GE HE693THM889 Thermocouple Input Module | Replacement, Equivalent & Selection Guide
The GE HE693THM889 is a multi-channel thermocouple input module designed for the GE Series 90-30 PLC platform. It provides direct thermocouple signal conditioning, cold-junction compensation, and high-resolution temperature measurement for demanding industrial process control applications. This page serves as a comprehensive selection, replacement, and compatibility reference for automation engineers and procurement teams.
Technical Specifications
- Part Number: HE693THM889
- Manufacturer: GE (General Electric) / GE Fanuc Automation
- Series: Series 90-30 (90-30 PLC I/O)
- Module Type: Thermocouple Analog Input
- Input Channels: 8 channels (isolated)
- Thermocouple Types Supported: J, K, T, E, R, S, B, C
- Resolution: 16-bit A/D conversion
- Cold Junction Compensation: Built-in automatic
- Input Range: Per thermocouple type (e.g., K-type: −200°C to +1372°C)
- Accuracy: ±1°C typical
- Backplane Bus: Series 90-30 standard I/O bus
- Power Consumption: 5 VDC from backplane
- Operating Temperature: 0°C to 60°C
- Dimensions: Standard Series 90-30 single-slot module
- Certifications: UL, CE
Compatible Replacement & Equivalent Models
When the HE693THM889 is discontinued, hard to source, or requires a cost-effective alternative, the following models offer functional equivalence or drop-in compatibility:
- IC693ALG221 – GE Fanuc Series 90-30 Analog Input Module (voltage/current; use with signal conditioner for TC)
- IC693ALG222 – GE Fanuc 16-channel Analog Input, compatible backplane
- HE693THM890 – Horner Electric equivalent thermocouple input for Series 90-30
- IC693ALG392 – GE Series 90-30 RTD/Thermocouple Input Module (direct replacement candidate)
- Spectrum Controls 1756-IT6I – For migration to Allen-Bradley ControlLogix platform (requires adapter)
- Siemens 6ES7331-7PF01-0AB0 – S7-300 thermocouple input (cross-platform migration reference)
Note: Always verify backplane slot compatibility, channel count, and thermocouple type support before substitution. Contact support@konmask.com for application-specific guidance.
Why Choose the Original HE693THM889
- Native Series 90-30 Integration: Plug-and-play with existing 90-30 racks — no gateway or signal converter required.
- Multi-Type TC Support: Handles J, K, T, E, R, S, B, C types in a single module, reducing spare-parts inventory.
- Built-in CJC: Eliminates external cold-junction compensation hardware, simplifying panel wiring.
- Proven Field Reliability: Widely deployed in power generation, chemical processing, and HVAC control systems.
- GE Proficy Compatibility: Fully supported by GE Proficy Machine Edition and Cimplicity SCADA.
Typical Applications
- Furnace and kiln temperature monitoring
- Boiler and steam system control
- Chemical reactor temperature loops
- HVAC air-handling unit control
- Food & beverage pasteurization processes
- Plastics extrusion barrel temperature zones
- Power plant turbine exhaust monitoring
System Compatibility
- PLC Platform: GE Series 90-30 (IC693 family)
- CPU Compatibility: IC693CPU311, IC693CPU313, IC693CPU323, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU374
- Rack Compatibility: IC693CHS391, IC693CHS392, IC693CHS393, IC693CHS398, IC693CHS399
- Programming Software: GE Proficy Machine Edition (Logic Developer – PLC)
- Communication: Via Series 90-30 backplane bus; supports Genius Bus, Ethernet NIU options
Selection Guide
Use the following criteria to confirm the HE693THM889 is the right module — or to identify the best alternative:
- Step 1 – Platform: Confirm your rack is Series 90-30 (IC693 family). For Series 90-70 or PACSystems RX3i, different modules apply.
- Step 2 – Channel Count: HE693THM889 provides 8 isolated TC channels. If you need 4 channels, consider IC693ALG221 with external conditioning.
- Step 3 – TC Type: Verify your thermocouple type (J/K/T/E/R/S/B/C) is in the supported list.
- Step 4 – Accuracy Requirement: ±1°C is standard. For tighter tolerances (<±0.5°C), evaluate RTD input modules instead.
- Step 5 – Budget vs. OEM: OEM modules ensure full firmware compatibility; third-party equivalents may offer cost savings with minor configuration differences.
- Step 6 – Migration Path: If upgrading to PACSystems RX3i, the IC695ALG608 is the recommended migration target.
Quality Assurance & Sourcing
- All modules sourced through Konmask.com are inspected for physical integrity and label authenticity prior to shipment.
- New, refurbished, and surplus stock options available — clearly labeled on each listing.
- Traceability documentation available upon request for MRO and OEM procurement teams.
- Secure anti-static packaging with ESD protection for all I/O modules.
- Lead time: typically 3–7 business days for in-stock items; expedited sourcing available.
How to Order
- Confirm part number: HE693THM889
- Specify quantity and required condition (new / refurbished / surplus)
- Add to cart or contact us directly for bulk pricing
- Email: support@konmask.com
- Phone/WhatsApp: +0086 19859288691
- We respond within 1 business day (Mon–Fri, UTC+8)
Replacement & Compatibility FAQ
Q: Is the HE693THM889 still in production?
A: GE Fanuc has transitioned many Series 90-30 modules to end-of-life. Konmask.com maintains surplus and refurbished stock to support legacy system maintenance.
Q: Can I use the HE693THM889 in a Series 90-70 rack?
A: No. The HE693THM889 is designed exclusively for Series 90-30 (IC693) backplanes. Series 90-70 uses the IC697 family.
Q: What is the closest drop-in replacement?
A: The IC693ALG392 (RTD/TC input) is the most commonly cited functional replacement within the same platform. Contact us to confirm compatibility with your specific CPU and rack revision.
Q: Do you provide a warranty?
A: Yes — 90-day warranty on all refurbished modules. New/surplus modules carry a 12-month warranty. Terms available on request.
Q: Can you help with cross-brand migration (e.g., to Siemens or Allen-Bradley)?
A: Yes. Our engineering team can provide migration mapping and equivalent module recommendations for major PLC platforms.
