HONEYWELL 51205995-501 Shunt Resistor Kit | Replacement, Equivalent & Selection Guide
The HONEYWELL 51205995-501 is a factory-original Shunt Resistor Kit designed for use in Honeywell TDC3000 and Experion PKS distributed control systems (DCS). This precision component ensures accurate 4–20 mA signal conversion and loop integrity across analog I/O modules. Sourced directly from verified industrial distributors, every unit at Konmask.com is inspected for authenticity and functionality before shipment.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 51205995-501 |
| Manufacturer | Honeywell Process Solutions |
| Component Type | Shunt Resistor Kit |
| Application | 4–20 mA current loop signal conditioning |
| Compatible Platform | TDC3000, Experion PKS, PlantScape |
| Resistance Value | 250 Ω (typical, per loop standard) |
| Operating Temperature | 0°C to 60°C |
| Weight | Approx. 20 g |
| Condition Available | New, Refurbished, Tested |
Compatible Replacement & Equivalent Models
If the 51205995-501 is on extended lead time or discontinued, the following alternatives are commonly used in equivalent DCS configurations:
| Model | Brand | Notes |
|---|---|---|
| 51205995-502 | Honeywell | Revised revision, functionally equivalent |
| 51204160-175 | Honeywell | Used in similar analog I/O termination assemblies |
| Generic 250Ω Shunt Kit | Third-party | Must verify tolerance ±0.1% and power rating |
Always verify compatibility with your specific I/O module and termination assembly before substitution. Contact support@konmask.com for engineering confirmation.
Why Choose the Original Model
- Factory-calibrated precision — Honeywell-spec resistance tolerance ensures signal accuracy across the full 4–20 mA range.
- Plug-and-play compatibility — Designed specifically for TDC3000 and Experion termination panels; no field modification required.
- Regulatory traceability — Original part numbers support SIL-rated loop documentation and audit trails.
- Long service life — Industrial-grade materials rated for continuous operation in process plant environments.
Typical Applications
- Analog input signal conditioning in TDC3000 High-Performance Process Manager (HPM)
- 4–20 mA loop termination in Experion PKS C200/C300 controller cabinets
- Field device interface panels in refinery, petrochemical, and power generation plants
- Retrofit and spare parts inventory for legacy Honeywell DCS installations
System Compatibility
- Honeywell TDC3000 (HPM, LCN, UCN architectures)
- Honeywell Experion PKS (R400–R520)
- Honeywell PlantScape (legacy)
- Third-party marshalling panels wired to Honeywell I/O termination assemblies
Selection Guide
Use the following criteria to confirm the correct shunt resistor kit for your application:
- Identify your I/O module — Check the termination assembly part number on the cabinet label.
- Verify resistance value — Standard 4–20 mA loops use 250 Ω; confirm with your loop drawing.
- Check revision level — Suffix -501 vs -502 may indicate hardware revision; consult Honeywell release notes.
- Confirm quantity per kit — The 51205995-501 kit typically includes multiple resistors; verify against your BOM.
- Assess condition requirement — New OEM stock recommended for SIL loops; refurbished acceptable for non-critical monitoring.
Quality Assurance & Sourcing
- All units sourced from authorized industrial distributors or verified surplus channels.
- Each kit undergoes visual inspection and resistance verification before dispatch.
- Certificate of conformance (CoC) available upon request for regulated applications.
- Packaging preserved in original or equivalent ESD-safe materials.
How to Order
- Add the HONEYWELL 51205995-501 to your cart on this page.
- For bulk orders (>10 units) or urgent requirements, email support@konmask.com for a dedicated quote.
- Specify required condition (New / Refurbished / Tested) in your order notes.
- Lead time: In-stock orders ship within 1–3 business days; sourced orders 5–15 business days.
Replacement & Compatibility FAQ
Q: Can I use a generic 250 Ω resistor instead of 51205995-501?
A: Technically possible for non-critical loops, but not recommended for SIL-rated or certified loops. The OEM kit ensures correct physical form factor and termination method.
Q: Is 51205995-502 a direct drop-in replacement?
A: In most cases yes, but verify with your Honeywell system integrator or check the Honeywell product change notice (PCN) for your specific revision.
Q: Do you provide a warranty?
A: New OEM units carry the standard Honeywell warranty. Refurbished units carry a 90-day Konmask functional warranty.
Q: Can you supply a full termination assembly instead?
A: Yes — contact us with your cabinet model and we can quote the complete assembly.
