Industrial Power Distribution Solution – GE Fanuc IC697VDD100 | Series 90-70
Where This Product Is Used
The GE IC697VDD100 Voltage Distribution Device is deployed across a wide range of industrial automation environments where reliable, centralized power distribution to PLC backplane modules is critical. Typical application scenarios include:
- Automotive Manufacturing Lines – Distributes stable DC voltage across Series 90-70 racks controlling robotic welding cells and conveyor systems.
- Oil & Gas Processing Plants – Provides redundant power distribution in hazardous-area control panels where uptime is non-negotiable.
- Water & Wastewater Treatment Facilities – Supports continuous 24/7 PLC operation for pump control, SCADA integration, and alarm management.
- Pulp & Paper Mills – Powers distributed I/O racks across large-footprint process lines requiring long cable runs and stable voltage rails.
- Power Generation & Utilities – Used in turbine governor control panels and substation automation systems built on GE Series 90-70 architecture.
- Food & Beverage Processing – Integrated into washdown-rated control enclosures for packaging and filling line automation.
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number | IC697VDD100 |
| Manufacturer | GE Fanuc Automation (now GE Vernova / Emerson) |
| Series | Series 90-70 PLC |
| Module Type | Voltage Distribution Device |
| Form Factor | Single-slot Series 90-70 backplane module |
| Input Voltage | DC bus from Series 90-70 power supply |
| Output | Distributed voltage rails to adjacent I/O and CPU modules |
| Backplane Compatibility | IC697CHS750, IC697CHS782, IC697CHS790 and compatible racks |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | Approx. 450 g |
| Certifications | UL Listed, CE Marked, CSA |
Why Engineers Specify This Model
- Backplane Voltage Integrity – Ensures clean, regulated voltage distribution across multi-rack Series 90-70 configurations, reducing noise-induced faults in high-density I/O environments.
- Drop-in Replacement – Direct form-fit-function replacement for aging IC697VDD100 units without requiring rack or wiring modifications.
- Extended System Life – Enables continued operation of legacy Series 90-70 infrastructure, deferring costly full-system migrations.
- Proven Field Reliability – Thousands of units deployed globally in mission-critical industrial applications since the 1990s.
- Simplified Maintenance – Hot-swap-compatible design (with appropriate power sequencing) minimizes planned downtime during module replacement.
Complete System Bill of Materials
For a complete Series 90-70 PLC power distribution system, engineers typically specify the following alongside the IC697VDD100:
- IC697PWR710 / IC697PWR711 – Series 90-70 Power Supply (120/240 VAC input)
- IC697CHS750 / IC697CHS790 – Series 90-70 Baseplate / Rack
- IC697CPU772 / IC697CPU781 – Series 90-70 CPU Module
- IC697MDL340 / IC697MDL341 – Discrete Input/Output Modules
- IC697ALG320 / IC697ALG440 – Analog I/O Modules
- IC697BEM711 – Bus Expansion Module (for multi-rack configurations)
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- CSA C22.2 – Canadian Standards Association certification
- IEC 61131-2 – Programmable Controllers Hardware Requirements
- RoHS Compliant – Restriction of Hazardous Substances (where applicable to production date)
Quality Assurance & Sourcing
All GE IC697VDD100 units offered by Konmask.com are:
- Sourced from verified industrial surplus, OEM overstock, or authorized distribution channels
- Inspected and tested prior to shipment — including visual inspection, board-level checks, and functional verification where applicable
- Shipped with anti-static packaging and protective foam inserts to prevent transit damage
- Accompanied by a 90-day warranty against defects in materials and workmanship
- Traceable via lot documentation upon request for regulated industries
How to Source This Part
To place an order or request a quote for the GE IC697VDD100:
- Online: Add to cart directly on this page — stock is updated in real time.
- Email RFQ: Send your BOM or part number to support@konmask.com for volume pricing.
- Phone / WhatsApp: +0086 19859288691 — available Monday–Friday, 09:00–18:00 CST.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock units subject to sourcing lead time (typically 5–15 business days).
- Export: We ship worldwide. Export documentation (commercial invoice, packing list, COO) provided for international orders.
Application-Specific FAQ
Q: Is the IC697VDD100 compatible with all Series 90-70 racks?
A: Yes. It is designed for use with standard Series 90-70 backplanes including the IC697CHS750, IC697CHS782, and IC697CHS790 families. Always verify slot availability and power budget before installation.
Q: Can this module be used in a redundant power configuration?
A: The IC697VDD100 itself is a passive distribution device. Redundancy is achieved at the power supply level (e.g., dual IC697PWR711 supplies with appropriate diode ORing). Consult GE Series 90-70 Hardware Reference Manual (GFK-0262) for redundant power design guidance.
Q: What is the difference between IC697VDD100 and IC697VDD200?
A: The IC697VDD200 supports higher current distribution capacity for expanded rack configurations. The IC697VDD100 is the standard single-rack voltage distribution device. Confirm your rack’s power requirements before substituting.
Q: Do you provide a test report or certificate of conformance?
A: Yes, upon request. Please contact support@konmask.com with your order number and compliance requirements.
Q: Can I return a module if it does not fit my application?
A: We accept returns within 30 days of delivery for unused, uninstalled modules in original packaging. Contact our support team to initiate an RMA.
