Honeywell 51202329-200 – I/O Link Cable | Experion PKS DCS Platform
Engineering Background: The Honeywell 51202329-200 is a factory-engineered I/O Link Cable designed for use within Honeywell’s Experion PKS (Process Knowledge System) Distributed Control System architecture. This cable assembly provides the critical signal pathway between I/O modules and field termination assemblies (FTAs), ensuring deterministic, noise-immune communication in demanding process-control environments.
Product Positioning: Targeted at instrumentation and control engineers responsible for DCS panel wiring, cabinet integration, and system commissioning, the 51202329-200 is a direct OEM replacement and extension cable that eliminates field-fabrication risk. Its standardized connector interface and shielded construction make it the preferred choice for brownfield upgrades and greenfield Experion PKS installations alike.
Complete Technical Specifications
| Part Number | 51202329-200 |
| Manufacturer | Honeywell Process Solutions |
| Series / Platform | Experion PKS |
| Cable Function | I/O Link – Module-to-FTA Signal Cable |
| Cable Length | 200 (refer to Honeywell datasheet for unit; typically cm or inches per suffix convention) |
| Connector Type | OEM-specified multi-pin keyed connector (both ends) |
| Shielding | Overall foil + braid shield with drain wire |
| Jacket Material | PVC / Low-smoke halogen-free (per OEM spec) |
| Operating Temperature | 0 °C to +60 °C (storage: −40 °C to +85 °C) |
| Weight | 3,040 g (approx.) |
| Compliance | CE, RoHS (verify current revision with Honeywell) |
| Country of Origin | USA / Honeywell certified manufacturing facility |
Proven Application Environments
- Honeywell Experion PKS C200 / C300 Controller cabinets
- HLAI, LLAI, LLMUX, and digital I/O module-to-FTA wiring
- Oil & gas upstream / downstream DCS panels
- Petrochemical and refinery control rooms
- Power generation and utilities SCADA/DCS integration
- Pharmaceutical batch-process control systems (21 CFR Part 11 environments)
- Brownfield Experion PKS migration from TDC 3000 / PlantScape
Engineering Advantages
- OEM-Exact Fit: Keyed connectors prevent mis-wiring; plug-and-play replacement with zero field termination.
- EMI/RFI Immunity: Dual-layer shielding suppresses noise in high-density I/O marshalling cabinets.
- Signal Integrity: Matched impedance construction maintains Honeywell-specified I/O Link timing margins.
- Reduced Commissioning Time: Pre-tested, labeled assemblies eliminate continuity-check loops during FAT/SAT.
- Long Service Life: Industrial-grade jacket resists abrasion, chemicals, and UV in cabinet environments.
System Architecture & Signal Flow
In a standard Experion PKS I/O subsystem, the 51202329-200 cable routes from the I/O module backplane connector to the corresponding Field Termination Assembly (FTA) mounted on the marshalling cabinet rail. The I/O Link protocol carries multiplexed analog and discrete signals at defined scan rates governed by the C200/C300 controller. Proper cable routing—with segregation from power conductors and adherence to Honeywell’s bend-radius specification—is essential to maintain EMC compliance and system certification.
Sourcing & Quality Verification
- All units sourced from authorized Honeywell distributors or verified OEM-surplus channels.
- Each cable inspected for connector integrity, shield continuity, and jacket condition prior to dispatch.
- Part number label and date code verified against Honeywell’s published part numbering convention.
- Traceability documentation (CoC / test records) available upon request for regulated industries.
Procurement Process
- Confirm part number 51202329-200 against your Experion PKS BOM or cabinet drawing.
- Submit inquiry via support@konmask.com or place order directly on Konmask.com.
- Lead time: typically in-stock; expedited shipping available for AOG / plant-shutdown scenarios.
- Export documentation (commercial invoice, packing list, COO) provided for international shipments.
- Net payment terms available for qualified industrial accounts — contact sales for credit application.
Technical FAQ
Q: Is 51202329-200 compatible with Experion PKS R500 and later releases?
A: Yes. The I/O Link cable interface is backward-compatible across Experion PKS releases. Verify FTA model compatibility in your system’s hardware reference manual.
Q: Can this cable be used with Safety Manager (SM) I/O modules?
A: No. Safety Manager uses dedicated SIL-rated cabling. The 51202329-200 is for standard (non-safety) Experion PKS I/O only.
Q: What is the maximum I/O Link cable run length?
A: Honeywell specifies a maximum of 30 m (≈ 100 ft) for I/O Link cables. Consult Experion PKS Hardware Planning Guide for derating in high-noise environments.
Q: Do you supply the mating FTA connector or only the cable?
A: This listing covers the cable assembly only. FTAs and individual connectors are available as separate line items — contact us with your full BOM.
Q: Can I get a Certificate of Conformance?
A: Yes. CoC is available upon request at time of order for all units shipped from Konmask.com.
