GE IC698CHS017 17-Slot VME Backplane Rack – PACSystems RX7i Series
When a critical manufacturing line loses its PLC backplane, every minute of downtime translates directly into lost production, missed delivery windows, and cascading equipment faults. The GE IC698CHS017 is the structural and electrical backbone of your PACSystems RX7i control cabinet — without it, no CPU, no I/O module, and no power supply can communicate. There is no workaround; the rack must be sourced and replaced correctly.
The IC698CHS017 is GE’s largest standard VME-based backplane for the PACSystems RX7i platform, offering 17 module slots to support the most demanding, high-channel-count automation architectures. As part of GE’s flagship Series 90-70 successor platform, the RX7i is deployed across power generation, oil & gas, automotive assembly, and heavy process industries worldwide — making the IC698CHS017 one of the most sought-after spare parts in the global industrial automation market.
Technical Specifications
- Part Number: IC698CHS017
- Manufacturer: GE (General Electric) / GE Automation & Controls
- Series: PACSystems RX7i
- Backplane Type: VME (Versa Module Europa)
- Number of Slots: 17
- Compatible Power Supplies: IC698PSA100, IC698PSA350, IC698PSD300
- Compatible CPUs: IC698CPE010, IC698CPE020, IC698CPE030, IC698CPE040
- Mounting: 19-inch rack panel mount
- Weight: Approx. 800 g
- Operating Temperature: 0°C to 60°C
- Humidity: 5% to 95% non-condensing
- Certifications: CE, UL listed
Key Features & Benefits
- Maximum Slot Density: 17 slots accommodate CPUs, communication modules, and I/O in a single chassis — minimizing cabinet footprint.
- VME Bus Architecture: High-speed, deterministic backplane communication ensures real-time data integrity across all installed modules.
- Hot-Swap Ready: Supports module insertion/removal without full system shutdown when used with compatible RX7i components.
- Robust Industrial Construction: Heavy-gauge steel chassis with EMI shielding designed for harsh industrial environments.
- Backward Compatibility: Accepts legacy Series 90-70 I/O modules alongside modern PACSystems modules, protecting existing investments.
- Redundancy Support: Compatible with GE’s CPU redundancy configurations for high-availability applications.
Industry & Equipment Applications
- Power Generation: Turbine control, boiler management, and grid synchronization systems.
- Oil & Gas: Pipeline SCADA, compressor control, and wellhead automation.
- Automotive Manufacturing: Body-in-white assembly lines, paint shop conveyors, and press control.
- Water & Wastewater: Pump station control, filtration process management.
- Pulp & Paper / Chemical: Continuous process control requiring high I/O density and system uptime.
- Mining & Metals: Conveyor systems, crusher control, and smelter automation.
System Integration & Compatible Parts
The IC698CHS017 is the foundation of a complete PACSystems RX7i control system. Commonly paired components include:
- CPU Modules: IC698CPE010, IC698CPE020, IC698CPE030, IC698CPE040
- Power Supplies: IC698PSA100 (100W), IC698PSA350 (350W), IC698PSD300 (DC input)
- Ethernet Modules: IC698ETM001
- Analog I/O: IC694ALG220, IC694ALG390
- Digital I/O: IC694MDL340, IC694MDL654
- Expansion Racks: IC698CHS009 (9-slot), IC698CHS012 (12-slot)
Contact our technical team to verify compatibility with your existing RX7i configuration before ordering.
Our Quality Assurance Process
- Visual Inspection: All units checked for physical damage, bent pins, and connector integrity upon receipt.
- Functional Verification: Where applicable, modules are bench-tested against known-good reference systems.
- Authenticity Check: Part numbers, date codes, and manufacturer markings verified against GE documentation.
- Anti-Static Packaging: All units shipped in ESD-safe bags with foam padding and double-box protection.
- Documentation: Certificate of conformance available upon request.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond within 24 business hours with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange export documentation and international shipping.
For urgent requirements, email support@konmask.com or call +0086 19859288691.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, and automation hardware — not a general electronics marketplace.
- ✅ Global Export Experience: Serving clients in 40+ countries with proper commercial invoices, packing lists, and export declarations.
- ✅ Responsive Technical Support: Our team includes engineers with hands-on GE PACSystems experience.
- ✅ Competitive Lead Times: Extensive supplier network ensures faster sourcing than OEM channels for MRO and emergency needs.
- ✅ Secure Transactions: T/T, L/C, and other B2B payment terms available.
Frequently Asked Questions
Q: Is the IC698CHS017 still in production by GE?
A: The PACSystems RX7i platform has transitioned to end-of-life status with GE. Konmask.com sources genuine surplus and refurbished units to support ongoing maintenance needs.
Q: Can I mix Series 90-70 modules with PACSystems RX7i modules in this rack?
A: Yes. The IC698CHS017 supports both legacy Series 90-70 I/O modules and current PACSystems RX7i modules in the same chassis, subject to slot assignment rules defined in GE’s system configuration documentation.
Q: What is the maximum number of I/O points supported?
A: With 17 slots (minus CPU and power supply slots), the rack can support up to 13–15 I/O or communication modules, enabling thousands of I/O points depending on module selection.
Q: Do you provide a warranty?
A: Yes. We offer a standard 90-day warranty against defects in materials and workmanship. Extended warranty options are available — please inquire.
Q: Can you ship to my country?
A: We ship globally. Please provide your destination country when submitting your RFQ so we can confirm shipping options and estimated costs.
{
