GE IC694ALG221 16-Channel Analog Input Module | Replacement, Equivalent & Selection Guide
The GE IC694ALG221 is a 16-channel analog input module designed for the GE Series 90-30 PLC platform. It accepts voltage and current signals, making it a versatile choice for process monitoring in industrial automation systems. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: IC694ALG221
- Manufacturer: General Electric (GE Fanuc / Emerson)
- Series: Series 90-30 (GE 90-30)
- Module Type: Analog Input
- Number of Channels: 16
- Input Signal Types: Voltage (0–10 V, ±10 V) and Current (4–20 mA)
- Resolution: 12-bit
- Isolation: Non-isolated (channel-to-channel)
- Backplane Bus: Series 90-30 compatible
- Power Consumption: Supplied via backplane
- Operating Temperature: 0°C to 60°C
- Weight: Approx. 360 g
- Form Factor: Single-slot 90-30 module
- Status Indicators: LED diagnostics
Compatible Replacement & Equivalent Models
When the IC694ALG221 is discontinued, hard to source, or cost-prohibitive, the following models are commonly evaluated as replacements or equivalents. Always verify firmware compatibility and I/O mapping before substitution.
- IC694ALG220 – 8-channel analog input; same series, reduced channel count; suitable for smaller applications
- IC694ALG222 – 16-channel analog input with extended range options; direct functional equivalent in many configurations
- IC694ALG223 – Analog input/output combo module; consider when mixed I/O consolidation is needed
- IC693ALG221 – Series 90-30 predecessor; electrically similar but verify backplane slot compatibility
- Third-party equivalents – Modules from Horner, Spectrum Controls, or ProSoft may offer drop-in compatibility; confirm via vendor datasheets
Note: Konmask.com recommends using OEM-sourced modules for safety-critical applications. Contact our team for cross-reference verification.
Why Choose the Original IC694ALG221
- ✅ Guaranteed OEM compatibility with GE Series 90-30 CPU and backplane
- ✅ 16 channels in a single slot — maximizes rack density vs. dual 8-channel alternatives
- ✅ Dual signal type support (voltage + current) reduces need for signal conditioners
- ✅ Proven field reliability in process industries with decades of deployment history
- ✅ Native Proficy / Logicmaster programming support — no additional configuration overhead
Typical Applications
- Temperature and pressure monitoring in chemical and petrochemical plants
- Flow measurement in water treatment and utilities
- Level sensing in tank farms and storage facilities
- Multi-loop process control in food & beverage manufacturing
- HVAC and building automation systems using GE 90-30 infrastructure
- Machine tool feedback and position monitoring
System Compatibility
- Compatible CPUs: IC693CPU311, IC693CPU313, IC693CPU323, IC693CPU331, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU364, IC693CPU374 and all IC694 series CPUs
- Compatible Racks: IC693CHS391, IC693CHS392, IC693CHS393, IC694CHS392, IC694CHS398
- Programming Software: Proficy Machine Edition (ME), Logicmaster 90-30
- Communication: Via backplane; no dedicated fieldbus required
Selection Guide
Use the following criteria to determine whether the IC694ALG221 is the right module for your application:
- Channel count needed ≥ 9: IC694ALG221 (16-ch) preferred over IC694ALG220 (8-ch)
- Mixed voltage + current inputs: IC694ALG221 supports both; no need for separate modules
- Rack space constrained: Single-slot form factor is optimal
- Budget-sensitive replacement: Evaluate IC694ALG222 or certified refurbished IC694ALG221
- High-precision requirement (>12-bit): Consider IC694ALG391 (16-bit high-resolution analog input)
- Isolated channels required: IC694ALG221 is non-isolated; select IC694ALG391 or third-party isolated alternatives
Quality Assurance & Sourcing
All modules listed on Konmask.com are sourced through verified industrial supply channels. Each IC694ALG221 unit undergoes:
- Visual inspection for physical damage and label integrity
- Functional power-on verification where applicable
- Anti-static packaging and secure international shipping
- Traceability documentation available on request
We supply both new OEM stock and certified refurbished units. Lead times and pricing vary — contact us for current availability.
How to Order
- Confirm your GE 90-30 rack and CPU model for compatibility
- Specify quantity and preferred condition (new / refurbished)
- Add to cart or contact support@konmask.com for bulk pricing
- Provide your shipping destination for freight quote (DHL / FedEx / sea freight available)
- Payment via T/T, PayPal, or trade terms for qualified accounts
Replacement & Compatibility FAQ
Q: Can IC694ALG221 replace IC693ALG221?
A: In most cases yes, but verify the backplane slot keying and firmware version of your CPU. The IC694 series is the updated revision of IC693.
Q: Is IC694ALG221 compatible with GE PACSystems RX3i?
A: No. The IC694ALG221 is designed for the Series 90-30 backplane. PACSystems RX3i uses a different backplane (IC695 series modules).
Q: What is the difference between IC694ALG221 and IC694ALG222?
A: The ALG222 offers additional input range configurations. Both are 16-channel; the ALG222 is a functional upgrade in most applications.
Q: Can I use a third-party analog input module as a drop-in replacement?
A: Some third-party modules claim compatibility, but I/O mapping and diagnostic behavior may differ. Always test in a non-production environment first.
Q: Do you provide a warranty on IC694ALG221 units?
A: Yes. New units carry the standard manufacturer warranty. Refurbished units include a 90-day Konmask functional warranty. Contact us for details.
