Machine Vision Inspection Solution – ALLIED Vision Stingray C2514-M | Stingray Series
The ALLIED Vision Stingray C2514-M (SKUs: C2514-M / F146B / 36-0442 / 54-0442 / 7520572050 / 0920-01014 / LF-5SWC) is a high-performance monochrome CCD camera engineered for demanding industrial imaging applications. Bundled with a Pentax 25mm TV Lens, this system delivers sharp, distortion-free imagery across a wide range of automated inspection and measurement environments.
Where This Product Is Used
- Automated Optical Inspection (AOI) – PCB defect detection on SMT assembly lines
- Pharmaceutical Packaging Lines – Label verification, fill-level inspection, and cap integrity checks
- Semiconductor Wafer Handling – Die alignment and surface defect classification
- Food & Beverage Sorting – Foreign object detection and color/shape grading
- Automotive Parts Inspection – Dimensional gauging of machined components and weld seam analysis
- Logistics & Barcode Reading – High-speed parcel identification on conveyor systems
- Robotics Guidance – Vision-guided pick-and-place and bin-picking systems
Technical Specifications
- Model: Stingray C2514-M (Monochrome)
- Part Numbers: C2514-M | F146B | 36-0442 | 54-0442 | 7520572050 | 0920-01014 | LF-5SWC
- Sensor Type: CCD (Charge-Coupled Device)
- Interface: IEEE 1394b FireWire 800
- Lens Included: Pentax 25mm TV Lens (C-mount)
- Lens Mount: C-mount
- Housing: Compact industrial-grade aluminum enclosure
- Weight: ~800 g (camera + lens assembly)
- Operating Temperature: 0°C to +45°C
- Compliance: CE, FCC, RoHS
Why Engineers Specify This Model
- Proven CCD Sensitivity: Superior low-noise performance in low-light or high-contrast inspection environments compared to CMOS alternatives of the same era
- FireWire 800 Bandwidth: Enables high frame-rate streaming with deterministic latency — critical for real-time feedback loops in PLC-controlled lines
- Pentax 25mm Pairing: The bundled lens provides a balanced field of view for mid-range working distances (300–800 mm), minimizing vignetting and chromatic aberration
- ALLIED Vision SDK Compatibility: Fully supported by Vimba SDK and legacy UniCap/AVT FirePackage drivers for rapid integration
- Compact Form Factor: Fits standard 38mm camera mounting brackets without custom adapters
Complete System Bill of Materials
- ALLIED Vision Stingray C2514-M Camera Body (P/N: 36-0442 / 54-0442)
- Pentax 25mm TV Lens, C-mount (P/N: LF-5SWC / F146B)
- IEEE 1394b FireWire 800 Cable (9-pin to 9-pin, customer-supplied)
- FireWire 800 PCIe Host Adapter Card (customer-supplied)
- Camera mounting bracket – 38mm standard (customer-supplied)
- ALLIED Vision Vimba SDK (free download from ALLIED Vision website)
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU
- FCC Part 15 Class B – Electromagnetic interference compliance
- RoHS Directive 2011/65/EU – Restriction of hazardous substances
- IEEE 1394b Standard – FireWire 800 protocol compliance
- ISO 9001 – Manufactured under ALLIED Vision’s quality management system
Quality Assurance & Sourcing
All units offered through Konmask.com are sourced from verified industrial surplus, decommissioned OEM lines, or authorized secondary-market channels. Each camera undergoes a functional power-on check and visual inspection prior to listing. Condition is accurately described — surplus/used units are clearly noted. We do not misrepresent refurbished stock as new.
How to Source This Part
- Click Add to Cart or Request a Quote for volume orders
- For urgent requirements, contact us directly: support@konmask.com or +0086 19859288691
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Export documentation (commercial invoice, packing list, COO) provided for international shipments
Application-Specific FAQ
Q: Is the Stingray C2514-M compatible with modern Windows 10/11 systems?
A: Yes, via ALLIED Vision’s Vimba SDK with a compatible FireWire 800 PCIe adapter. Legacy AVT FirePackage drivers also support Windows 7/8.
Q: Can this camera be triggered externally from a PLC?
A: Yes. The Stingray series supports hardware trigger input via its GPIO connector, compatible with 5–24V PLC output signals.
Q: What is the maximum frame rate at full resolution?
A: Dependent on resolution setting; at reduced ROI, frame rates above 30 fps are achievable over FireWire 800.
Q: Is the Pentax 25mm lens fixed or interchangeable?
A: The C-mount lens is interchangeable. The 25mm Pentax is included but any standard C-mount lens can be substituted.
Q: Do you provide a warranty?
A: A 30-day functional warranty is provided on all tested units. Extended warranty available upon request.
