Motion Control Solution – GE Fanuc IC693DSM324 | Series 90-30
Where This Product Is Used
The GE Fanuc IC693DSM324 Motion Controller Module is engineered for demanding multi-axis motion control applications across a wide range of industrial environments. Engineers and system integrators specify this module in:
- CNC Machining Centers – Coordinated axis positioning for milling, turning, and drilling operations requiring precise interpolation.
- Packaging & Labeling Lines – High-speed servo coordination for pick-and-place, wrapping, and label-application stations.
- Automotive Assembly – Synchronized multi-axis motion for robotic welding fixtures, press-feed systems, and transfer lines.
- Printing & Converting – Register control and tension management across web-fed printing and slitting equipment.
- Material Handling & Conveyors – Gantry positioning, palletizing, and sortation systems requiring deterministic motion profiles.
- Semiconductor & Electronics Manufacturing – Sub-millimeter positioning for PCB handling, die bonding, and wafer transport.
Technical Specifications
| Part Number (SKU) | IC693DSM324 |
| Manufacturer | GE Fanuc Automation (General Electric) |
| Series | Series 90-30 PLC |
| Module Type | Motion Controller / DSM (Digital Servo Module) |
| Axes Supported | Up to 4 axes (servo or stepper) |
| Backplane Interface | Series 90-30 I/O bus compatible |
| Programming Environment | Logicmaster 90-30 / VersaPro / Proficy Machine Edition |
| Motion Modes | Point-to-point, velocity, torque, electronic gearing, cam profiling |
| Encoder Interface | Incremental quadrature encoder feedback |
| Power Consumption | Refer to GE Fanuc IC693DSM324 datasheet |
| Weight | 340 g (approx.) |
| Form Factor | Single-slot Series 90-30 module |
| Operating Temperature | 0 °C to 60 °C |
| Humidity | 5% to 95% non-condensing |
Why Engineers Specify This Model
- Native Series 90-30 Integration – Slots directly into any 90-30 baseplate; no external motion controller or gateway required, reducing panel footprint and wiring complexity.
- Multi-Axis Coordination – Supports up to 4 axes with electronic gearing and cam-profile capabilities, enabling complex synchronized motion without a dedicated CNC controller.
- Deterministic Scan-Cycle Execution – Motion tasks execute within the PLC scan cycle, ensuring tight synchronization between I/O events and axis commands.
- Broad Drive Compatibility – Works with GE Fanuc servo drives and is adaptable to third-party drives via analog ±10 V command output.
- Proven Field Reliability – Widely deployed since the 1990s; extensive installed base means readily available spare parts, experienced integrators, and well-documented troubleshooting resources.
- Upgrade Path – Compatible with Proficy Machine Edition for modernized programming while preserving existing 90-30 hardware investments.
Complete System Bill of Materials
A typical Series 90-30 motion control system built around the IC693DSM324 includes:
- IC693DSM324 – Motion Controller Module (this item)
- IC693CPU374 / IC693CPU364 – Series 90-30 CPU Module
- IC693CHS391 / IC693CHS397 – 5-slot or 10-slot Baseplate
- IC693PWR321 / IC693PWR330 – Power Supply Module
- IC693MDL655 / IC693MDL753 – Digital I/O Modules
- GE Fanuc Alpha Series or βi Series Servo Drive + Motor
- IC693CBL316 – Encoder Feedback Cable
- IC693ACC300 – Programming Cable / Adapter
Compliance & Industry Standards
- CE Marking – Designed to meet applicable EU directives for industrial machinery.
- UL Listed – Recognized for use in UL-listed control panels per UL 508A.
- RoHS – Original GE Fanuc production; consult datasheet for RoHS revision status.
- IEC 61131-3 – Programming conforms to IEC ladder logic and structured text standards via Proficy ME.
- NEMA / IP Rating – Module is designed for installation inside NEMA 12 or IP54-rated enclosures.
Quality Assurance & Sourcing
At Konmask.com, every IC693DSM324 unit undergoes a structured inspection process before shipment:
- Visual inspection for physical damage, corrosion, and counterfeit indicators.
- Functional power-on verification and backplane communication test.
- Firmware version documentation and label authenticity check.
- Anti-static packaging with humidity indicator card for safe transit.
- Traceability records maintained for each unit shipped.
We source from decommissioned OEM lines, certified distributors, and controlled surplus channels — never from unverified grey-market brokers.
How to Source This Part
- Add to Cart – Click Add to Cart above to purchase directly online.
- Request a Quote – For volume orders (5+ units) or project-based procurement, email support@konmask.com for a formal quotation.
- Expedited Sourcing – Need it urgently? Call or WhatsApp +0086 19859288691 for same-day availability confirmation.
- Cross-Reference Check – If you are unsure whether IC693DSM324 is the correct replacement, share your existing module part number and we will verify compatibility.
Application-Specific FAQ
Q: Can the IC693DSM324 control stepper motors as well as servo motors?
A: Yes. The DSM324 supports both servo (closed-loop with encoder feedback) and open-loop stepper motor configurations, making it versatile for mixed-drive machine architectures.
Q: Is this module compatible with the Series 90-70 backplane?
A: No. The IC693DSM324 is designed exclusively for the Series 90-30 backplane. For Series 90-70 applications, refer to the IC697DSM324 or equivalent DSM module.
Q: What programming software is required?
A: The module is programmed via GE Fanuc Proficy Machine Edition (ME) or the legacy Logicmaster 90-30 software. Proficy ME is the recommended current platform.
Q: Can I use this module for electronic cam (e-cam) applications?
A: Yes. The IC693DSM324 supports cam-profile motion, enabling electronic gearing and cam-following for applications such as flying shears, rotary cutters, and registration control.
Q: What is the lead time for this part?
A: Units in stock ship within 1–3 business days. Contact us for current inventory status and expedited shipping options.
Q: Do you provide a warranty?
A: Yes. All units sold by Konmask.com carry a 90-day functional warranty covering defects identified under normal operating conditions.
