Honeywell 8937-HN / 8939-HN / CC-PCNT01 / TC-RPSC04 – Process Controller Module | Experion PKS / TDC 3000 Platform
Engineering Background
Honeywell’s process control hardware has been the backbone of critical industrial infrastructure for decades. The 8937-HN, 8939-HN, CC-PCNT01, and TC-RPSC04 represent a family of controller and process-count modules engineered for the TDC 3000 and Experion PKS distributed control architectures — platforms trusted in refining, petrochemical, power generation, and advanced manufacturing environments worldwide.
Product Positioning
These modules serve as primary or redundant controller nodes within Honeywell DCS backplanes, handling high-speed process counting, regulatory control loops, and supervisory coordination. Procurement engineers sourcing replacement or expansion hardware will find these units essential for maintaining system continuity without full platform migration.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Numbers | 8937-HN / 8939-HN / CC-PCNT01 / TC-RPSC04 |
| Manufacturer | Honeywell Process Solutions |
| Platform Compatibility | TDC 3000, Experion PKS, PlantScape |
| Module Type | Process Controller / Counter Module |
| Form Factor | DIN-rail / Backplane card module |
| Operating Voltage | 24 VDC (backplane supplied) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | 480 g (approx.) |
| Communication Bus | Honeywell UCN / LCN proprietary backplane |
| Certifications | CE, UL Listed, RoHS compliant |
| Condition Available | New surplus / Tested refurbished / OEM |
Proven Application Environments
- Oil & Gas Refining – Regulatory loop control for distillation columns, compressors, and heat exchangers
- Petrochemical Plants – High-speed process counting for reactor feed and product metering
- Power Generation – Turbine governor and boiler control integration within TDC 3000 networks
- Pulp & Paper – Coordinated multi-loop control for digester and recovery boiler systems
- Pharmaceutical Manufacturing – Batch process control with audit-trail compliance requirements
- Water & Wastewater Treatment – SCADA-integrated pump and valve sequencing
Engineering Advantages
- Drop-in Compatibility – Direct replacement for existing TDC 3000 / Experion PKS backplane slots; no firmware reconfiguration required in most installations
- Redundancy Support – Supports hot-standby redundant controller configurations to achieve >99.9% uptime targets
- High-Speed Counting – CC-PCNT01 / TC-RPSC04 variants optimized for pulse-train inputs from flow meters, encoders, and turbine meters
- Deterministic Scan Cycle – Fixed-cycle execution ensures predictable loop response times critical for safety-instrumented systems
- Long Service Life – Designed for 15+ year operational lifespan in continuous-process environments
- Broad Firmware Compatibility – Compatible across multiple Honeywell DCS software revisions without hardware change
System Architecture & Signal Flow
Within a Honeywell TDC 3000 or Experion PKS cabinet, these controller modules reside in the Local Control Network (LCN) or Universal Control Network (UCN) backplane. The module receives process variable data from field I/O modules via the backplane bus, executes configured control algorithms (PID, ratio, cascade, feedforward), and outputs manipulated variable signals to final control elements. The CC-PCNT01 and TC-RPSC04 additionally accept high-frequency pulse inputs directly, performing hardware-level counting and rate calculation before passing engineering-unit values to the supervisory controller layer.
Redundant configurations pair two modules in primary/secondary roles with automatic bumpless transfer on fault detection, maintaining loop integrity without operator intervention.
Sourcing & Quality Verification
- All units sourced from authorized distributors, OEM surplus channels, or certified refurbishers
- Each module undergoes functional power-on verification and backplane communication test prior to shipment
- Serial numbers and firmware revision levels documented and provided with shipment
- Anti-static packaging with humidity indicator cards for safe international transit
- Counterfeit-prevention: physical inspection against Honeywell OEM reference standards
Procurement Process
- Confirm Part Number – Verify your required model (8937-HN, 8939-HN, CC-PCNT01, or TC-RPSC04) against your system’s bill of materials or existing module label
- Request Stock Confirmation – Contact us at support@konmask.com or +0086 19859288691 for real-time availability and lead time
- Place Order – Add to cart and complete checkout, or request a formal quotation for PO-based procurement
- Shipment & Documentation – Units ship with test report, packing list, and commercial invoice; DDP/DAP Incoterms available
- Incoming Inspection – We recommend functional verification in a test backplane before installation in live systems
Technical FAQ
Q: Are these modules compatible with Experion PKS R500 and later?
A: The 8937-HN and 8939-HN are TDC 3000-era modules; compatibility with Experion PKS depends on the specific cabinet and backplane revision. Please provide your system configuration for a compatibility assessment.
Q: Can CC-PCNT01 replace TC-RPSC04 directly?
A: Both perform process counting functions but differ in backplane slot type and firmware configuration. Cross-substitution requires engineering review of your system’s I/O assignment database.
Q: What warranty is provided?
A: All units carry a 90-day functional warranty covering defects in operation under normal DCS operating conditions. Extended warranty options available on request.
Q: Do you provide installation support?
A: Yes. Our technical team can provide remote commissioning guidance and configuration documentation for qualified site engineers.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items typically have a 2–6 week sourcing lead time depending on global availability.
