Industrial Motion Control Solution – Bosch Rexroth HMS01.1N-W0150-A-07-NNNN | IndraDrive M Series
Where This Product Is Used
The Bosch Rexroth HMS01.1N-W0150-A-07-NNNN is a high-performance AC servo drive from the IndraDrive M (HMS01) series, engineered for demanding motion control applications across multiple industries:
- CNC Machine Tools – Precision axis control for milling, turning, and grinding centers requiring tight velocity and position loops.
- Robotics & Handling Systems – Multi-axis coordinated motion in articulated robots, SCARA arms, and gantry systems.
- Packaging Machinery – High-speed servo control for form-fill-seal, cartoning, and labeling lines.
- Printing & Converting – Register control and tension management in web-fed offset and flexographic presses.
- Semiconductor & Electronics Manufacturing – Ultra-precise positioning for pick-and-place, wafer handling, and PCB drilling.
- Plastics & Injection Molding – Servo-hydraulic and all-electric injection axis control.
- Material Handling & Conveyors – Synchronous multi-drive coordination in automated warehouses and sorting systems.
Technical Specifications
| Part Number | HMS01.1N-W0150-A-07-NNNN |
| Brand / Manufacturer | Bosch Rexroth |
| Series | IndraDrive M – HMS01 |
| Drive Type | AC Servo Drive (Single-Axis) |
| Continuous Output Current | 15 A (W0150) |
| Supply Voltage | 3 × AC 200–480 V, 50/60 Hz |
| DC Bus Voltage | 540–750 V DC |
| Firmware / Hardware Variant | A-07 |
| Option Code | NNNN (Standard, no additional options) |
| Communication Interface | SERCOS III / PROFIBUS / EtherCAT (firmware-dependent) |
| Cooling Method | Forced air (integrated fan) |
| Protection Class | IP20 (cabinet-mount) |
| Weight | 2.9 kg |
| Mounting | DIN rail / panel mount |
| Compatible Controllers | Rexroth IndraMotion MLC, MTX, CNC; Siemens SINUMERIK (via gateway) |
Why Engineers Specify This Model
- Scalable Power Range – The HMS01 family spans from 6 A to 210 A; the W0150 (15 A) covers the mid-range sweet spot for servo motors up to ~5 kW.
- Integrated Safety – Supports STO (Safe Torque Off) and SS1 (Safe Stop 1) per IEC 62061 / ISO 13849-1 PLe, eliminating external safety relays.
- High Dynamic Response – Current loop bandwidth >3 kHz enables sub-millisecond torque response for high-throughput automation.
- Multi-Protocol Flexibility – Single hardware platform supports SERCOS III, PROFIBUS DP, EtherCAT, and CANopen via firmware selection.
- Regenerative Capability – Energy fed back to the DC bus during deceleration reduces net energy consumption in multi-axis systems.
- Compact Footprint – Slim 50 mm width allows dense cabinet packing in space-constrained machine designs.
Complete System Bill of Materials
For a fully operational IndraDrive M axis, the following components are typically required alongside the HMS01.1N-W0150-A-07-NNNN:
- Power Supply Unit – Rexroth HMV01 or HMV02 mains supply module
- Servo Motor – Rexroth MSK / MKD / MHD series (matched to 15 A drive rating)
- Feedback Cable – Rexroth IKS / IKG encoder cable (motor-specific)
- Power Cable – Rexroth IKL motor power cable
- Control Card / Firmware – CSB01 or CSE02 control section (if not pre-installed)
- Communication Cable – SERCOS fiber or EtherCAT RJ45 patch cable
- Braking Resistor – HLR01 (if regenerative energy exceeds bus capacity)
- Controller – IndraMotion MLC L25 / L45 or equivalent PLC with motion library
Compliance & Industry Standards
- CE Marking – Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C – Power Conversion Equipment (North American market)
- IEC 61800-5-1 – Adjustable speed electrical power drive systems safety
- IEC 61800-3 – EMC requirements for drive systems
- ISO 13849-1 / IEC 62061 – Functional safety (STO: PLe / SIL 3)
- RoHS 2011/65/EU compliant
Quality Assurance & Sourcing
At Konmask.com, every unit undergoes a structured inspection process before dispatch:
- Visual inspection for physical damage, corrosion, and label integrity
- Part number and firmware version verification against Rexroth documentation
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Traceable sourcing from authorized distributors and OEM decommissions
All units are supplied with a 90-day warranty covering manufacturing defects and are eligible for Rexroth factory repair service referral.
How to Source This Part
Ready to order or need a formal quotation?
- Add to Cart – Immediate checkout for stocked units
- Request a Quote – Email support@konmask.com with your project BOM for volume pricing
- Urgent Requirement – Call/WhatsApp +0086 19859288691 for same-day response
- Lead Time – In-stock units ship within 1–3 business days; ex-stock orders 5–15 business days
- Export Documentation – Commercial invoice, packing list, and CO available for international shipments
Application-Specific FAQ
Q: Is the HMS01.1N-W0150-A-07-NNNN compatible with third-party servo motors?
A: The drive is optimized for Rexroth MSK/MKD motors. Third-party motors can be used with custom motor data sets, but Rexroth factory support may be limited. Contact us for compatibility assessment.
Q: Can this drive operate in standalone mode without a higher-level controller?
A: Yes. With the appropriate firmware, the HMS01 supports standalone operation via integrated motion programs (IndraWorks MP), enabling simple point-to-point or cam-profile motion without an external PLC.
Q: What is the difference between HMS01 and HMD01 drives?
A: HMS01 is a single-axis drive with an integrated power section. HMD01 is a double-axis drive sharing a common DC bus, offering higher power density for multi-axis cabinets.
Q: How do I update the firmware on this unit?
A: Firmware updates are performed via IndraWorks Engineering software over the SERCOS or EtherCAT interface. Ensure the target firmware version is compatible with your control section hardware revision (A-07 in this case).
Q: Is export of this product restricted?
A: This product may be subject to export control regulations (EAR/ECCN). Buyers are responsible for compliance with applicable export laws in their jurisdiction. Contact us for ECCN classification details.
