Honeywell SPXCDXSB1SS Sensepoint XCD Fixed Gas Detector | Replacement, Equivalent & Selection Guide
The Honeywell SPXCDXSB1SS is a fixed-point gas detector from the Sensepoint XCD series, engineered for continuous toxic and flammable gas monitoring in industrial environments. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: SPXCDXSB1SS
- Series: Sensepoint XCD
- Manufacturer: Honeywell Analytics
- Detector Type: Fixed-point gas detector (electrochemical / catalytic bead)
- Housing Material: Stainless steel (SS suffix)
- Enclosure Rating: IP66 / IP67
- Explosion Protection: ATEX / IECEx certified
- Output Signal: 4–20 mA analog + HART / Modbus RS-485
- Power Supply: 18–30 V DC
- Operating Temperature: −40°C to +65°C
- Display: Integrated LCD with backlight
- Alarm Relays: 3 × SPDT configurable relays
- Sensor Interface: Smart sensor plug-in module (field-replaceable)
- Approvals: ATEX, IECEx, cULus, SIL 2 capable
- Dimensions: Refer to Honeywell datasheet 13-261
- Weight: Approx. 1.2 kg (housing only)
Compatible Replacement & Equivalent Models
The following models are functionally compatible or serve as direct/near-direct replacements for the SPXCDXSB1SS in most applications. Always verify sensor module compatibility and output signal requirements before substitution.
- Honeywell SPXCDULK1SS — Sensepoint XCD universal sensor variant (stainless steel)
- Honeywell SPXCDXSB1AL — Aluminium housing variant; same electronics, different enclosure material
- Honeywell SPXCDXSB2SS — Dual-sensor variant for simultaneous gas detection
- Honeywell Sensepoint XCL — Compact lower-cost alternative for less demanding environments
- MSA Ultima X5000 — Cross-brand equivalent; 4–20 mA + HART, SIL 2, IP66
- Draeger Polytron 8700 — Equivalent fixed detector with plug-in sensor modules
- Crowcon Xgard Bright — Compatible replacement with LCD display and relay outputs
- Oldham MX 43 — Multi-channel controller-based equivalent for larger installations
Note: Third-party replacements may require adapter plates or recalibration. Contact Konmask for compatibility verification.
Why Choose the Original Model
- Plug-in smart sensor modules — field-replaceable without tools, minimizing downtime
- SIL 2 capable — meets functional safety requirements for critical process environments
- Dual-protocol output — native HART and Modbus RS-485 for seamless DCS/SCADA integration
- Stainless steel housing — superior corrosion resistance for offshore, chemical, and marine applications
- Proven global installed base — extensive OEM support, spare parts availability, and certified service network
- Integrated display & relays — standalone operation without external controller required
Typical Applications
- Oil & gas production platforms and refineries
- Chemical and petrochemical processing plants
- Wastewater treatment and utility facilities
- Pharmaceutical manufacturing (solvent vapor detection)
- Marine and offshore installations
- Power generation and turbine enclosures
- Food & beverage (CO₂ / NH₃ monitoring)
- Mining and tunneling environments
System Compatibility
The SPXCDXSB1SS integrates directly with the following control and safety systems:
- Honeywell HC900 / Experion PKS — native HART integration
- Siemens S7-300/400/1500 PLC — via 4–20 mA AI module or HART modem
- Rockwell Automation ControlLogix / CompactLogix — 4–20 mA or HART pass-through
- ABB System 800xA / AC500 — HART or Modbus RTU
- Emerson DeltaV / Fisher ROC — HART multidrop or point-to-point
- Yokogawa CENTUM VP — 4–20 mA with HART overlay
- Generic Modbus RTU masters — RS-485 two-wire, configurable baud rate
Selection Guide
Use the criteria below to confirm the SPXCDXSB1SS is the right model, or to identify the correct variant:
- Gas type: Select the appropriate plug-in sensor module (toxic, flammable, O₂) — the XSB1SS base unit is sensor-agnostic
- Housing material: SS (stainless steel) for corrosive/marine environments; AL (aluminium) for standard industrial use
- Output protocol: Confirm DCS/PLC input card type — 4–20 mA, HART, or Modbus RS-485
- Hazardous area classification: Verify ATEX/IECEx zone rating matches installation zone (Zone 1/2 or Zone 0 with appropriate sensor)
- Functional safety: If SIL 2 loop required, confirm SIL-rated sensor module is paired
- Ambient temperature: Standard range −40°C to +65°C; confirm against site conditions
- Mounting: 2-inch NPT or M20 conduit entry; confirm local conduit standard
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified OEM channels
- Each unit ships with original manufacturer documentation and calibration certificate where applicable
- Batch traceability maintained — lot numbers and date codes available on request
- Anti-counterfeit verification available for Honeywell-branded products
- Export compliance checked — ECCN / HTS classification provided upon request
- Lead time: typically 3–15 business days depending on stock status; contact us for urgent requirements
How to Order
-
Step 1: Confirm part number:
SPXCDXSB1SS - Step 2: Specify required sensor module (gas type + range) if not already paired
- Step 3: Indicate quantity and required delivery location
- Step 4: Submit inquiry via support@konmask.com or add to cart and proceed to checkout
- Step 5: Receive order confirmation with lead time and shipping details within 1 business day
For bulk orders (>5 units), OEM project pricing, or system integration support, contact our technical sales team directly.
Replacement & Compatibility FAQ
Q: Can I replace the SPXCDXSB1SS with an aluminium housing variant?
A: Yes, the SPXCDXSB1AL uses identical electronics. Ensure the enclosure material meets your site’s corrosion and area classification requirements.
Q: Are third-party sensor modules compatible with the XCD base unit?
A: No. The Sensepoint XCD uses proprietary smart sensor modules. Only Honeywell-approved modules are compatible.
Q: Can the SPXCDXSB1SS replace an older Sensepoint XCD unit?
A: Yes, it is backward-compatible with existing XCD wiring and conduit entries in most installations.
Q: Is recalibration required after replacing the sensor module?
A: Smart sensor modules are pre-calibrated at the factory. A bump test and zero/span verification on-site is recommended per IEC 60079-29-2.
Q: Does Konmask provide installation or commissioning support?
A: We provide technical documentation and remote guidance. On-site commissioning can be arranged through our partner network.
Q: What is the warranty on this product?
A: Standard manufacturer warranty applies (12 months). Extended warranty options available — contact us for details.
