Echelon 35100 ISA Network Interface Card with FTM-10 SMX — LonWorks / LON Platform
Engineering Background
The Echelon 35100 is a full-featured ISA-bus LonWorks Network Interface Card (NIC) designed for PC-based LON network management, commissioning, and monitoring applications. Paired with the FTM-10 SMX free-topology transceiver module, this card enables reliable communication across mixed-topology LonWorks segments — making it a proven tool for building automation integrators, OEM developers, and system commissioning engineers.
Product Positioning
Targeted at engineers maintaining legacy LON infrastructure or developing LonWorks-based control systems, the 35100 ISA NIC provides a direct hardware interface between a host PC and a LonWorks TP/FT-10 network. It is compatible with Echelon’s LonMaker Integration Tool, LNS, and third-party LON network management software. Konmask.com supplies verified surplus units with full functional testing documentation available upon request.
Complete Technical Specifications
| Part Number | 35100 |
| Form Factor | ISA 16-bit Bus Card |
| Transceiver Module | FTM-10 SMX (Free-Topology, TP/FT-10) |
| Network Protocol | LonWorks / LON (ISO/IEC 14908) |
| Topology Support | Free-topology (bus, star, loop, mixed) |
| Max Nodes per Segment | Up to 128 nodes (with repeater) |
| Data Rate | 78 kbps (TP/FT-10) |
| Host Interface | ISA 16-bit slot |
| Neuron Chip | Echelon Neuron 3150 / 3120 (onboard) |
| Operating Voltage | 5 VDC (ISA bus supplied) |
| Operating Temperature | 0°C to +70°C |
| Dimensions | Standard ISA half-length card |
| Weight | Approx. 1,350 g (packaged) |
| Compliance | LONMARK Certified, CE |
| Software Compatibility | LonMaker, LNS, NodeBuilder, OpenLNS |
| Manufacturer | Echelon Corporation (now part of Adesto/Dialog) |
| Country of Origin | USA |
Proven Application Environments
- Building Automation Systems (BAS): HVAC control, lighting management, access control integration via LonWorks backbone
- Industrial Process Control: LON-based PLC/DCS integration and field device commissioning
- Energy Management: Metering and demand-response systems on TP/FT-10 segments
- Transportation Infrastructure: Traffic signal control and tunnel ventilation LON networks
- OEM Development: Embedded LON network interface for custom PC-based controllers
- Legacy System Maintenance: Replacement NIC for existing Echelon-based LON installations
Engineering Advantages
- Free-Topology Flexibility: FTM-10 SMX transceiver supports bus, star, and mixed wiring without topology restrictions, reducing installation cost
- Onboard Neuron Processing: Dedicated Neuron chip offloads LON protocol stack from host CPU, ensuring deterministic network timing
- LONMARK Certified: Interoperability guaranteed with all LONMARK-certified devices across vendors
- Broad Software Ecosystem: Native support for LonMaker, LNS, NodeBuilder, and OpenLNS — no custom drivers required
- Proven Field Reliability: Thousands of units deployed globally in mission-critical BAS and industrial LON networks
- Surplus Availability: Konmask maintains verified surplus inventory for MRO and legacy system support without long lead times
System Architecture & Signal Flow
The 35100 ISA NIC operates as a LON network node from the host PC’s perspective. The onboard Neuron chip handles the full LonWorks protocol stack (Layers 1–6), communicating with the host via the ISA bus using Echelon’s Host Application Programmer’s Interface (HAPI). The FTM-10 SMX transceiver module connects to the TP/FT-10 twisted-pair network segment, providing differential signal transmission at 78 kbps. The host PC runs LNS or compatible software to issue network management commands, configure node variables, and monitor network health — all routed through the 35100 NIC as the network interface gateway.
Signal Flow: Host PC Application → ISA Bus → Neuron 3150 (HAPI) → FTM-10 SMX Transceiver → TP/FT-10 Network Segment → LON Field Devices
Sourcing & Quality Verification
- All units sourced from verified surplus channels with documented chain of custody
- Pre-shipment functional inspection: visual, connector integrity, and board-level check
- Full functional testing available upon request (LON network enumeration test)
- Original manufacturer packaging preserved where available
- Counterfeit-prevention: units cross-referenced against Echelon part number database
- 90-day warranty on all Konmask-supplied surplus components
Procurement Process
- Inquiry: Submit your BOM or part number to support@konmask.com or via the product page
- Quote: Receive a formal quotation with lead time and stock confirmation within 1 business day
- Order Confirmation: Purchase order accepted via Shopify checkout, bank transfer, or B2B invoice
- Inspection & Dispatch: Unit inspected, photographed, and dispatched with tracking within 2–3 business days
- Delivery: DHL / FedEx express international shipping; customs documentation provided
- After-Sales: Technical support available via email for integration and commissioning queries
Technical FAQ
Q: Is the 35100 compatible with modern Windows operating systems?
A: The 35100 ISA NIC requires a physical ISA slot, which is not present on modern motherboards. It is designed for use with legacy industrial PCs or ISA-bus embedded systems running Windows XP/7 or compatible LNS environments. For modern PC integration, consider Echelon’s USB or PCIe LON NICs.
Q: Can the FTM-10 SMX transceiver be replaced or upgraded?
A: Yes. The FTM-10 SMX is a plug-in transceiver module. It can be replaced with other compatible Echelon transceiver modules (e.g., FTT-10A) if a different physical medium is required, subject to board compatibility.
Q: What is the maximum cable length for TP/FT-10 with FTM-10 SMX?
A: In a free-topology configuration, the total wire length is up to 500 meters. In a bus topology, up to 2,700 meters is achievable with appropriate termination.
Q: Does Konmask provide a certificate of conformance?
A: Yes. A certificate of conformance and inspection report can be provided upon request for B2B and OEM orders.
Q: Is this product RoHS compliant?
A: As a legacy surplus component, RoHS compliance status follows the original Echelon manufacturing specification. Please contact us for documentation if required for your compliance program.
