positioning Controller
Where This Product Is Used
The BERGER LAHR WDP3-014.0801 is a compact, high-performance positioning controller engineered for demanding industrial motion control environments. It is widely deployed across the following application sectors:
- Packaging Machinery – Precise indexing and positioning of conveyor belts, filling stations, and labeling heads in food, beverage, and pharmaceutical packaging lines.
- Textile & Printing Equipment – Accurate web tension control and step-feed positioning in fabric cutting, screen printing, and digital printing machines.
- CNC & Machine Tool Systems – Axis positioning for milling, drilling, and turning centers requiring repeatable, high-resolution movement.
- Assembly Automation – Pick-and-place units, rotary indexing tables, and multi-axis gantry systems in automotive and electronics assembly.
- Medical & Laboratory Equipment – Syringe pumps, sample handling robots, and diagnostic instrument stages where smooth, quiet motion is critical.
- Semiconductor & Optics – Wafer handling, lens alignment, and precision stage control in cleanroom environments.
- Material Handling – Automated storage and retrieval systems (AS/RS), pallet shuttles, and sortation conveyors.
Technical Specifications
| Parameter | Value |
|---|---|
| Model / Part Number | WDP3-014.0801 |
| Brand | BERGER LAHR (Schneider Electric) |
| Series | WDP3 |
| Device Type | Positioning Controller / Stepper Drive |
| Output Current | 1.4 A (per phase, peak) |
| Supply Voltage | 24 VDC (nominal) |
| Control Interface | Step/Direction, RS-232/RS-485 (model dependent) |
| Microstep Resolution | Up to 1/64 step (model dependent) |
| Protection Class | IP20 |
| Operating Temperature | 0 °C to +45 °C |
| Weight | 1,350 g (approx.) |
| Mounting | DIN Rail / Panel Mount |
| Certifications | CE, UL (verify with datasheet) |
Note: Always verify specifications against the official BERGER LAHR / Schneider Electric datasheet before integration.
Why Engineers Specify This Model
- Integrated Positioning Logic – Onboard motion program storage eliminates the need for an external PLC in simple point-to-point applications, reducing panel space and wiring cost.
- Smooth Microstepping – Advanced current control minimizes resonance and audible noise, critical for medical and laboratory environments.
- Compact DIN-Rail Form Factor – Fits standard 35 mm DIN rail, simplifying cabinet integration alongside PLCs and I/O modules.
- Proven BERGER LAHR Reliability – Backed by decades of field deployment in European and global OEM machinery, with a well-documented spare-parts ecosystem.
- Flexible Communication – Supports serial fieldbus options compatible with legacy BERGER LAHR motion networks and modern Schneider Electric architectures.
Complete System Bill of Materials
For a fully functional WDP3-014.0801 positioning system, the following components are typically required:
- WDP3-014.0801 – Positioning Controller (this unit)
- BERGER LAHR / IMS Stepper Motor (e.g., VRDM series, matched to 1.4 A phase current)
- 24 VDC Power Supply (appropriately rated, e.g., Schneider Electric ABLM1A24025)
- Motor Cable & Encoder Cable (shielded, length per installation)
- Programming Cable (RS-232 to USB adapter for WDP3 configuration software)
- DIN Rail & Terminal Blocks
- Emergency Stop / Safety Relay (per local safety standards)
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and EMC Directive (verify with product label).
- RoHS – Manufactured under RoHS-compliant processes (confirm with batch documentation).
- ISO 9001 – BERGER LAHR / Schneider Electric production facilities are ISO 9001 certified.
- UL Recognition – UL listing applicable to select markets; confirm with product nameplate.
Quality Assurance & Sourcing
At Konmask.com, every WDP3-014.0801 unit is subject to a rigorous pre-shipment process:
- Visual inspection for physical damage, label integrity, and connector condition.
- Functional power-on test to verify LED status and communication response.
- Traceability documentation: serial number, batch record, and origin verification.
- Anti-static packaging with humidity indicator card for safe international transit.
- 30-day return window for DOA (Dead on Arrival) units with full replacement support.
How to Source This Part
- Add to Cart – Click the purchase button above to place your order directly.
- Request a Quote – For bulk orders (>3 units) or urgent requirements, email support@konmask.com for a dedicated quote within 24 hours.
- Provide Your PO – We accept purchase orders from verified industrial buyers and MRO procurement teams.
- Shipping – DHL Express / FedEx International Priority available. Typical lead time: 3–7 business days from stock.
- Phone / WhatsApp – Reach our technical team at +0086 19859288691 for urgent sourcing assistance.
Application-Specific FAQ
Q: Can the WDP3-014.0801 drive a NEMA 23 stepper motor?
A: Yes, provided the motor’s phase current rating does not exceed 1.4 A peak. Always match motor inductance to the drive’s voltage for optimal performance.
Q: Is this controller compatible with Schneider Electric SoMove software?
A: The WDP3 series predates SoMove; it uses the dedicated BERGER LAHR WDP3 configuration software. Contact us for software sourcing assistance.
Q: What is the difference between WDP3-014.0801 and WDP3-014.0802?
A: The suffix typically denotes firmware or hardware revision. Verify the exact revision required by your machine documentation before ordering.
Q: Can I use this drive in a 48 VDC system?
A: No. The WDP3-014.0801 is rated for 24 VDC supply. Using a higher voltage will damage the unit and void any warranty.
Q: Do you provide a warranty?
A: Yes. Konmask.com offers a 30-day DOA guarantee and 90-day limited warranty on all stocked units. Extended warranty options are available on request.
