Industrial Bus Expansion Solution – GE IC697BEM742 | Series 90-70
The GE IC697BEM742 is a 5VDC Bus Expansion Module designed for the GE Series 90-70 Programmable Logic Controller platform. It enables engineers to extend the I/O rack capacity of existing control systems — a critical capability in large-scale industrial automation environments where scalability, uptime, and signal integrity are non-negotiable.
Where This Product Is Used
The IC697BEM742 is deployed across a wide range of heavy-industry and process-control environments where the Series 90-70 PLC platform manages distributed I/O across multiple expansion racks:
- Power Generation Plants — Turbine control, boiler management, and auxiliary system monitoring requiring high-density I/O across multiple racks.
- Oil & Gas Processing Facilities — Pipeline SCADA systems and compressor station automation where rack expansion supports hundreds of field I/O points.
- Automotive Manufacturing Lines — Body-in-white welding cells and paint shop conveyors using Series 90-70 as the backbone PLC with multi-rack I/O configurations.
- Water & Wastewater Treatment — Pump station control and chemical dosing systems requiring reliable 5VDC bus communication between CPU and remote I/O racks.
- Pulp & Paper Mills — Continuous process lines where the BEM742 bridges the CPU rack to expansion racks handling motor drives, valve actuators, and sensor arrays.
- Chemical & Petrochemical Plants — Batch reactor control and distillation column automation with safety-critical I/O expansion requirements.
- Steel & Metals Processing — Rolling mill and furnace control systems with large I/O counts distributed across multiple physical rack locations.
Technical Specifications
| Part Number | IC697BEM742 |
| Manufacturer | GE (General Electric Automation / GE Vernova) |
| Series | Series 90-70 PLC |
| Module Type | Bus Expansion Module (BEM) |
| Operating Voltage | 5VDC |
| Function | Extends Series 90-70 backplane bus to remote expansion racks |
| Communication | Series 90-70 proprietary backplane bus protocol |
| Compatible Rack | IC697CHS750, IC697CHS782, IC697CHS790 and compatible Series 90-70 racks |
| Weight | 240 g |
| Form Factor | Single-slot Series 90-70 module |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% non-condensing |
| Mounting | Series 90-70 backplane slot |
Why Engineers Specify This Model
When a Series 90-70 system needs to grow beyond the base rack’s slot capacity, the IC697BEM742 is the OEM-specified solution. Engineers choose this module for the following reasons:
- Seamless Rack Expansion — Maintains full backplane bus integrity when connecting the CPU rack to one or more expansion racks, preserving scan-cycle determinism.
- 5VDC Bus Stability — Provides clean, regulated 5VDC bus signaling across the expansion link, minimizing noise-induced faults in high-EMI industrial environments.
- Drop-In Compatibility — Slots directly into any Series 90-70 rack without firmware changes or software reconfiguration in most standard applications.
- Long Service Life — Solid-state design with no moving parts; proven reliability in 24/7 continuous-process environments over multi-decade operational lifespans.
- Legacy System Support — Critical for maintaining and expanding installed Series 90-70 systems where platform migration is not yet feasible or cost-justified.
- Reduced Downtime Risk — Having a verified spare on-hand eliminates extended lead-time exposure during unplanned failures in production-critical systems.
Complete System Bill of Materials
The IC697BEM742 operates as part of a coordinated Series 90-70 rack expansion architecture. Typical BOM components include:
- CPU Module — IC697CPX935, IC697CPX928, or IC697CPU772 (Series 90-70 CPU)
- Base/CPU Rack — IC697CHS750 (5-slot) or IC697CHS790 (9-slot)
- Bus Expansion Module (Transmitter) — IC697BEM742 (this module, installed in CPU rack)
- Bus Receiver Module — IC697BEM741 (installed in expansion rack)
- Expansion Rack — IC697CHS782 or IC697CHS790
- Power Supply — IC697PWR711 or IC697PWR724 (per rack)
- I/O Modules — IC697MDL340 (discrete input), IC697MDL341 (discrete output), IC697ALG320 (analog input), IC697ALG321 (analog output)
- Bus Expansion Cable — IC697CBL700 series (length-dependent)
Contact us to source any of the above components. We maintain cross-referenced inventory across the full Series 90-70 catalog.
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage Directive and EMC Directive (original OEM certification)
- UL Listed — UL 508 Industrial Control Equipment (original OEM listing)
- RoHS — Original GE production units; RoHS status varies by manufacturing date — confirm with our team if required for your project
- IEC 61131-2 — Programmable controllers hardware requirements (Series 90-70 platform compliance)
- ATEX / IECEx — Not rated for hazardous area installation; use appropriate barriers or safe-area mounting
Quality Assurance & Sourcing
At Konmask.com, every module undergoes a structured verification process before shipment:
- Visual Inspection — Board-level examination for physical damage, corrosion, counterfeit indicators, and label authenticity.
- Functional Bench Test — Power-on verification and bus communication test where test equipment is available.
- Provenance Review — Documentation of sourcing channel; preference for factory-sealed, OEM-surplus, or single-owner decommissioned units.
- Packaging & ESD Protection — Anti-static bagging, foam cushioning, and double-wall carton for international shipment.
We source from verified industrial surplus channels, authorized distributors, and decommissioned plant inventories — never from unverified grey-market aggregators.
How to Source This Part
- Confirm Part Number — Verify IC697BEM742 against your existing rack label or GE system documentation.
- Request a Quote — Email support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Receive Availability & Pricing — We respond within 1 business day with stock status, unit price, and lead time.
- Place Order & Confirm Shipping — Secure checkout via this store or proforma invoice for B2B wire transfer. DHL / FedEx / UPS international express available.
- Receive & Install — Module ships with inspection report. Installation follows GE Series 90-70 Hardware Reference Manual (GFK-0262).
Application-Specific FAQ
Q: Can the IC697BEM742 be used in both the CPU rack and the expansion rack?
A: No. The IC697BEM742 is the bus transmitter module and is installed in the CPU (master) rack. The IC697BEM741 is the corresponding receiver module installed in the expansion rack. Both are required for a complete expansion link.
Q: How many expansion racks can one IC697BEM742 support?
A: Each IC697BEM742 supports one expansion rack link. For multiple expansion racks, additional BEM742/BEM741 pairs are required — one pair per expansion rack.
Q: Is this module compatible with the Series 90-30 or PACSystems platform?
A: No. The IC697BEM742 is exclusively compatible with the GE Series 90-70 platform. It is not interchangeable with Series 90-30 (IC693 prefix) or PACSystems RX7i/RX3i modules.
Q: What is the maximum cable length between the CPU rack and expansion rack?
A: GE specifies a maximum of 15 meters (approximately 50 feet) using the IC697CBL700 series expansion cable. Exceeding this distance may cause bus communication errors.
Q: Do you offer exchange or repair services for faulty IC697BEM742 units?
A: Yes. Contact us with your defective unit details. We can arrange exchange-in-advance (EIA) to minimize your downtime, or refer you to certified GE repair partners.
Q: Can I order multiple units for a spare parts program?
A: Absolutely. We support B2B bulk orders and can provide volume pricing, consolidated shipping, and documentation packages for MRO spare parts programs.
