Industrial Automation Solution – B&R 2CP104.60-1 | Automation Runtime Series
Where This Product Is Used
The B&R 2CP104.60-1 is a compact PLC processor module engineered for demanding industrial automation environments. It is widely deployed in:
- Machine tool control systems – CNC machining centers, grinding machines, and multi-axis milling platforms requiring deterministic cycle times
- Packaging & filling lines – High-speed pick-and-place, form-fill-seal, and labeling machines where synchronized motion and I/O response are critical
- Automotive assembly – Body-in-white welding fixtures, press transfer lines, and end-of-line test benches
- Plastics & injection molding – Injection molding machines and extrusion lines requiring precise temperature and pressure loop control
- Renewable energy & power generation – Wind turbine nacelle controllers and solar inverter management systems
- Water & wastewater treatment – Pump station automation, SCADA-integrated filtration control, and dosing systems
Technical Specifications
- Part Number: 2CP104.60-1
- Manufacturer: B&R Industrial Automation
- Series: Automation Runtime (X20 / 2003 compatible)
- Module Type: CPU / Processor Module
- Operating System: B&R Automation Runtime
- Programming Standards: IEC 61131-3 (LD, FBD, ST, IL, SFC)
- Communication Interfaces: POWERLINK, CAN, RS232/RS485 (model-dependent)
- Supply Voltage: 24 V DC
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −25 °C to +70 °C
- Protection Rating: IP20
- Weight: approx. 4,800 g (packaged)
- Certifications: CE, UL, cUL
Why Engineers Specify This Model
- Deterministic real-time performance – Automation Runtime guarantees microsecond-level task jitter, essential for motion-critical applications
- Seamless B&R ecosystem integration – Drop-in compatible with X20 I/O slices, ACOPOS servo drives, and Automation Studio IDE without additional gateways
- Compact DIN-rail form factor – Minimizes panel footprint while delivering full CPU-class processing power
- Long lifecycle availability – B&R maintains extended product support, reducing obsolescence risk for OEM machine builders
- Unified engineering environment – Single Automation Studio project covers PLC logic, motion, HMI, and safety, reducing commissioning time
Complete System Bill of Materials
For a fully operational control cabinet based on the 2CP104.60-1, engineers typically specify:
- B&R 2CP104.60-1 – CPU Processor Module (this item)
- B&R X20PS9400 – 24 V DC Power Supply Module
- B&R X20DI9371 – Digital Input Module (12 × 24 V DC)
- B&R X20DO9322 – Digital Output Module (12 × 24 V DC, 0.5 A)
- B&R X20AI1744 – Analog Input Module (4 × ±10 V / 0–20 mA)
- B&R X20BB80 – Bus Base for X20 modules
- POWERLINK Managing Node cable (Cat 5e shielded)
- 24 V DC DIN-rail power supply (Phoenix Contact or equivalent)
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- UL 508 – Industrial Control Equipment (North American market)
- IEC 61131-3 – PLC programming language standard
- POWERLINK – IEC 61784-2 real-time Ethernet protocol
- RoHS 2 – Directive 2011/65/EU compliant
Quality Assurance & Sourcing
Every B&R 2CP104.60-1 unit shipped by Konmask.com undergoes a documented inspection process:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware version verification against B&R release notes
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Traceability documentation available on request (batch/lot records)
We source from authorized distributors and verified surplus channels. Counterfeit-risk screening is applied to all B&R inventory.
How to Source This Part
- In-stock orders: Add to cart and check out — ships within 1–3 business days from our warehouse
- Bulk / project orders (5+ units): Contact us for volume pricing and lead-time commitment
- Urgent / emergency replacement: Email support@konmask.com with your required delivery date — we prioritize downtime recovery requests
- International shipping: Available to 50+ countries; DDP (Delivered Duty Paid) terms available for EU and select markets
Application-Specific FAQ
Q: Is the 2CP104.60-1 compatible with Automation Studio 4.x?
A: Yes. The module is supported under Automation Studio 4.x with the appropriate hardware configuration package. Confirm the exact AS version compatibility in the B&R online help portal before upgrading firmware.
Q: Can this CPU run safety functions (SafeLOGIC)?
A: The 2CP104.60-1 is a standard (non-safety) CPU. For integrated safety, pair it with a B&R X20SL8100 SafeLOGIC module on the same POWERLINK network.
Q: What is the maximum number of I/O points supported?
A: Depends on the POWERLINK network topology and cycle time settings. Consult the B&R system designer tool for your specific I/O count and scan-time requirements.
Q: Do you provide a warranty?
A: Yes — 12-month warranty against defects in materials and workmanship. RMA process initiated within 24 hours of confirmed fault report.
Q: Can I get a datasheet or wiring diagram?
A: Yes. Email support@konmask.com with your part number and application details.
