Precision Motion Control Solution – DIVERSEN TD-300CU-200AC-G20L2-5U-J | TD-300 Series
Where This Product Is Used
The DIVERSEN TD-300CU-200AC-G20L2-5U-J Linear Motor Driver is engineered for high-precision, high-dynamic motion control applications across demanding industrial environments. Typical deployment scenarios include:
- Semiconductor wafer handling & lithography stages – sub-micron positioning accuracy required
- PCB pick-and-place machines – high-speed linear axis control with minimal settling time
- CNC machining centers & grinding machines – direct-drive linear axes eliminating backlash
- Laser cutting & engraving systems – smooth velocity profiles for clean cut edges
- Automated optical inspection (AOI) equipment – fast, repeatable scanning motion
- Medical imaging & laboratory automation – quiet, vibration-free linear actuation
- Gantry & multi-axis Cartesian robots – synchronized multi-axis coordination
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | TD-300CU-200AC-G20L2-5U-J |
| Brand / Manufacturer | DIVERSEN |
| Series | TD-300 |
| Driver Type | Linear Motor Driver (Servo Amplifier) |
| Input Voltage | 200 VAC (single/three-phase) |
| Continuous Output Current | 20 A |
| Encoder Interface | Linear encoder (L2 type) |
| Axis Count | Up to 5 axes (5U) |
| Communication Interface | J-type (EtherCAT / proprietary high-speed bus) |
| Control Mode | Position / Velocity / Force (Thrust) control |
| Cooling Method | Forced air / heatsink (model dependent) |
| Weight | 13.6 kg |
| Compliance | CE, RoHS |
Why Engineers Specify This Model
- Direct-drive architecture – eliminates mechanical transmission components (ballscrews, gearboxes), reducing maintenance and improving repeatability
- 20 A continuous current rating – sufficient thrust force for medium-to-heavy payload linear stages
- 5-axis expandability – a single TD-300CU unit can coordinate up to 5 independent linear axes, reducing cabinet footprint
- 200 VAC input compatibility – standard industrial power supply, no step-up transformer required in most facilities
- L2 linear encoder interface – direct feedback from high-resolution linear scales for closed-loop nanometer-level control
- J-type high-speed communication – deterministic real-time bus for tight multi-axis synchronization
Complete System Bill of Materials
A complete linear motor drive system typically requires the following components (available separately at Konmask.com):
- DIVERSEN TD-300CU-200AC-G20L2-5U-J – Linear Motor Driver (this unit)
- DIVERSEN linear motor forcer (coil assembly) – matched to stage load
- DIVERSEN linear motor magnet track – matched to travel length
- High-resolution linear encoder + read head (L2 compatible)
- 24 VDC control power supply
- EtherCAT master controller or motion controller (J-bus compatible)
- EMC line filter & braking resistor (application dependent)
- Shielded motor power cable & encoder cable
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) & EMC Directive compliant
- RoHS – Restriction of Hazardous Substances compliant
- IEC 61800-5-1 – Safety requirements for adjustable speed electrical power drive systems
- ISO 9001 – Manufactured under quality management system certification
Quality Assurance & Sourcing
All DIVERSEN products supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes incoming inspection including:
- Visual inspection for physical damage and label authenticity
- Serial number verification against manufacturer records
- Functional power-on test where applicable
- Anti-static packaging and climate-controlled storage
We maintain traceability documentation for every shipment. Counterfeit-free guarantee backed by our sourcing policy.
How to Source This Part
- Request a Quote – Contact us at support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Lead Time – In-stock units ship within 3–5 business days. Out-of-stock units: 4–8 weeks standard lead time.
- Payment – T/T (bank transfer), PayPal, and trade assurance accepted.
- Shipping – DHL / FedEx / UPS express worldwide. Sea freight available for bulk orders.
- Export Documentation – Commercial invoice, packing list, and certificate of origin provided for all international shipments.
Application-Specific FAQ
Q: Can the TD-300CU drive ironless linear motors?
A: Yes. The TD-300CU supports both iron-core and ironless linear motor configurations. Confirm coil resistance and inductance parameters with DIVERSEN’s motor matching guide before commissioning.
Q: What is the maximum travel speed supported?
A: Maximum velocity is determined by the linear encoder resolution and the bus cycle time. With L2 encoder interface and J-type communication, speeds exceeding 3 m/s are achievable depending on stage mechanics.
Q: Is the TD-300CU compatible with third-party motion controllers?
A: The J-type interface is optimized for DIVERSEN’s own controller ecosystem. EtherCAT compatibility may require firmware configuration. Contact us for integration support.
Q: Do you provide commissioning support?
A: Konmask.com provides pre-sales technical consultation and can connect customers with DIVERSEN-certified integrators for on-site commissioning.
Q: What warranty applies?
A: 12-month warranty against manufacturing defects from date of shipment, subject to correct installation and operating conditions.
