GE DS200TBQCC1AAA PC Board | Replacement, Equivalent & Selection Guide
The GE DS200TBQCC1AAA is a printed circuit board (PC Board) designed for use within General Electric’s Mark VI Turbine Control System. Engineered to exacting industrial standards, this board serves as a critical interface and signal-processing component in gas and steam turbine control architectures. Procurement engineers sourcing this part will find complete replacement guidance, equivalent model cross-references, and verified sourcing information below.
Technical Specifications
| Parameter | Detail |
|---|---|
| Part Number | DS200TBQCC1AAA |
| Manufacturer | General Electric (GE) |
| Series / Platform | Mark VI Turbine Control System |
| Component Type | PC Board (Printed Circuit Board) |
| SKU | DS200TBQCC1AAA |
| Weight | 320 g (approx.) |
| Condition Available | New, Refurbished, Tested & Repaired |
| Compliance | RoHS-compatible; CE-marked equivalent available on request |
| Lead Time | In-stock units ship within 3–5 business days; sourced units 7–21 days |
Note: Full datasheet and firmware revision details available upon request. Contact [email protected].
Compatible Replacement & Equivalent Models
When the original DS200TBQCC1AAA is unavailable or cost-prohibitive, the following models may serve as functional equivalents or drop-in replacements depending on your system revision. Always verify firmware and hardware revision compatibility before installation.
| Model Number | Compatibility Level | Notes |
|---|---|---|
| DS200TBQCC1AAB | Direct Replacement | Revision B — confirm Mark VI firmware version |
| DS200TBQCC1BAA | Functional Equivalent | Minor BOM revision; same form/fit/function |
| DS200TBQCC2AAA | Upgraded Equivalent | Enhanced signal conditioning; backward compatible |
| DS200TBQCG1AAA | Cross-Reference | Different suffix — verify connector pinout before swap |
| IS200TBQCC1AAA | IS200 Series Equivalent | Mark VIe platform; confirm system architecture |
⚠ Engineering Note: Suffix characters (e.g., AAA vs. AAB) denote hardware revision levels. Always cross-reference with your Mark VI system BOM and GE service documentation before substitution.
Why Choose the Original Model
- Guaranteed Compatibility: The DS200TBQCC1AAA is the OEM-specified part for your Mark VI system — zero integration risk.
- Validated Firmware Pairing: Matched to specific Mark VI firmware revisions, eliminating calibration drift or communication faults.
- Regulatory Compliance: Meets GE’s internal quality standards for turbine safety-critical applications.
- Reduced Commissioning Time: Plug-and-play replacement with no re-parameterization required in most installations.
- Long-Term Support: Konmask maintains stock of legacy GE boards to support extended plant lifecycles beyond OEM availability windows.
Typical Applications
- Gas turbine control panels (Frame 5, Frame 6, Frame 7, Frame 9 series)
- Steam turbine governor and protection systems
- Combined-cycle power plant (CCPP) control rooms
- Compressor station automation and surge control
- Offshore platform turbine management systems
- Industrial co-generation facilities
- Refinery and petrochemical plant rotating equipment control
System Compatibility
| System | Compatible | Remarks |
|---|---|---|
| GE Mark VI | ✅ Primary | OEM-specified application |
| GE Mark VIe | ⚠ Conditional | Verify IS200 series cross-reference |
| GE Mark V | ❌ Not Compatible | Different backplane architecture |
| GE Mark IV | ❌ Not Compatible | Legacy platform — different form factor |
| Third-Party DCS | ❌ Not Applicable | GE proprietary board — no cross-platform use |
Selection Guide
Use the following decision framework to select the correct part for your application:
- Identify your Mark VI system revision — check the system BOM or GE project documentation for the exact DS200 part number specified.
- Confirm the suffix revision (AAA, AAB, BAA, etc.) — each suffix may indicate a different PCB layout or component revision.
- Check firmware version — some board revisions are locked to specific Mark VI firmware builds. Request the firmware compatibility matrix from Konmask.
- Assess condition requirements — for critical turbine applications, specify New or Fully Tested Refurbished. For non-critical backup spares, Tested & Repaired may be acceptable.
- Evaluate lead time vs. downtime cost — in-stock units ship within 3–5 days. For planned maintenance, order 2–4 weeks in advance to allow for incoming inspection.
📧 Not sure which revision you need? Send your system BOM or nameplate photo to [email protected] and our engineers will confirm the correct part within 24 hours.
Quality Assurance & Sourcing
- Source Traceability: All units are sourced from verified OEM channels, authorized distributors, or decommissioned plant inventories with full chain-of-custody documentation.
- Incoming Inspection: Every board undergoes visual inspection, component-level verification, and functional bench testing prior to dispatch.
- Anti-Counterfeit Measures: IC date codes, PCB silkscreen markings, and GE part labels are verified against known-good reference units.
- Warranty: 12-month warranty on all tested units. Extended warranty available on request.
- Packaging: ESD-safe anti-static bags, foam-lined cartons, and climate-controlled storage for long-term inventory.
How to Order
- Add to Cart directly on this page, or
- Request a Quote — email [email protected] with your required quantity, condition preference, and delivery timeline.
- Provide System Details — include your Mark VI system serial number or BOM reference for engineering verification.
- Confirm Lead Time & Payment — we accept T/T wire transfer, PayPal, and major credit cards. Pro-forma invoice issued within 2 business hours.
- Receive & Inspect — all shipments include a test report and packing list. DHL / FedEx / UPS express available worldwide.
📞 Phone / WhatsApp: +0086 19859288691
📧 Email: [email protected]
Replacement & Compatibility FAQ
Q: Can DS200TBQCC1AAA be used as a direct replacement for DS200TBQCC1AAB?
A: In most cases, yes — the AAB suffix is a minor hardware revision. However, confirm with your GE system documentation or contact us for a compatibility check before installation.
Q: Is a refurbished DS200TBQCC1AAA reliable for turbine control?
A: Yes, provided it has been fully tested and certified. Konmask’s refurbished units undergo the same functional test protocol as new units and carry a 12-month warranty.
Q: How do I identify a counterfeit DS200TBQCC1AAA?
A: Key indicators include mismatched IC date codes, incorrect PCB color or silkscreen font, and missing or poorly reproduced GE part labels. All Konmask units are verified against reference samples.
Q: What is the typical lead time for DS200TBQCC1AAA?
A: In-stock units ship within 3–5 business days. If sourcing is required, lead time is typically 7–21 business days depending on global inventory availability.
Q: Can you supply a certificate of conformance (CoC) or test report?
A: Yes. A functional test report is included with every shipment. CoC and third-party inspection reports are available upon request.
Q: Do you ship internationally?
A: Yes — we ship worldwide via DHL, FedEx, and UPS Express. Export documentation (commercial invoice, packing list, HS code declaration) is provided for all international orders.
