Honeywell CC-TAIN01 Analog Input Module | Replacement, Equivalent & Selection Guide
The Honeywell CC-TAIN01 is a high-precision Analog Input Module designed for use in Honeywell’s Experion PKS and TotalPlant Solution (TPS) distributed control systems. This page provides a comprehensive selection guide, compatible replacement models, and sourcing information for industrial automation engineers and procurement teams.
Technical Specifications
- Part Number: CC-TAIN01
- Manufacturer: Honeywell Process Solutions
- Module Type: Analog Input Module
- Series: Experion PKS / C300 Controller Series
- Signal Type: 4–20 mA / 1–5 V analog input
- Channels: 8 channels (single-ended) / 4 channels (differential)
- Resolution: 16-bit A/D conversion
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication: FTE (Fault Tolerant Ethernet) / CEE bus
- Power Supply: 24 VDC (supplied via backplane)
- Operating Temperature: 0°C to 60°C
- Weight: Approx. 210 g
- Certifications: CE, UL, FM, ATEX (zone 2)
Compatible Replacement & Equivalent Models
The following Honeywell part numbers are functionally compatible or direct replacements for the CC-TAIN01 in specific system configurations:
- CC-PDIL01 — Process Digital Input Link Module; used in redundant I/O link configurations
- CC-TDIL01 — Terminal Digital Input Link Module; compatible in standard C300 I/O assemblies
- CC-TDIL11 — Enhanced Terminal Digital Input Link Module with extended diagnostics
- TK-FXX102 — Analog Input FTA (Field Termination Assembly); pairs with CC-TAIN01 for field wiring
- TK-FXX072 — Analog Input FTA variant; supports HART-enabled field devices
- TK-FXX132 — Analog Input FTA for intrinsically safe (IS) applications
Note: Always verify firmware revision and backplane compatibility before substitution. Contact our team for cross-reference validation.
Why Choose the Original CC-TAIN01
- Factory-tested and certified by Honeywell Process Solutions
- Full compatibility with Experion PKS R400–R520 and later revisions
- Supports HART pass-through for advanced field device diagnostics
- Redundancy-ready: hot-swap capable without process interruption
- Long-term availability backed by Honeywell’s lifecycle support program
Typical Applications
- Oil & gas upstream/downstream process control
- Chemical and petrochemical plant automation
- Power generation and utilities monitoring
- Pharmaceutical batch process control
- Pulp & paper and water treatment facilities
System Compatibility
- DCS Platform: Honeywell Experion PKS (C300 Controller)
- Legacy Systems: TotalPlant Solution (TPS), PlantScape
- I/O Link: CEE (Control Execution Environment) bus
- FTA Compatibility: TK-FXX102, TK-FXX072, TK-FXX132 series
- Redundancy: Supported with CC-TAIN01 pair configuration
Selection Guide
Use the table below to select the correct module for your application:
- Standard analog input (4–20 mA), non-HART: → CC-TAIN01 + TK-FXX102
- HART-enabled field devices: → CC-TAIN01 + TK-FXX072
- Intrinsically safe (IS) zone applications: → CC-TAIN01 + TK-FXX132
- Redundant I/O link required: → CC-TAIN01 + CC-PDIL01
- Extended diagnostics needed: → CC-TDIL11 (evaluate firmware compatibility)
Quality Assurance & Sourcing
- All units are sourced from authorized distributors or verified surplus channels
- 100% functional testing performed prior to shipment
- Original packaging and documentation preserved where available
- Traceability records available upon request
- 90-day warranty on all stocked modules
How to Order
- Confirm your part number: CC-TAIN01 (or compatible equivalent)
- Verify system revision and FTA pairing requirements
- Contact us via email or phone for stock availability and lead time
- Submit PO or place order directly through this page
- Receive shipping confirmation and tracking within 1–2 business days
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can CC-PDIL01 directly replace CC-TAIN01?
A: CC-PDIL01 is a Digital Input Link module and is not a direct functional replacement for CC-TAIN01 (Analog Input). They serve different I/O types. Consult your system I/O list before substitution.
Q: Is CC-TDIL11 backward compatible with CC-TDIL01?
A: Generally yes, but CC-TDIL11 includes enhanced diagnostics that may require updated Experion PKS firmware (R430 or later). Verify with your system engineer.
Q: Which FTA do I need for HART devices?
A: Use TK-FXX072 for HART-enabled analog input applications paired with CC-TAIN01.
Q: Do you supply tested or new units?
A: We supply both new (factory-sealed) and professionally tested surplus units. Condition is clearly stated on each listing.
Q: What is the lead time for CC-TAIN01?
A: In-stock units ship within 1–2 business days. Out-of-stock items typically have a 2–4 week lead time. Contact us for current availability.
