Emerson KJ3241X1-BA2 Serial Interface Card – RS-232/RS-485 Communication Module | DeltaV Platform
Engineering Background
The Emerson KJ3241X1-BA2 is a dedicated serial communication interface card engineered for integration within Emerson’s DeltaV Distributed Control System (DCS) architecture. Designed to bridge legacy serial field devices with modern DCS infrastructure, this module enables reliable RS-232 and RS-485 data exchange in demanding process automation environments. It is a critical component for facilities managing mixed-protocol device networks across oil & gas, chemical, power generation, and pharmaceutical operations.
Product Positioning
As a genuine Emerson DeltaV I/O subsystem card, the KJ3241X1-BA2 is purpose-built for procurement engineers who require certified, drop-in compatible hardware with full traceability. Konmask.com supplies this module with quality verification documentation, supporting both MRO replacement and new system integration projects.
Complete Technical Specifications
| Part Number | KJ3241X1-BA2 |
| Manufacturer | Emerson Electric Co. |
| Product Family | DeltaV Series DCS I/O |
| Module Type | Serial Interface Card |
| Communication Protocols | RS-232, RS-485 |
| Interface Standard | Serial (EIA/TIA-232, EIA/TIA-485) |
| Form Factor | DeltaV I/O Card (plug-in module) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Power Supply | Supplied via DeltaV I/O bus backplane |
| Approvals / Certifications | CE, UL (refer to Emerson datasheet for full listing) |
| Weight | Approx. 200 g |
| Country of Origin | United States |
| Condition | New / Refurbished (specify at inquiry) |
Proven Application Environments
- Oil & Gas: Upstream SCADA and wellhead controller serial integration into DeltaV host systems
- Chemical Processing: Serial-linked analyzers, flow computers, and chromatographs interfaced to DCS
- Power Generation: Turbine control serial data acquisition and historian connectivity
- Pharmaceutical / Life Sciences: 21 CFR Part 11-compliant process data collection via serial field instruments
- Pulp & Paper / Water Treatment: Legacy PLC and RTU serial bridge to DeltaV control network
Engineering Advantages
- Native DeltaV platform compatibility — no additional gateway hardware required
- Supports both RS-232 (point-to-point) and RS-485 (multi-drop, up to 32 nodes) topologies
- Hot-swap capable within DeltaV I/O subsystem for minimal process disruption
- Deterministic serial communication with configurable baud rates and parity settings
- Compact card form factor reduces panel space requirements
- Full backward compatibility with existing DeltaV I/O carrier and controller infrastructure
System Architecture & Signal Flow
The KJ3241X1-BA2 installs directly into a DeltaV I/O carrier card slot. Serial field devices connect via the card’s RS-232 or RS-485 port. Data is transmitted over the DeltaV I/O bus to the DeltaV controller, where it is processed and made available to the DeltaV Operate HMI and historian. The module supports standard Modbus RTU and proprietary serial protocols as configured in DeltaV Control Studio. Signal isolation and surge protection are provided per Emerson’s I/O subsystem design standards.
Sourcing & Quality Verification
- All units sourced from authorized distribution channels or certified MRO suppliers
- Pre-shipment functional inspection and visual verification performed
- Original manufacturer labels, firmware revision, and date codes intact
- Traceability documentation available upon request (CoC, test reports)
- Anti-static packaging with humidity indicator card for safe transit
Procurement Process
- Submit RFQ via [email protected] or place order directly on Konmask.com
- Receive order confirmation with lead time and shipping estimate within 1 business day
- Quality inspection completed and documentation prepared prior to dispatch
- Shipment via DHL / FedEx / UPS with full tracking; export documentation included
- Post-delivery technical support available for integration assistance
Technical FAQ
Q: Is the KJ3241X1-BA2 compatible with all DeltaV controller versions?
A: The card is designed for DeltaV I/O subsystem compatibility. Please confirm your DeltaV controller version and carrier type with our technical team prior to ordering.
Q: Can this card support Modbus RTU protocol?
A: Yes. When configured in DeltaV Control Studio, the KJ3241X1-BA2 supports Modbus RTU over RS-485 multi-drop networks.
Q: What is the maximum RS-485 network length?
A: Per EIA/TIA-485 standard, maximum cable length is 1,200 meters (4,000 ft) at lower baud rates. Actual performance depends on cable quality and termination.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 12-month warranty on all modules. Extended warranty options are available — contact us for details.
Q: Can I request a datasheet or wiring diagram?
A: Yes. Contact [email protected] and reference part number KJ3241X1-BA2 for full technical documentation.
