HONEYWELL 10310/2/1 – Earth Leakage Detector | Residual Current Protection Relay
Engineering Background
Ground fault and earth leakage events are among the leading causes of electrical fires and equipment damage in industrial facilities. The HONEYWELL 10310/2/1 is engineered to detect residual currents with precision, providing a critical safety layer in power distribution panels, motor control centers, and process automation systems.
Product Positioning
The 10310/2/1 is a dedicated earth leakage detection relay designed for integration into industrial control architectures. It is widely deployed in manufacturing plants, utilities, and building automation systems where continuous ground fault monitoring is mandatory. As an OEM-sourced component, it is fully compatible with HONEYWELL’s broader protection and control ecosystem.
Complete Technical Specifications
- Part Number / SKU: 10310/2/1
- Manufacturer: HONEYWELL
- Function: Earth Leakage / Residual Current Detection
- Device Type: Residual Current Relay (RCR)
- Mounting: DIN Rail / Panel Mount
- Output: Relay contact output (SPDT)
- Weight: 200 g (approx.)
- Country of Origin: CN
- HS Code: 8536.49
- Compliance: CE / RoHS (verify current datasheet for regional certifications)
Note: For full electrical ratings (voltage range, trip current thresholds, response time, IP rating), please request the official HONEYWELL 10310/2/1 datasheet via support@konmask.com.
Proven Application Environments
- Industrial power distribution panels and MCC (Motor Control Centers)
- Process automation and PLC-controlled machinery
- Building management systems (BMS) and HVAC electrical protection
- Utility substations and switchgear assemblies
- Oil & gas, chemical, and pharmaceutical plant electrical safety systems
- Data center UPS and critical power infrastructure
Engineering Advantages
- High Sensitivity Detection: Accurately identifies residual currents to prevent latent ground faults from escalating into equipment failures or fires.
- Fast Trip Response: Minimizes exposure time to fault conditions, protecting both personnel and downstream equipment.
- Relay Contact Output: Directly interfaces with PLCs, SCADA systems, and alarm circuits without additional signal conditioning.
- Compact Form Factor: Optimized for space-constrained control panels with DIN rail compatibility.
- HONEYWELL OEM Quality: Manufactured to HONEYWELL’s industrial reliability standards, ensuring long service life in demanding environments.
System Architecture & Signal Flow
The 10310/2/1 monitors the vector sum of phase and neutral currents via a toroidal current transformer (CT). Under normal conditions, the sum equals zero. When a ground fault occurs, the imbalance exceeds the set threshold, triggering the internal relay. The relay contact output then signals the upstream circuit breaker, PLC input, or alarm system to initiate a protective response. This architecture ensures fail-safe operation independent of the main control logic.
Sourcing & Quality Verification
- Source: OEM-authorized supply chain — genuine HONEYWELL components only.
- Inspection: Each unit undergoes incoming quality inspection including visual, label, and functional verification.
- Documentation: Certificate of conformity and original packaging available upon request.
- Traceability: Lot and date codes traceable to HONEYWELL manufacturing records.
- Anti-Counterfeit: We do not source from gray-market or unverified distributors. All stock is procured through documented supply channels.
Procurement Process
- Inquiry: Submit your BOM or part number to support@konmask.com or via the product page.
- Quote: Receive a formal quotation with lead time, MOQ, and pricing within 1 business day.
- Order Confirmation: Purchase order accepted via email or online checkout.
- Quality Check & Dispatch: Units inspected and shipped with tracking within 2–5 business days.
- After-Sales Support: Technical support and warranty claims handled directly by Konmask engineering team.
Technical FAQ
Q: Is the HONEYWELL 10310/2/1 compatible with my existing HONEYWELL protection relay panel?
A: In most cases, yes. The 10310/2/1 is designed for integration within HONEYWELL’s industrial protection ecosystem. Please share your panel schematic for confirmation.
Q: What is the minimum detectable leakage current?
A: Please refer to the official HONEYWELL datasheet or contact us at support@konmask.com for the precise trip current specification for your application.
Q: Can this relay be used in ATEX / hazardous area zones?
A: The standard 10310/2/1 is not ATEX-rated. For hazardous area applications, please consult our team for suitable alternatives.
Q: Do you offer volume pricing for OEM or EPC contractors?
A: Yes. Volume discounts and blanket order arrangements are available. Contact us with your annual forecast for a tailored pricing agreement.
Q: What is the warranty period?
A: 12 months from date of shipment, covering manufacturing defects under normal operating conditions.
