Genuine Allen-Bradley 1756-IB16D Digital Input Module | ControlLogix – Verified Source
The Allen-Bradley 1756-IB16D is a 16-point, 10–30V DC sourcing digital input module within Rockwell Automation’s ControlLogix platform — one of the most widely deployed programmable automation controllers in heavy industry, oil & gas, automotive, and critical infrastructure worldwide. Its diagnostic-grade design (the “D” suffix denotes full diagnostics) makes it irreplaceable in safety-sensitive and high-availability applications. Due to its long production lifecycle and global demand, the 1756-IB16D is a frequent target for counterfeit reproduction, grey-market diversion, and refurbished units misrepresented as new — risks that can result in unplanned downtime, failed audits, or safety incidents.
At Konmask, every 1756-IB16D unit is sourced exclusively through verified industrial distribution channels and undergoes a documented 4-step quality verification process before dispatch. We supply only genuine, authentic, original Allen-Bradley modules — never refurbished, relabelled, or third-party clones. Our verified sourcing process, combined with full traceability documentation, gives procurement engineers and plant managers the confidence to specify Konmask as a trusted supply partner for genuine Rockwell Automation components.
Technical Specifications
- Part Number: 1756-IB16D
- Series: ControlLogix
- Manufacturer: Allen-Bradley / Rockwell Automation
- Module Type: Digital Input, Sourcing (DC)
- Number of Points: 16
- Input Voltage Range: 10–30V DC
- Diagnostic Features: Open-wire detection, short-circuit detection, field-side power loss detection
- Input Current (nominal): 2.0 mA @ 24V DC
- Input Delay (OFF→ON): 0–2 ms (software configurable)
- Input Delay (ON→OFF): 0–2 ms (software configurable)
- Backplane Current (5V DC): 75 mA
- Backplane Current (24V DC): 2 mA
- Power Dissipation (max): 2.5 W
- Isolation Voltage: 100V DC continuous (channel-to-backplane)
- Operating Temperature: 0–60°C (32–140°F)
- Storage Temperature: -40–85°C (-40–185°F)
- Relative Humidity: 5–95% non-condensing
- Wiring: Removable terminal block (RTB), 20-pin
- Dimensions (H × W × D): 94.0 × 94.5 × 58.5 mm
- Weight: Approx. 0.30 kg
- Certifications: UL, CE, C-Tick, FM Class I Div 2
Specifications verified against Allen-Bradley / Rockwell Automation official documentation (Publication 1756-TD002).
Our 4-Step Quality Verification Process
- Step 1 — Source Authentication: All units are procured from traceable industrial distribution channels. Supplier credentials, purchase invoices, and chain-of-custody records are retained for every batch. We do not source from open marketplaces or unverified brokers.
- Step 2 — Physical Inspection & Label Verification: Each module is inspected against Rockwell Automation’s published physical standards — holographic labels, date codes, PCB markings, and housing tolerances are cross-checked. Any unit with anomalies is quarantined and rejected.
- Step 3 — Functional Bench Testing: Modules are powered up and tested for correct backplane communication, input point response, and diagnostic signal integrity using ControlLogix test chassis. Test results are logged per serial number.
- Step 4 — Documentation Package: Every shipment is accompanied by a full documentation set upon request: Certificate of Conformance (COC), Functional Test Report, Packing List with serial numbers, Country of Origin (COO) Declaration, and high-resolution photos of the actual unit shipped.
Key Features & Benefits
- Full Diagnostic Capability: Open-wire, short-circuit, and field-power-loss detection per IEC 61131-2 input module diagnostic standards — enabling predictive maintenance and reducing unplanned downtime.
- Software-Configurable Input Filtering: 0–2 ms adjustable input delay allows optimisation for both high-speed sensing and noise-immune applications without hardware changes.
- ControlLogix Backplane Integration: Native integration with the 1756 chassis backplane ensures deterministic data exchange with ControlLogix L-series processors, compliant with Rockwell Automation’s Integrated Architecture® design guidelines.
- Removable Terminal Block (RTB): 20-pin RTB design allows field wiring to remain in place during module replacement, minimising maintenance downtime in live production environments.
- Wide DC Input Range (10–30V DC): Accommodates standard 24V DC field devices with tolerance for voltage sag, meeting IEC 61131-2 Type 1 and Type 3 input specifications.
- Proven Industrial Reliability: Rated for continuous operation at 0–60°C with 5–95% RH, meeting IEC 60068-2 environmental test standards for industrial control equipment.
Typical Applications
- Oil & Gas: Wellhead control panels and pipeline SCADA systems requiring diagnostic-grade discrete input monitoring with full fault reporting.
