GE IC200UDD104-BG – 28-Point DC Micro PLC Controller | VersaMax Micro Series
Engineering Background
The GE IC200UDD104-BG is a member of GE Automation & Controls’ VersaMax Micro family — a purpose-built line of compact programmable logic controllers engineered for cost-sensitive, space-constrained industrial applications. The VersaMax Micro platform was developed to bridge the gap between relay-based control and full-scale PLC systems, delivering deterministic scan performance and robust I/O handling in a DIN-rail-mountable form factor.
Product Positioning
The IC200UDD104-BG targets OEM machine builders, panel integrators, and plant engineers who require a reliable, field-proven micro PLC with native DC I/O, onboard serial communications, and compatibility with GE’s broader PACSystems ecosystem. It is a direct replacement candidate for aging relay logic panels and legacy micro-PLC installations across discrete manufacturing, material handling, and building automation sectors.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IC200UDD104-BG |
| Series / Platform | VersaMax Micro | GE Automation & Controls |
| Total I/O Points | 28 (14 DI + 14 DO) |
| Input Type | 24 VDC Discrete Input |
| Output Type | 24 VDC Discrete Output (Transistor / Source) |
| Supply Voltage | 24 VDC (±10%) |
| Program Memory | 10 KB (Ladder Logic) |
| Data Memory | 10 KB |
| Communications Port | RS-232 / RS-485 Serial (onboard) |
| Programming Software | VersaPro / Proficy Machine Edition |
| Scan Time | ~1 ms/K (typical) |
| Mounting | DIN Rail or Panel Mount |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Protection Rating | IP20 |
| Weight | ~300 g |
| Certifications | UL, CE, cUL |
| RoHS Compliance | Yes (-BG suffix) |
Proven Application Environments
- Discrete Manufacturing: Assembly line sequencing, conveyor control, and end-of-line testing stations
- Material Handling: Sortation systems, palletizers, and automated guided vehicle (AGV) interlocks
- Packaging Machinery: Fill-and-seal machines, labelers, and case erectors requiring compact footprint controllers
- Building Automation: HVAC control panels, pump station management, and access control interlocks
- Water & Wastewater: Lift station control, dosing pump sequencing, and remote monitoring panels
- OEM Machine Control: Standalone machine controllers where a full-rack PLC is cost-prohibitive
Engineering Advantages
- Compact Form Factor: Minimal panel real estate consumption — ideal for retrofit and space-constrained enclosures
- Native DC I/O: 24 VDC sourcing outputs eliminate the need for external relay modules in most DC load applications
- Onboard Serial Port: RS-232/RS-485 enables direct HMI connection, SCADA integration, and Modbus RTU communication without additional communication modules
- GE Ecosystem Compatibility: Fully programmable via Proficy Machine Edition, compatible with GE VersaMax expansion I/O modules
- RoHS-Compliant (-BG Suffix): Meets EU RoHS Directive requirements — suitable for export to European markets and environmentally regulated facilities
- Deterministic Scan Performance: ~1 ms/K scan time ensures reliable real-time control for high-speed discrete applications
System Architecture & Signal Flow
The IC200UDD104-BG operates as a standalone controller. The CPU, power supply, and I/O are integrated into a single housing. Signal flow is as follows:
- Power Input: 24 VDC supplied to the unit’s power terminals
- Digital Inputs (14 × 24 VDC): Field sensors, pushbuttons, and limit switches connect directly to the input terminals; the CPU reads input states each scan cycle
- CPU Execution: Ladder logic program executes deterministically; output coil states are resolved at end of each scan
- Digital Outputs (14 × 24 VDC Transistor): Output transistors switch field loads (solenoids, relays, indicators) based on resolved coil states
- Serial Port: Asynchronous serial communication for programming, HMI data exchange, or Modbus RTU master/slave operation
Sourcing & Quality Verification
- Origin: Sourced from authorized GE Automation distributors and verified surplus channels
- Inspection Protocol: Each unit undergoes visual inspection, label verification (part number, revision, date code), and functional power-on testing prior to shipment
- Packaging: Anti-static bag + foam-lined carton; original GE packaging preserved where available
- Warranty: 90-day operational warranty against defects in materials and workmanship
- Counterfeit Mitigation: All units verified against GE factory markings; units with suspect labels or anomalous date codes are quarantined and not listed
Procurement Process
- Confirm Compatibility: Verify your application’s I/O count, voltage requirements, and communication needs against the specifications above
- Request Quote / Place Order: Add to cart or contact support@konmask.com for volume pricing and lead time confirmation
- Order Confirmation: You will receive an order confirmation with estimated dispatch date within 1 business day
- Inspection & Dispatch: Unit is inspected, tested, and packed; tracking number provided upon shipment
- Delivery: Standard international shipping 5–15 business days; expedited options available on request
- After-Sales Support: Technical support available via email and phone for installation, programming, and integration queries
Technical FAQ
Q: Is the IC200UDD104-BG compatible with Proficy Machine Edition (PME)?
A: Yes. The VersaMax Micro series is fully supported by GE Proficy Machine Edition. Use the VersaMax Micro target type when creating your project.
Q: Can I expand the I/O beyond the onboard 28 points?
A: The IC200UDD104-BG supports connection of VersaMax Micro expansion modules (e.g., IC200MDL series) via the expansion port, allowing additional discrete and analog I/O.
Q: What is the difference between the standard IC200UDD104 and the -BG suffix variant?
A: The -BG suffix denotes RoHS compliance (restriction of hazardous substances). Functionally, the units are identical; the -BG variant uses RoHS-compliant materials in its construction.
Q: Does this unit support Modbus RTU?
A: Yes. The onboard RS-485 port can be configured for Modbus RTU master or slave operation using the serial communication function blocks in Proficy Machine Edition.
Q: What programming cable is required?
A: A standard RS-232 serial cable (or USB-to-RS232 adapter) connecting to the unit’s programming port is required. GE IC690ACC901 or equivalent is recommended.
Q: Is this unit new or refurbished?
A: Units are clearly described in the listing as new, surplus-new, or refurbished. All units are tested and verified before shipment. Contact us if you require a specific condition grade.
