Honeywell C7076A1015 – Self-Check UV Flame Sensor | Burner Management Systems
Engineering Background
The Honeywell C7076A1015 is a self-checking ultraviolet (UV) flame sensor engineered for continuous-duty industrial burner management applications. Designed to operate within Honeywell’s proven flame safeguard ecosystem, this sensor provides reliable, fail-safe flame detection by monitoring UV radiation emitted during combustion. The self-check architecture ensures that any internal sensor failure is automatically detected and reported, preventing dangerous false-safe conditions in critical thermal processes.
Product Positioning
The C7076A1015 is the preferred choice for process engineers and OEM integrators specifying UV flame detection in boilers, industrial furnaces, process heaters, and multi-burner combustion systems. Its compatibility with Honeywell R7847, R7849, and RM7800-series flame amplifiers makes it a drop-in solution for both new installations and legacy system upgrades. Konmask.com supplies this sensor as a genuine, traceable component with full quality documentation.
Complete Technical Specifications
| Part Number | C7076A1015 |
| Manufacturer | Honeywell Process Solutions |
| Sensor Type | Self-Checking Ultraviolet (UV) Flame Sensor |
| Detection Spectrum | Ultraviolet (UV), 185–260 nm |
| Self-Check Function | Automatic internal self-test; detects sensor failure and signals lockout |
| Supply Voltage | 120 VAC / 60 Hz (nominal) |
| Compatible Amplifiers | R7847A, R7849A, RM7800-series, R4795A |
| Mounting | 1/2 in. NPT threaded sight pipe |
| Viewing Angle | 70° (half-angle) |
| Operating Temperature | –40°C to +66°C (–40°F to +150°F) |
| Enclosure Rating | NEMA 4 (IP65 equivalent) |
| Approvals / Certifications | UL Listed, CSA Certified, CE Marked |
| Weight | Approx. 3,080 g (with mounting hardware) |
| Country of Origin | USA |
Proven Application Environments
- Industrial Boilers – Steam and hot-water boilers requiring continuous flame supervision with automatic self-diagnostics
- Process Furnaces & Kilns – High-temperature combustion chambers where UV detection outperforms infrared in sooty or luminous-flame conditions
- Multi-Burner Combustion Systems – Parallel burner arrays managed by RM7800-series programmable controllers
- Thermal Oxidizers & Incinerators – Waste-gas combustion systems requiring fail-safe flame proof
- Power Generation Auxiliary Burners – Startup and pilot burner supervision in gas turbine and combined-cycle plants
- OEM Packaged Burner Units – Factory-integrated into Honeywell-compatible burner management panels
Engineering Advantages
- Self-Check Architecture – Continuously verifies sensor tube integrity; any degradation triggers immediate lockout signal, eliminating dangerous false-safe states
- UV-Only Detection – Immune to infrared background radiation from hot refractory walls, reducing nuisance trips in high-temperature environments
- Wide Viewing Angle (70°) – Accommodates burner misalignment and simplifies sight-pipe positioning during commissioning
- NEMA 4 / IP65 Enclosure – Suitable for washdown environments and outdoor installations subject to moisture ingress
- Direct Amplifier Compatibility – Plug-compatible with the full Honeywell R7847/R7849/RM7800 amplifier family; no signal conditioning required
- Long Service Life – UV tube rated for extended duty cycles; self-check function provides early warning before end-of-life failure
System Architecture & Signal Flow
The C7076A1015 operates as the sensing element within a Honeywell flame safeguard loop. UV photons from the burner flame strike the sensor’s internal UV tube, generating a pulsed signal proportional to flame intensity. This signal is transmitted to a compatible flame amplifier (e.g., R7847A), which processes the pulse rate and amplitude to determine flame presence. The self-check circuit periodically interrupts the UV tube bias voltage; if the tube fails to respond correctly, the amplifier drives the burner controller to a safe lockout state. The entire detection-to-lockout sequence complies with IEC 61511 SIL 2 functional safety requirements when integrated with a certified RM7800-series controller.
Sourcing & Quality Verification
- Genuine OEM Component – Sourced through authorized Honeywell distribution channels; each unit carries original Honeywell part labeling and date codes
- Traceability Documentation – Certificate of Conformance (CoC) and packing slip available upon request for each shipment lot
- Pre-Shipment Inspection – Visual inspection and packaging integrity check performed before dispatch
- Anti-Counterfeit Assurance – Holographic labels and OEM serial numbers verified against Honeywell product databases prior to listing
- Storage Conditions – Maintained in climate-controlled warehouse; UV tubes stored away from direct light exposure to preserve tube life
Procurement Process
- Confirm Compatibility – Verify your flame amplifier model (R7847A, R7849A, RM7800-series) and sight-pipe thread size (1/2 in. NPT) before ordering
- Request a Quote – Contact support@konmask.com for volume pricing, lead time confirmation, and CoC documentation
- Place Order – Orders accepted via the Konmask.com storefront or direct PO for B2B accounts; net payment terms available for qualified buyers
- Shipping & Lead Time – In-stock units ship within 1–3 business days; international DDP/DAP options available for cross-border procurement
- After-Sales Support – Technical commissioning guidance and warranty claim processing handled by Konmask engineering support team
Technical FAQ
Q: Can the C7076A1015 detect natural gas flames?
A: Yes. Natural gas flames emit sufficient UV radiation in the 185–260 nm band for reliable detection. The sensor is equally effective on oil, propane, and hydrogen flames.
Q: What is the difference between C7076A1015 and C7076D?
A: The C7076A series uses a self-checking UV tube design compatible with R7847/R7849 amplifiers. The C7076D is a non-self-checking variant. Always match the sensor to the amplifier’s self-check input requirements.
Q: How often should the UV tube be replaced?
A: Honeywell recommends annual inspection. The self-check function provides continuous in-service monitoring; a lockout event with no combustion fault present is a reliable indicator of tube end-of-life.
Q: Is the C7076A1015 suitable for outdoor installation?
A: Yes. The NEMA 4 enclosure rating provides protection against rain, splashing water, and windblown dust, making it suitable for outdoor boiler houses and process heater installations.
Q: Can Konmask provide a Certificate of Conformance?
A: Yes. CoC documentation is available for all shipments upon request. Contact support@konmask.com with your order number.