- Automotive Manufacturing: Body-in-white assembly lines using ControlLogix PLCs for high-speed conveyor and robot interlock sensing.
- Water & Wastewater Treatment: Pump station and valve position monitoring in distributed control architectures with redundant I/O requirements.
- Power Generation & Utilities: Turbine control and switchgear monitoring applications where open-wire detection is mandatory for safety compliance.
- Food & Beverage Processing: Hygienic production lines requiring reliable 24V DC sensor interfacing with full diagnostic visibility for OEE reporting.
- Mining & Minerals Processing: Crusher and conveyor control systems operating in high-vibration, wide-temperature environments demanding proven module reliability.
Compatible System Components
- 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 — ControlLogix Chassis (4, 7, 10, 13, 17 slot)
- 1756-PA72 / 1756-PB72 — ControlLogix Power Supplies (AC/DC)
- 1756-L71, 1756-L72, 1756-L73, 1756-L74, 1756-L75 — ControlLogix L7x Processors
- 1756-L81E, 1756-L82E, 1756-L83E, 1756-L84E, 1756-L85E — ControlLogix L8x Processors
- 1756-TBCH / 1756-TBS6H — Removable Terminal Blocks (RTB) for 1756-IB16D wiring
- 1756-EN2T / 1756-EN2TR — EtherNet/IP Communication Modules for networked I/O architectures
- Studio 5000 Logix Designer v21.00 or later — Required programming software
Global Sourcing & Shipping Capabilities
- Primary Service Regions: Mainland China, Hong Kong SAR, Southeast Asia (Vietnam, Thailand, Indonesia, Malaysia), Middle East (UAE, Saudi Arabia), Europe (Germany, Netherlands, Poland), and North America (USA, Canada, Mexico).
- Export Packaging Standard: Anti-static ESD bag + foam-lined carton + moisture-barrier outer packaging. All units are individually boxed with original or equivalent protective packaging. Fragile/high-value shipments are double-boxed with shock-indicator labels.
- Logistics Options: DHL Express, FedEx International Priority, UPS Worldwide, sea freight (LCL/FCL) for bulk orders, and China Post registered airmail for budget-sensitive destinations.
- Lead Time: In-stock units ship within 1–3 business days. Pre-order or sourced units: 5–15 business days depending on origin. Expedited sourcing available upon request.
- Export Documentation: Commercial Invoice, Packing List, COO Declaration, and HS Code 8538.90 classification provided as standard for customs clearance.
Certifications & Compliance Statement
- UL Listed (UL 508) — Industrial Control Equipment
- CE Marked — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- C-Tick (RCM) — Australian Communications and Media Authority
- FM Approved — Class I, Division 2, Groups A, B, C, D (Hazardous Locations)
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
Konmask Quality Commitment: Konmask.com supplies only genuine, original Allen-Bradley / Rockwell Automation products. We maintain full traceability records for every unit sold. If any product supplied by Konmask is found to be non-genuine, we will provide a full replacement or refund — no questions asked. Our quality commitment is backed by documented verification records available upon request.
How to Order
- Step 1 — Enquire: Submit your requirement via the product page, email [email protected], or WhatsApp/WeChat +0086 19859288691 with your required quantity, delivery address, and any special documentation needs.
- Step 2 — Confirm & Quote: Our technical team will respond within 24 hours with a formal quotation, availability confirmation, lead time, and documentation options (COC, test report, photos).
- Step 3 — Order & Ship: Upon order confirmation and payment, your unit is verified, packaged to export standard, and dispatched with full tracking and documentation. Sample units and pre-shipment test reports are available for qualified buyers.
Authenticity & Trust FAQ
-
Q: How can I verify that the 1756-IB16D I receive from Konmask is genuine?
A: Every unit we supply comes with a Certificate of Conformance (COC) and, upon request, a functional test report with serial number traceability. You can also verify the module’s date code and holographic label against Rockwell Automation’s published authenticity guidelines. We welcome pre-shipment photo verification for all orders. -
Q: What is Konmask’s warranty policy for the 1756-IB16D?
A: We offer a 12-month warranty against manufacturing defects on all genuine new units. If a module fails within the warranty period under normal operating conditions, we will replace it or issue a full refund. Warranty claims are supported by our test report and COC documentation. -
Q: Can Konmask provide a functional test report before shipment?
A: Yes. Pre-shipment functional test reports are available for all orders upon request. Reports include power-on test results, input point verification, diagnostic signal confirmation, and the serial number of the specific unit being shipped. Contact us at the time of enquiry to include this in your order documentation package.
