Honeywell 51304901-100 HWD C I/O Module – High-Density Analog/Digital I/O Interface | TDC 3000 / TPS Platform
The Honeywell 51304901-100 is a HWD C I/O Module engineered for the TDC 3000 and TotalPlant Solution (TPS) Distributed Control System platform. Designed for continuous process industries, this module serves as a critical interface between field instrumentation and the DCS controller, enabling reliable signal acquisition and process control in demanding industrial environments.
As a procurement engineer sourcing legacy or active Honeywell TDC 3000 / TPS components, the 51304901-100 represents a proven, field-validated I/O solution with direct compatibility across Honeywell’s High-Performance Process Manager (HPM) and Process Manager (PM) architectures. Konmask.com maintains verified stock of this module, sourced through authorized and traceable supply channels.
Complete Technical Specifications
- Part Number: 51304901-100
- Description: HWD C I/O Module
- Manufacturer: Honeywell Process Solutions
- Platform Compatibility: TDC 3000, TotalPlant Solution (TPS), HPM, PM
- Module Type: I/O Interface Module (HWD C Series)
- Form Factor: Card/Module – DCS rack-mount
- Signal Types: Analog and Digital I/O (field-side interface)
- Communication: Honeywell proprietary UCN / LCN backplane bus
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Power Supply: Supplied via DCS rack backplane
- Weight: Approx. 220 g
- Country of Origin: United States
- Compliance: CE, UL listed (per Honeywell TDC 3000 system certification)
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA, downstream refinery DCS loops
- Petrochemical & Chemical: Reactor temperature/pressure monitoring, batch process control
- Power Generation: Boiler management systems, turbine control interfaces
- Pulp & Paper: Continuous digester control, bleaching process automation
- Pharmaceuticals: FDA-compliant process monitoring in validated DCS environments
- Water & Wastewater: Treatment plant process control integration
Engineering Advantages
- Direct TDC 3000 / TPS Compatibility: Drop-in replacement with no firmware reconfiguration required in most HPM/PM rack configurations
- High Signal Integrity: HWD C series modules are designed for noise-immune signal conditioning in electrically harsh plant environments
- Hot-Swap Capable: Supports live insertion/removal in redundant rack configurations (verify with site safety procedures)
- Long Service Life: Honeywell TDC 3000 platform modules are built to 20+ year operational standards, minimizing lifecycle replacement costs
- Backward Compatibility: Interoperable with legacy TDC 3000 and current TPS/Experion migration paths
System Architecture & Signal Flow
Within the TDC 3000 / TPS architecture, the 51304901-100 HWD C I/O Module resides in the I/O Link subsystem, interfacing field transmitters and actuators to the High-Performance Process Manager (HPM) or Process Manager (PM) controller via the Local Control Network (LCN) or Universal Control Network (UCN) backplane.
Signal Flow: Field Device → Field Termination Assembly (FTA) → 51304901-100 HWD C I/O Module → HPM/PM Controller → LCN/UCN Data Highway → Operator Console (US/GUS/TPS Console)
This module handles signal conditioning, A/D or D/A conversion, and data formatting before passing process values to the controller for PID loop execution and alarm management.
Sourcing & Quality Verification
- Source Traceability: All Honeywell modules at Konmask.com are sourced from documented supply chains including OEM overstock, decommissioned plant inventories, and authorized distributors
- Pre-Shipment Testing: Each unit undergoes visual inspection, board-level integrity check, and functional verification prior to dispatch
- Condition Grading: New surplus, refurbished, or used-tested – condition clearly stated at time of quotation
- Warranty: 12-month replacement warranty against manufacturing defects and functional failure
- Counterfeit Prevention: Konmask applies IDEA-STD-1010 inspection protocols to screen for counterfeit or non-conforming components
Procurement Process
- Submit RFQ: Contact support@konmask.com with your part number (51304901-100), required quantity, and delivery timeline
- Receive Quote: Pricing, lead time, and condition report provided within 24 business hours
- Order Confirmation: Purchase order accepted via email; payment terms available for qualified accounts
- Quality Inspection: Pre-shipment inspection report issued upon request
- Shipping: DHL / FedEx / UPS international express; EXW Xiamen or CIF destination available
- Documentation: Commercial invoice, packing list, certificate of conformance, and test report included
Technical FAQ
Q: Is the Honeywell 51304901-100 compatible with Experion PKS?
A: The 51304901-100 is native to TDC 3000 / TPS architecture. Experion PKS uses a different I/O subsystem (CIOM-A, LLMUX, etc.). Migration adapters may be required – consult your Honeywell system integrator.
Q: Can this module be used as a direct replacement for a failed unit in an HPM rack?
A: Yes, in most cases the 51304901-100 is a direct slot-for-slot replacement within compatible HPM I/O link configurations. Verify rack slot assignment and FTA wiring before installation.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. Contact us for current availability.
Q: Do you provide a test report?
A: Yes. A functional test report is available upon request at time of order.
Q: What certifications does this module carry?
A: The module is certified as part of the Honeywell TDC 3000 system, which carries CE, UL, and CSA system-level approvals. Individual module markings may vary by revision.
