Emerson KJ3241X1-BA1 12P2506X052 – Serial Interface Module | DeltaV DCS Platform
Engineering Background: The KJ3241X1-BA1 (part number 12P2506X052) is a serial communications interface module designed for Emerson’s DeltaV distributed control system. It provides reliable RS-232/RS-485 serial connectivity between DeltaV controllers and third-party field devices, enabling seamless integration of legacy instrumentation, analyzers, and smart transmitters into modern DCS architectures.
Product Positioning: Targeted at process automation engineers and MRO procurement teams managing DeltaV installations in oil & gas, chemical, power generation, and pharmaceutical facilities. This module is a direct OEM replacement part, ensuring full compatibility with existing DeltaV hardware and firmware revisions without re-engineering.
Complete Technical Specifications
- Manufacturer: Emerson Electric / Emerson Automation Solutions
- Part Number: KJ3241X1-BA1
- Sub-Part / Revision: 12P2506X052
- Module Type: Serial Interface Module (SIM)
- Platform: Emerson DeltaV DCS
- Communication Protocol: RS-232 / RS-485 serial
- Mounting: DeltaV I/O carrier / backplane
- Power Supply: Supplied via DeltaV carrier backplane
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% RH, non-condensing
- Weight: Approx. 200 g
- Certifications: CE, UL (per Emerson DeltaV system certification)
- Firmware: Compatible with DeltaV v10.3 and above
- Form Factor: Standard DeltaV I/O module
Proven Application Environments
- Oil & Gas upstream/downstream process control (SCADA integration, analyzer interfaces)
- Chemical plant DCS expansions requiring legacy serial device integration
- Power generation facilities connecting smart transmitters via RS-485 Modbus
- Pharmaceutical manufacturing with 21 CFR Part 11 compliant DeltaV systems
- Refinery control rooms upgrading I/O subsystems without full DCS replacement
- Water treatment plants integrating third-party flow meters and analyzers
Engineering Advantages
- Drop-in OEM Replacement: Identical form, fit, and function to original factory module — no reconfiguration required
- Dual Protocol Support: RS-232 and RS-485 on a single module reduces spare parts inventory
- Hot-Swap Capable: Supports DeltaV online module replacement to minimize process downtime
- Noise Immunity: Industrial-grade isolation protects DCS backplane from field-side transients
- Long Service Life: Designed for 24/7 continuous operation in harsh industrial environments
- Firmware Compatibility: Validated across multiple DeltaV software versions for broad fleet applicability
System Architecture & Signal Flow
The KJ3241X1-BA1 installs directly into a DeltaV I/O carrier slot. Field serial devices connect to the module’s terminal block via shielded twisted-pair cable. The module converts serial data frames to DeltaV’s internal I/O bus protocol, making device parameters available as standard DeltaV parameters accessible from any DeltaV controller or workstation on the network. Signal isolation is maintained between the field-side serial interface and the DeltaV backplane bus, protecting system integrity.
Sourcing & Quality Verification
- Condition: New surplus / refurbished — fully tested and function-verified prior to shipment
- Traceability: Each unit inspected against OEM part number and revision markings
- Testing: Power-on functional test performed; communication ports verified
- Packaging: Anti-static ESD packaging with moisture barrier; double-boxed for international freight
- Warranty: 12-month replacement warranty against manufacturing defects
- Counterfeit Prevention: All units sourced from verified industrial MRO channels; OEM labels and markings authenticated
Procurement Process
- Confirm Compatibility: Verify your DeltaV system version and carrier slot type against the KJ3241X1-BA1 datasheet
- Request Quote: Contact us at support@konmask.com for volume pricing or urgent RFQ
- Place Order: Add to cart and complete checkout — we accept T/T, PayPal, and major credit cards
- Shipping: Orders dispatched within 1–3 business days via DHL / FedEx with full tracking
- Documentation: Commercial invoice, packing list, and test report provided with every shipment
Technical FAQ
Q: Is this module compatible with DeltaV v13 / v14?
A: Yes. The KJ3241X1-BA1 is backward compatible with DeltaV v10.3 through current releases. Confirm your specific firmware revision with our technical team if needed.
Q: Can this module be used for Modbus RTU communication?
A: Yes. The RS-485 port supports Modbus RTU when configured via DeltaV’s serial device integration tools.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Contact us for availability confirmation before placing large orders.
Q: Do you provide a test report?
A: Yes. A functional test report is included with every shipment at no additional charge.
Q: Can I return the module if it does not work in my system?
A: Yes. We offer a 30-day return policy and 12-month warranty. Contact support@konmask.com to initiate a return.
