GE IC695ALG508 Isolated RTD Input Module | PACSystems RX3i

Genuine GE IC695ALG508 Isolated RTD Input Module | PACSystems RX3i – Verified Source

When a temperature measurement channel fails silently in a critical process loop — a furnace, a reactor, a turbine cooling circuit — the consequences range from product loss to catastrophic equipment failure. The GE IC695ALG508 eliminates that risk by providing eight fully isolated RTD input channels within the PACSystems RX3i backplane, ensuring that a fault on one channel never propagates to adjacent signals or the control bus. Without this module, engineers are forced to rely on external signal conditioners, multiplexers, and additional wiring — adding cost, latency, and failure points to every measurement loop.

The IC695ALG508 occupies a well-established position in GE’s PACSystems RX3i analog portfolio as the dedicated isolated RTD solution. While the IC695ALG600 series handles voltage and current inputs, the IC695ALG508 is purpose-engineered for resistance temperature detector signals — supporting Pt100, Pt1000, Ni120, and other standard RTD types. Its channel-to-channel isolation architecture makes it the preferred choice for installations where ground loops, common-mode noise, or intrinsic safety barriers are engineering constraints. Globally, this module is deployed across power generation, oil & gas, chemical processing, and heavy manufacturing facilities running GE’s PACSystems RX3i platform.

Technical Specifications

• Part Number: IC695ALG508
• Manufacturer: GE (GE Intelligent Platforms / Emerson)
• Series: PACSystems RX3i
• Module Type: Isolated RTD Analog Input
• Input Channels: 8 (fully isolated, channel-to-channel)
• Supported RTD Types: Pt100, Pt200, Pt500, Pt1000, Ni120, Cu10 (configuration-dependent)
• Input Isolation: Channel-to-channel and channel-to-backplane
• Backplane Interface: RX3i Universal Backplane (IC695CHS007, IC695CHS012, IC695CHS016)
• Power Consumption: Refer to GE PACSystems RX3i System Manual (GFK-2314)
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5% to 95% non-condensing
• Certifications: CE, UL Listed, cUL
• Form Factor: Single-slot RX3i module
• Weight: Approx. 220 g

Note: All specifications are sourced from GE published documentation. Konmask.com does not fabricate or modify manufacturer specifications.

Our 4-Step Quality Verification Process

Every IC695ALG508 unit processed through Konmask.com undergoes a structured verification protocol before shipment:

• Step 1 — Visual Inspection: Physical examination of housing, connector pins, label integrity, and firmware revision markings against GE reference standards.
• Step 2 — Functional Bench Test: Where applicable, modules are powered and channel response is verified using calibrated RTD simulators to confirm analog input accuracy.
• Step 3 — Documentation Cross-Check: Serial number, date code, and revision level are cross-referenced against known GE production records and supplier documentation.
• Step 4 — Packaging & ESD Protection: Units are repackaged in anti-static bags with desiccant and foam cushioning, labeled with inspection pass date and technician ID before dispatch.

Key Features & Benefits

• Full Channel Isolation: Eliminates ground loops and common-mode interference — critical in industrial environments with long cable runs or mixed grounding systems.
• Multi-RTD Type Support: Configurable per channel for Pt100, Pt1000, Ni120, and other standard types — reducing the need for multiple module SKUs.
• Native RX3i Integration: Plug-and-play compatibility with PACSystems RX3i backplanes; no external signal conditioning required.
• High-Resolution Measurement: Delivers precise temperature data suitable for closed-loop PID control and process monitoring applications.
• Compact Single-Slot Design: Maximizes backplane density in space-constrained control cabinets.
• Diagnostic Reporting: Supports open-wire detection and out-of-range fault reporting via the RX3i CPU diagnostic registers.

Typical Applications

• Power generation — turbine inlet and exhaust temperature monitoring
• Oil & gas — wellhead and pipeline temperature measurement loops
• Chemical processing — reactor temperature control with PID feedback
• Pharmaceutical manufacturing — validated temperature logging for GMP compliance
• Steel and metals — furnace zone temperature control
• Water treatment — process temperature monitoring in SCADA-integrated systems
• Food & beverage — pasteurization and CIP temperature verification

Compatible System Components

• CPUs: IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE330, IC695CPE400
• Backplanes: IC695CHS007 (7-slot), IC695CHS012 (12-slot), IC695CHS016 (16-slot)
• Power Supplies: IC695PSA040, IC695PSA140, IC695PSD040
• Related Analog Modules: IC695ALG600 (voltage/current input), IC695ALG704 (analog output), IC695ALG808 (8-ch current/voltage input)
• Communications: IC695ETM001 (Ethernet), IC695PBM300 (PROFIBUS Master)

Global Sourcing & Shipping Capabilities

Konmask.com maintains sourcing relationships across authorized distributor networks and certified secondary market channels in Asia, Europe, and North America. We ship the IC695ALG508 to customers in over 60 countries, with the following logistics capabilities:

• Standard export packaging compliant with ISTA 2A transit testing guidelines
• DHL Express, FedEx International Priority, and UPS Worldwide available
• Commercial invoice, packing list, and certificate of origin provided for customs clearance
• Lead time: typically 3–7 business days for in-stock units; 2–4 weeks for sourced orders
• Minimum order quantity: 1 unit

Certifications & Compliance Statement

• CE Marking: Compliant with EU EMC Directive and Low Voltage Directive as declared by GE
• UL / cUL Listed: Recognized under applicable UL standards for industrial control equipment
• RoHS: Refer to GE product compliance documentation for RoHS status by revision
• Export Control: This product may be subject to export licensing requirements. Buyers are responsible for compliance with applicable export regulations in their jurisdiction.
