DALSA VA2-03-C11-1 – 0.3MP Color Area Scan Camera | Genie Platform
Engineering Background
The DALSA VA2-03-C11-1 is part of the Genie series of area scan cameras engineered by Teledyne DALSA for demanding industrial machine vision applications. Designed to deliver consistent, high-fidelity color imaging in compact form factors, the Genie platform has been deployed across semiconductor inspection, electronics assembly, pharmaceutical packaging, and logistics sorting lines worldwide.
Product Positioning
The VA2-03-C11-1 targets OEM integrators and system builders who require a reliable, cost-effective 0.3MP color camera with CameraLink output. Its compact housing, deterministic trigger response, and broad illumination compatibility make it a preferred choice for inline quality inspection and robotic guidance systems where pixel-accurate color discrimination is critical.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Model | VA2-03-C11-1 |
| Brand / Manufacturer | Teledyne DALSA |
| Series | Genie Area Scan |
| Resolution | 0.3 MP (640 × 480) |
| Sensor Type | CCD Color |
| Color / Mono | Color |
| Interface | CameraLink (Base) |
| Frame Rate | Up to 90 fps (at full resolution) |
| Pixel Size | 7.4 µm × 7.4 µm |
| Shutter Type | Global Shutter |
| Trigger Mode | Hardware / Software Trigger |
| Power Supply | 12–24 VDC via CameraLink connector |
| Power Consumption | ≤ 3.5 W |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Dimensions (L×W×H) | 44 × 44 × 30 mm (approx.) |
| Weight | ~380 g (with housing) |
| Lens Mount | C-Mount |
| Compliance | CE, FCC, RoHS |
| Part Number | VA2-03-C11-1 |
Proven Application Environments
- Electronics PCB Inspection: Color solder joint and component presence verification on SMT lines
- Pharmaceutical Packaging: Label color verification, cap color sorting, and blister pack inspection
- Food & Beverage: Color grading, foreign object detection, and fill-level inspection
- Logistics & Parcel Sorting: Barcode reading assist and color-coded label classification
- Semiconductor Wafer Handling: Wafer edge and surface color anomaly detection
- Robotic Guidance: Color-based object localization for pick-and-place systems
Engineering Advantages
- Global Shutter: Eliminates motion blur for high-speed moving targets — critical for conveyor-based inspection
- CameraLink Base Interface: Deterministic, low-latency data transfer with proven industrial reliability; compatible with all major frame grabbers
- Compact C-Mount Form Factor: Fits standard machine vision lens libraries; easy integration into existing optical assemblies
- Wide Operating Temperature: 0–50°C continuous operation without active cooling
- DALSA Sapera SDK Compatible: Seamless integration with Teledyne DALSA’s Sapera LT and Sapera Processing libraries for rapid application development
- Hardware Trigger Input: Sub-millisecond trigger latency for precise synchronization with PLCs and motion controllers
System Architecture & Signal Flow
The VA2-03-C11-1 operates within a standard CameraLink machine vision architecture:
- Illumination Source → Structured or diffuse light (ring, coaxial, or dome) illuminates the target object
- Lens (C-Mount) → Focuses image onto the CCD sensor; select lens based on working distance and field of view
- VA2-03-C11-1 Camera → Captures color image frame; outputs digital data via CameraLink Base cable
- Frame Grabber (PCIe) → Receives CameraLink data stream; transfers to host PC memory via DMA
- Host PC / Vision Software → Processes image using Sapera SDK, Halcon, VisionPro, or OpenCV; outputs pass/fail or measurement data
- PLC / Robot Controller → Receives inspection result via I/O or fieldbus; executes reject, sort, or guidance action
Sourcing & Quality Verification
Konmask.com sources the DALSA VA2-03-C11-1 through verified industrial automation supply channels. Every unit undergoes the following pre-shipment process:
- Visual inspection for housing integrity and connector condition
- Power-on functional verification (image capture confirmed)
- Serial number and firmware version documentation
- Anti-static packaging with desiccant for transit protection
We supply both new-in-box and tested surplus units. Condition is clearly stated on each listing. All units are shipped with a 90-day operational warranty.
Procurement Process
- Confirm Requirement: Verify part number VA2-03-C11-1 against your BOM or existing system documentation
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and condition options
- Order Placement: Purchase directly via Konmask.com checkout or via proforma invoice for B2B orders
- Shipping: DHL / FedEx Express worldwide; export documentation (commercial invoice, packing list) provided
- Incoming Inspection: We recommend verifying serial number and performing power-on test upon receipt
Technical FAQ
Q: Is the VA2-03-C11-1 compatible with National Instruments frame grabbers?
A: Yes. The CameraLink Base interface is compatible with NI PCIe-1427, PCIe-1433, and similar NI frame grabbers using the standard CameraLink configuration file (CCF).
Q: What frame grabber do you recommend for this camera?
A: Teledyne DALSA’s own Xcelera-CL PX4 or Matrox Solios eA/XA are proven pairings. Any CameraLink Base-compliant frame grabber will work.
Q: Can this camera be used with GigE Vision software?
A: No. The VA2-03-C11-1 uses CameraLink, not GigE Vision. It requires a physical CameraLink frame grabber and is not compatible with GigE Vision or GenICam over Ethernet.
Q: What is the minimum cable length for CameraLink?
A: Standard CameraLink cables support up to 10 meters at Base configuration. For longer runs, use Camera Link repeaters or fiber optic extenders.
Q: Do you provide the Sapera SDK or camera configuration files?
A: Sapera LT SDK is freely available from Teledyne DALSA’s website. We can provide the camera configuration file (CCF/VIC) upon request.
Q: What is the warranty on this unit?
A: All units sold by Konmask.com carry a 90-day operational warranty. Extended warranty options are available — contact us for details.
