Honeywell 10002/1/2 – Analog Input Module | TDC 3000 DCS Platform
Engineering Background
The Honeywell TDC 3000 (Total Distributed Control) system has been the backbone of process automation in refining, petrochemical, and power generation facilities for decades. Designed for mission-critical continuous process environments, TDC 3000 delivers deterministic control with high-availability architecture. The 10002/1/2 is a field-proven analog input module within this platform, enabling precise acquisition of process variable signals from field transmitters directly into the control network.
Product Positioning
The Honeywell 10002/1/2 is engineered for procurement engineers and maintenance teams who require a verified, drop-in replacement or expansion module for existing TDC 3000 installations. Konmask.com supplies this module from inspected surplus inventory, ensuring functional integrity and compatibility with your existing system architecture.
Complete Technical Specifications
| Part Number | 10002/1/2 |
| Manufacturer | Honeywell Process Solutions |
| Platform / Series | TDC 3000 (Total Distributed Control) |
| Module Type | Analog Input Module |
| Signal Type | 4–20 mA / 1–5 VDC (field transmitter compatible) |
| Input Channels | Multi-channel analog input (refer to OEM datasheet for channel count) |
| Communication Bus | TDC 3000 Local Control Network (LCN) / Data Hiway |
| Power Supply | Supplied via TDC 3000 backplane (module-bus powered) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Form Factor | Standard TDC 3000 card cage module |
| Weight | Approx. 180 g |
| Certifications | CE, UL (refer to OEM documentation) |
| Country of Origin | USA |
Proven Application Environments
- Oil & Gas Refining – Continuous process variable monitoring in distillation, cracking, and blending units
- Petrochemical Plants – Integration with field transmitters for temperature, pressure, and flow measurement
- Power Generation – Boiler control and turbine monitoring within TDC 3000 architectures
- Pulp & Paper – Process loop control requiring high-resolution analog acquisition
- Pharmaceutical Manufacturing – Validated process environments with legacy DCS infrastructure
- Water & Wastewater Treatment – Long-lifecycle installations requiring OEM-compatible spare modules
Engineering Advantages
- Direct OEM Compatibility – Plug-and-play replacement within existing TDC 3000 card cages; no firmware reconfiguration required
- High Signal Fidelity – Precision analog-to-digital conversion minimizes process variable error
- Deterministic Response – Consistent scan cycle performance aligned with TDC 3000 control strategy timing
- Long Service Life – Designed for 24/7 continuous operation in industrial environments
- Reduced Downtime Risk – Stocking verified surplus units eliminates lead-time exposure during unplanned outages
System Architecture & Signal Flow
The 10002/1/2 module seats into the TDC 3000 card cage and interfaces with field wiring via the system’s I/O termination assembly. Analog signals from field-mounted transmitters (4–20 mA) are conditioned, converted, and transmitted over the Local Control Network (LCN) or Data Hiway to the High-Performance Process Manager (HPM) or equivalent controller node. The module operates transparently within the existing TDC 3000 configuration database — no re-engineering of control strategies is required for a like-for-like replacement.
Sourcing & Quality Verification
- All units sourced from decommissioned or surplus industrial installations
- Visual inspection: PCB integrity, connector condition, label legibility
- Functional bench test performed prior to shipment where applicable
- Original Honeywell firmware and hardware — no third-party modifications
- Shipped in anti-static packaging with protective foam insert
- Certificate of conformance available upon request
Procurement Process
- Submit RFQ – Contact us via email or phone with your required quantity and delivery timeline
- Stock Confirmation – We verify current inventory and provide a formal quotation within 24 hours
- Order Placement – Purchase order accepted; payment terms available for qualified accounts
- Inspection & Packaging – Unit inspected, photographed, and packed for safe transit
- Shipping – DHL / FedEx / UPS international express; tracking provided upon dispatch
- After-Sales Support – Technical assistance available post-delivery
Technical FAQ
Q: Is the 10002/1/2 compatible with all TDC 3000 card cage variants?
A: The module is designed for standard TDC 3000 card cages. Please confirm your cage model and backplane revision with our technical team before ordering.
Q: Can this module be used in a Honeywell Experion PKS migration project?
A: The 10002/1/2 is a native TDC 3000 module. For Experion PKS integration, consult Honeywell’s migration guides or contact our engineering team for compatibility assessment.
Q: What is the typical lead time?
A: In-stock units ship within 3–5 business days. Lead time for sourced units is 2–4 weeks depending on availability.
Q: Do you provide a warranty?
A: Yes. We offer a 90-day functional warranty on all surplus modules. Extended warranty options available upon request.
Q: Can I request a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com with your part number and we will provide available OEM documentation.
