GE 469-P5-HI-A20 Motor Management Relay – Multilin 469 Series
When a critical motor fails unexpectedly on the plant floor — whether driving a compressor, pump, or conveyor — the consequences cascade instantly: unplanned downtime, production losses, and potential equipment damage that can cost tens of thousands of dollars per hour. Without intelligent motor protection, operators are left reacting to failures rather than preventing them. The GE Multilin 469-P5-HI-A20 Motor Management Relay eliminates this vulnerability by delivering comprehensive, real-time protection and monitoring that keeps your motors running safely and reliably.
The GE Multilin 469 series is one of the most trusted motor management platforms in global industrial automation. The 469-P5-HI-A20 variant occupies a premium position within this series, featuring high-interrupting (HI) current inputs and an analog output (A20) configuration that makes it ideal for demanding, high-power motor applications. Deployed across oil & gas, mining, water treatment, and heavy manufacturing facilities worldwide, the 469 series has established itself as the benchmark for comprehensive motor protection relay technology.
Technical Specifications
- Model: 469-P5-HI-A20
- Series: GE Multilin 469 Motor Management Relay
- Current Input Type: High-Interrupting (HI)
- Analog Output: A20 configuration
- Power Supply: P5 (please confirm with datasheet for exact voltage range)
- Communication: RS-485 Modbus RTU / DNP3.0
- Protection Functions: Thermal model, overload, undercurrent, phase unbalance, ground fault, stall/jam, starts per hour, winding RTD, bearing RTD
- Metering: Current (3-phase + ground), power, energy, motor thermal capacity
- Inputs/Outputs: Multiple digital inputs, relay outputs, and analog outputs
- Display: Alphanumeric LCD with LED indicators
- Weight: Approx. 5.04 kg
- Standards: IEC, ANSI/IEEE, UL, CE
Note: Always verify specifications against the official GE Multilin 469 instruction manual for your specific firmware revision.
Key Features & Benefits
- Comprehensive Motor Protection: Over 20 protection elements covering thermal, electrical, and mechanical failure modes — all in a single relay.
- Advanced Thermal Modeling: Accurate thermal capacity tracking accounts for ambient temperature, RTD inputs, and motor cooling curves to prevent insulation damage.
- High-Interrupting Current Inputs (HI): Designed for high-power motors where fault currents are significantly elevated, ensuring accurate measurement without saturation.
- Analog Output (A20): Enables seamless integration with SCADA, DCS, and PLC systems for real-time motor health data transmission.
- Predictive Maintenance Ready: Motor run hours, number of starts, and thermal capacity logs support proactive maintenance scheduling.
- Reduced Downtime: Fast fault detection and trip times minimize motor damage and accelerate post-fault restart procedures.
- Flexible Communications: Modbus RTU and DNP3.0 support integration into virtually any industrial control network.
- User-Friendly Interface: Intuitive LCD display and EnerVista 469 Setup software simplify commissioning and diagnostics.
Industry & Equipment Applications
- Oil & Gas: Pipeline compressors, wellhead pumps, gas injection motors
- Mining: Conveyor drives, crushers, ball mills, slurry pumps
- Water & Wastewater: High-power centrifugal pumps, aerators, blowers
- Pulp & Paper: Refiners, chippers, large fan drives
- Power Generation: Auxiliary motor protection in power plants
- Heavy Manufacturing: Extruders, presses, large HVAC systems
- Marine & Offshore: Critical motor protection in harsh environments
System Integration & Compatible Parts
The GE 469-P5-HI-A20 is designed to integrate seamlessly within GE Multilin protection ecosystems and broader industrial control architectures. Compatible and related components include:
- GE Multilin 469 series accessories: test plugs, communication cables, RTD modules
- GE EnerVista 469 Setup & Monitoring Software
- GE SR750 / SR760 Feeder Protection Relays (upstream protection coordination)
- Modbus RTU / DNP3.0 compatible PLCs and DCS platforms (Siemens, ABB, Rockwell, Honeywell)
- Current transformers (CTs) rated for HI input specifications
- RTD sensors (Pt100) for winding and bearing temperature monitoring
Our Quality Assurance Process
At Konmask.com, every GE Multilin relay we supply undergoes a rigorous quality verification process before shipment:
- Authenticity Verification: All units are sourced from authorized channels and verified against GE serial number databases where applicable.
- Visual & Physical Inspection: Enclosure integrity, terminal condition, label legibility, and connector completeness are checked.
- Functional Pre-check: Power-on test to confirm display operation and self-diagnostic pass.
- Secure Packaging: Anti-static packaging with shock-absorbing materials to protect sensitive electronics during international shipping.
- Documentation: Original manuals, calibration certificates, and test reports provided where available.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our technical team will confirm availability, lead time, and issue a formal quotation within 24 hours.
- Upon order confirmation, we arrange secure packaging and international shipping with full tracking.
- Post-delivery technical support is available for commissioning assistance.
Why Choose Konmask.com?
- Industrial Automation Specialists: Focused exclusively on PLC, DCS, relay, and automation hardware — we speak your engineering language.
- Global B2B Supply: Serving engineering firms, EPCs, OEMs, and MRO buyers across 50+ countries.
- Fast Inquiry Response: Dedicated sales engineers respond to RFQs within 24 business hours.
- Competitive Pricing: Direct sourcing relationships enable cost-effective pricing for both single units and bulk orders.
- Reliable Logistics: Partnerships with DHL, FedEx, and UPS for secure, trackable international delivery.
- Technical Expertise: Our team can assist with cross-referencing, compatibility verification, and application guidance.
Frequently Asked Questions
- Q: What does the “HI” designation mean in 469-P5-HI-A20?
- A: “HI” stands for High-Interrupting current input range. This configuration is designed for motors where fault currents can be very high, ensuring the relay measures accurately without CT saturation issues.
- Q: What is the “A20” suffix in the model number?
- A: “A20” indicates the relay includes an analog output module, allowing it to transmit real-time metering data (such as current or thermal capacity) as a 4–20 mA or 0–20 mA signal to external SCADA or DCS systems.
- Q: Is the GE 469-P5-HI-A20 compatible with Modbus RTU?
- A: Yes. The 469 series supports RS-485 Modbus RTU communication, making it compatible with most modern PLC and DCS platforms. DNP3.0 is also supported.
- Q: Can this relay protect both induction and synchronous motors?
- A: The GE Multilin 469 is primarily designed for induction motor protection. For synchronous motor applications, please consult our technical team for the appropriate relay selection.
- Q: Do you offer warranty on the GE 469-P5-HI-A20?
- A: Yes. We offer a standard warranty on all units supplied. Warranty terms are confirmed at the time of quotation. Please contact us for details.
- Q: What is the lead time for this product?
- A: Lead time varies based on current stock levels. Please submit an inquiry and our team will confirm availability and estimated delivery within 24 hours.
