GE IC694MDL753B 16-Point 120VAC Output Module | Replacement, Equivalent & Selection Guide
The GE IC694MDL753B is a 16-point, 120VAC discrete output module designed for the GE Series 90-30 PLC platform. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: IC694MDL753B
- Manufacturer: GE (General Electric / GE Automation & Controls)
- Series: Series 90-30 (90-30 PLC)
- Module Type: Discrete Output Module
- Output Points: 16
- Output Voltage: 120VAC
- Output Current: 0.5A per point (8A per module)
- Isolation: Optical isolation between field and logic
- Output Type: Triac (solid-state)
- Backplane Compatibility: Series 90-30 CPU and expansion racks
- Operating Temperature: 0°C to 60°C
- Dimensions: Standard Series 90-30 single-slot form factor
- Revision: B
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the IC694MDL753B. Always verify electrical and firmware compatibility before substitution:
- IC694MDL753 – Earlier revision; functionally identical in most applications
- IC694MDL754 – 32-point 120VAC output; use when higher point density is required
- IC694MDL740 – 8-point 120VAC output; suitable for smaller I/O requirements
- IC694MDL742 – 8-point 240VAC output; for higher voltage AC loads
- IC694MDL752 – 16-point 24VDC output; direct DC equivalent for voltage migration
- Horner HE693MDL753 – Third-party compatible module for Series 90-30 racks
Note: Third-party equivalents may require configuration validation. Contact Konmask for sourcing support.
Why Choose the Original IC694MDL753B
- ✅ OEM-certified compatibility with all Series 90-30 CPU and rack configurations
- ✅ Proven field reliability in continuous industrial duty cycles
- ✅ Firmware-transparent – no re-programming required when replacing same-revision modules
- ✅ Optical isolation protects PLC logic from field-side voltage transients
- ✅ Triac output enables zero-crossing switching for reduced electrical noise
Typical Applications
- Motor starter and contactor control in manufacturing lines
- Conveyor and material handling systems
- HVAC control panels and building automation
- Pump and valve sequencing in water/wastewater treatment
- Packaging machinery and assembly automation
- Food & beverage processing equipment
System Compatibility
- PLC Platform: GE Series 90-30 (90-30)
- Compatible CPUs: IC693CPU311, IC693CPU313, IC693CPU323, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU364, IC693CPU374
- Compatible Racks: IC693CHS391, IC693CHS392, IC693CHS393, IC694CHS392, IC694CHS398
- Programming Software: Proficy Machine Edition (PME) 8.0+, VersaPro
- Bus Interface: Series 90-30 backplane bus (not compatible with Series 90-70 or PACSystems RX3i without adapter)
Selection Guide
Use the following criteria to confirm the IC694MDL753B is the right module for your application:
- Output voltage required: 120VAC → IC694MDL753B ✅ | 240VAC → IC694MDL742 | 24VDC → IC694MDL752
- Point count needed: 16 points → IC694MDL753B ✅ | 8 points → IC694MDL740 | 32 points → IC694MDL754
- Load type: Resistive or inductive AC loads → Triac output (IC694MDL753B) ✅
- Rack slot availability: Single slot required → IC694MDL753B ✅
- Revision sensitivity: If existing system uses Rev B, specify IC694MDL753B to ensure drop-in compatibility
Quality Assurance & Sourcing
- All units sourced by Konmask.com are inspected for physical integrity and label authenticity
- New, refurbished, and tested-surplus conditions available — clearly labeled at time of quotation
- Traceability documentation available upon request for MRO and OEM procurement teams
- Export compliance: ECCN EAR99 (verify end-use requirements for your jurisdiction)
How to Order
- Confirm part number: IC694MDL753B
- Specify required condition: New / Refurbished / Tested Surplus
- Provide quantity and delivery timeline
- Contact us via the form below or email support@konmask.com
- Receive quotation within 1 business day
Replacement & Compatibility FAQ
Q: Can IC694MDL753 (no suffix) replace IC694MDL753B?
A: In most cases yes — the B revision is a minor hardware update. Verify with your system integrator if firmware version matters.
Q: Is IC694MDL753B compatible with PACSystems RX3i?
A: No. The RX3i uses a different backplane bus. You would need IC694MDL753B in an IC694 expansion rack connected via the RX3i’s Series 90-30 compatibility module.
Q: What is the lead time for IC694MDL753B?
A: Typically 1–5 business days for in-stock units. Contact Konmask for current availability.
Q: Does Konmask provide a warranty?
A: Yes — all units carry a minimum 90-day functional warranty. Extended warranty available on request.
Q: Can I return a module if it’s incompatible?
A: Yes, subject to our standard return policy. Contact support within 30 days of receipt.
