Industrial Coprocessor Solution – GE IC693PCM301 | Series 90-30
Where This Product Is Used
The GE IC693PCM301 Programmable Coprocessor Module is deployed across demanding industrial environments where the main PLC CPU requires supplemental processing power. Typical application scenarios include:
- Automotive Assembly Lines – Offloads complex motion sequencing and quality inspection algorithms from the primary CPU, enabling deterministic cycle times on high-speed transfer lines.
- Chemical & Petrochemical Plants – Executes custom PID loop calculations and safety interlock logic in parallel with the main controller, reducing scan-time bottlenecks.
- Food & Beverage Processing – Handles real-time recipe management and batch control routines while the host CPU manages HMI communications and historian data logging.
- Power Generation & Utilities – Runs turbine governor algorithms and load-shedding logic that demand sub-millisecond response independent of the main scan cycle.
- Packaging & Material Handling – Coordinates multi-axis servo positioning math and conveyor synchronization without burdening the primary Series 90-30 CPU.
- Water & Wastewater Treatment – Executes advanced process calculations (flow totalization, chemical dosing curves) alongside standard ladder logic.
Technical Specifications
| Part Number | IC693PCM301 |
| Manufacturer | GE Automation (GE Fanuc) |
| Series | Series 90-30 |
| Module Type | Programmable Coprocessor Module (PCM) |
| Processor | Intel 80C188 (10 MHz) |
| User RAM | 512 KB (expandable) |
| Programming Language | C / Assembly (user-loadable firmware) |
| Communication Interface | Backplane bus (Series 90-30 rack) |
| Serial Ports | 2 × RS-232 / RS-422 / RS-485 configurable |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Consumption | 1.5 W (typical) |
| Weight | 1,470 g (module + packaging) |
| Form Factor | Single-slot Series 90-30 rack module |
| Firmware | User-downloadable via serial port |
Why Engineers Specify This Model
- True Parallel Processing – Runs independently of the host CPU scan cycle, eliminating coprocessor tasks from the main program’s time budget.
- Dual Serial Ports – Enables simultaneous communication with barcode scanners, weighing systems, vision cameras, or third-party devices without consuming CPU communication slots.
- C-Language Programmability – Allows engineers to implement proprietary algorithms, custom protocols, and math-intensive routines impossible in standard ladder logic.
- Shared Memory Architecture – Exchanges data with the host CPU via a high-speed backplane shared memory window, ensuring low-latency data transfer.
- Drop-in Compatibility – Fits any standard Series 90-30 rack slot; no special rack or power supply required.
- Proven Field Reliability – Widely deployed since the 1990s with an extensive installed base, ensuring long-term spare parts availability and community support.
Complete System Bill of Materials
For a fully operational Series 90-30 system incorporating the IC693PCM301, engineers typically specify:
- IC693PCM301 – Programmable Coprocessor Module (this item)
- IC693CPU374 / IC693CPU364 – Series 90-30 CPU Module
- IC693PWR321 / IC693PWR330 – Series 90-30 Power Supply
- IC693CHS391 / IC693CHS397 – Series 90-30 Baseplate / Rack
- IC693MDL645 / IC693MDL654 – Digital I/O Modules
- IC693ALG220 / IC693ALG390 – Analog I/O Modules
- IC693CMM321 – Ethernet Communications Module (optional)
- IC693ACC300 – Memory Backup Battery (recommended)
Compliance & Industry Standards
- UL Listed (UL 508 Industrial Control Equipment)
- CE Marked – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- IEC 61131-2 Programmable Controllers – Hardware Requirements
- RoHS Compliant (where applicable to production date)
- ATEX / Class I Div 2 suitability – verify with project-specific documentation
Quality Assurance & Sourcing
Every IC693PCM301 unit offered through Konmask.com undergoes a structured inspection process:
- Visual Inspection – Board-level examination for corrosion, damaged traces, and component integrity.
- Functional Verification – Power-on test confirming module initialization and backplane communication.
- Firmware Check – Verification of installed firmware revision against GE release documentation.
- Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability – Serial number and inspection records retained for each unit.
How to Source This Part
To place an order or request a quotation for the GE IC693PCM301:
- Online: Add to cart directly on this page for immediate checkout.
- Email RFQ: support@konmask.com – include quantity, required delivery date, and project details.
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; sourced units typically 5–10 business days.
- Export: We support international shipping with full commercial invoice and packing list documentation.
Application-Specific FAQ
Q: Can the IC693PCM301 replace a failed IC693PCM300?
A: Yes. The PCM301 is the direct successor to the PCM300 and is backward-compatible with existing rack slots and backplane connections. Firmware may need to be updated.
Q: What programming environment is used to develop PCM301 applications?
A: GE provides a C-language SDK (PCM Development Kit). Applications are compiled and downloaded to the module via its RS-232 serial port using a standard terminal or GE’s download utility.
Q: How does the PCM301 share data with the host CPU?
A: Through a shared memory window on the Series 90-30 backplane. The host CPU reads/writes data registers mapped to the PCM’s memory space using standard ladder logic instructions.
Q: Is the IC693PCM301 still manufactured by GE?
A: This model is in the mature/legacy phase. Konmask.com specializes in sourcing tested surplus and refurbished units to support ongoing maintenance of installed Series 90-30 systems.
Q: What warranty is provided?
A: All units carry a 90-day functional warranty. Extended warranty options are available upon request.
