Factory Automation & Process Control Solution – GE IC200MDL650 | VersaMax Series
Where This Product Is Used
The GE IC200MDL650 is a 16-point, 120VAC discrete input module engineered for demanding industrial environments. It is widely deployed in:
- Automotive assembly lines – reading limit switches, proximity sensors, and push-button stations on 120VAC plant power
- Food & beverage processing – monitoring conveyor position sensors, door interlocks, and level switches in washdown-adjacent panels
- Water & wastewater treatment – interfacing with float switches, pressure switches, and motor run-status contacts across distributed pump stations
- Packaging machinery – capturing high-speed discrete signals from photo-eyes and registration sensors tied to 120VAC field wiring
- HVAC & building automation – reading damper end-switches, flow-proving switches, and safety interlocks in commercial mechanical rooms
- Oil & gas upstream/midstream – monitoring valve position feedback and emergency shutdown (ESD) contact inputs in remote RTU panels
Technical Specifications
- Part Number: IC200MDL650
- Series: GE VersaMax Modular I/O
- Module Type: Discrete Input
- Number of Points: 16 inputs
- Input Voltage: 120VAC (85–132VAC operating range)
- Input Current: 6 mA typical per point at 120VAC
- ON-State Voltage: 74VAC minimum
- OFF-State Voltage: 20VAC maximum
- Input Filter Time: 10 ms (nominal)
- Isolation: 1500VAC optical isolation (field-to-backplane)
- Backplane Current Draw: 80 mA @ 5VDC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5–95% non-condensing
- Dimensions (H × W × D): 138 × 30 × 76 mm (approx.)
- Weight: 140 g
- Mounting: VersaMax I/O carrier / backplane
- Certifications: UL Listed, CE Marked, cUL
Why Engineers Specify This Model
- Native 120VAC compatibility – eliminates interposing relays or signal converters when interfacing with North American plant wiring standards
- High-density 16-point format – maximizes panel real estate in space-constrained enclosures
- Robust optical isolation – 1500VAC barrier protects the PLC backplane from field-side transients and ground loops
- Hot-swap capable carrier design – VersaMax architecture allows module replacement without full system shutdown in supported configurations
- Broad ecosystem compatibility – works with VersaMax Modular CPU (IC200CPUE05, IC200CPUE10), NIU (IC200BEM003), and all standard VersaMax carriers
- Long production history – proven reliability with extensive installed base across North American and global industrial sites
Complete System Bill of Materials
A typical VersaMax node using the IC200MDL650 includes:
- IC200MDL650 – 16-point 120VAC discrete input module (this item)
- IC200CHS002 – VersaMax 5-slot I/O carrier
- IC200PWR002 – VersaMax power supply, 120/240VAC input
- IC200CPUE05 or IC200BEM003 – CPU or Bus Interface Unit
- IC200ACC001 – Terminal block connector for field wiring
- IC200CBL001 – Expansion cable (for multi-rack configurations)
Contact support@konmask.com to source complete system BOM packages.
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- cUL (Canadian UL equivalent)
- RoHS compliant (verify lot-specific documentation upon request)
- IEC 61131-2 – Programmable Controllers, Equipment Requirements & Tests
Quality Assurance & Sourcing
Every IC200MDL650 unit shipped from Konmask.com undergoes:
- Visual inspection for physical damage, label integrity, and connector condition
- Functional power-on verification where test fixtures are available
- Traceability documentation – lot number, origin, and inspection record provided on request
- Anti-static packaging with humidity indicator card for long-distance shipping
We source from authorized distribution channels and verified surplus inventories. Counterfeit-risk screening is applied to all GE/Emerson-heritage parts.
How to Source This Part
- In-stock orders: Add to cart and check out directly — ships within 1–3 business days
- Bulk / project BOM: Email support@konmask.com with quantity and required delivery date
- Urgent / emergency replacement: Call or WhatsApp +0086 19859288691 for expedited handling
- Cross-reference / substitution: Contact us if you need a compatible alternative (e.g., IC200MDL640 for 24VDC inputs)
Application-Specific FAQ
Q: Can the IC200MDL650 read 240VAC signals?
A: No. The module is rated for 85–132VAC. For 240VAC field signals, use interposing relays to step down to 120VAC, or specify the IC200MDL660 (240VAC input module).
Q: Is this module compatible with the VersaMax Nano/Micro CPUs?
A: No. The IC200MDL650 requires a VersaMax Modular backplane/carrier. It is not compatible with the Nano (IC200NAL) or Micro (IC200UDR) standalone units.
Q: What is the maximum cable length from field device to module terminal?
A: GE recommends keeping field wiring under 300 m (1000 ft) for 120VAC discrete inputs to minimize voltage drop and noise pickup. Use shielded cable in high-EMI environments.
Q: Can I mix IC200MDL650 and DC input modules on the same carrier?
A: Yes. VersaMax carriers support mixed I/O module types in adjacent slots, provided each module’s power budget is within the carrier’s supply capacity.
Q: Do you provide a warranty?
A: Yes — 12-month warranty against defects in materials and workmanship. See our store policy page for full terms.
