Differential Analog Input Solution – Honeywell CC-TAID11 51306731-175 | Experion PKS C300 Series
Where This Product Is Used
The Honeywell CC-TAID11 (P/N 51306731-175) Differential Analog Input IOTA is deployed in process industries where precise, noise-immune measurement of differential signals is critical. Typical installation environments include:
- Oil & Gas Upstream/Midstream: Wellhead pressure differential monitoring, separator level control, and pipeline flow measurement via differential pressure transmitters.
- Petrochemical & Refining: Reactor feed flow control, distillation column differential pressure profiling, and heat exchanger fouling detection.
- Power Generation: Steam flow measurement, boiler drum level control, and turbine lube oil differential pressure monitoring.
- Pulp & Paper / Chemical Plants: Digester pressure control, evaporator level measurement, and chemical dosing flow verification.
- Water & Wastewater Treatment: Filter differential pressure monitoring and pump performance trending.
This IOTA interfaces directly with Honeywell’s C300 Controller within the Experion PKS architecture, providing galvanically isolated, differential analog input channels that reject common-mode noise inherent in industrial field wiring.
Technical Specifications
| Part Number | CC-TAID11 / 51306731-175 |
| Manufacturer | Honeywell Process Solutions |
| Module Type | Differential Analog Input IOTA |
| Compatible Controller | C300 Process Controller (Experion PKS) |
| Input Type | Differential Analog (4–20 mA / voltage) |
| Channel Isolation | Galvanic isolation, channel-to-channel and channel-to-bus |
| Common-Mode Rejection | High CMRR for noisy industrial environments |
| Form Factor | IOTA (I/O Termination Assembly) — DIN rail / panel mount |
| Weight | 420 g |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Certifications | CE, UL/cUL (refer to Honeywell datasheet for full listing) |
| Firmware Compatibility | Experion PKS R310 and above (verify with site revision) |
Note: Always cross-reference with the Honeywell Experion PKS I/O Module Specification document for your site revision before ordering.
Why Engineers Specify This Model
- True Differential Input Architecture: Eliminates ground loop errors common with single-ended inputs — essential for long cable runs in large process plants.
- Seamless Experion PKS Integration: Plug-and-play compatibility with C300 controllers; no additional signal conditioning hardware required.
- High Signal Integrity: Superior common-mode rejection ratio (CMRR) ensures accurate readings even in electrically noisy environments near VFDs, motors, and switchgear.
- Galvanic Isolation: Protects the controller backplane from field-side faults and transients, reducing unplanned downtime risk.
- Proven Field Reliability: Honeywell’s IOTA platform has decades of installed base in tier-1 refineries and power plants globally.
- Simplified Maintenance: IOTA design allows field wiring to remain connected during FTA/module swap — minimizing process interruption during maintenance windows.
Complete System Bill of Materials
For a fully operational differential analog input loop within Experion PKS, the following components are typically required:
- CC-TAID11 / 51306731-175 — Differential Analog Input IOTA (this item)
- C300 Process Controller (e.g., CC-PCF901) — Main controller module
- Analog Input FIM/FTA — Field Interface Module or Field Termination Assembly (site-specific)
- ASSY Cable / Ribbon Cable — IOTA-to-FTA interconnect (Honeywell-specified part)
- DIN Rail & Enclosure Hardware — Per site installation standard
- Differential Pressure Transmitter (e.g., Honeywell STD800, Yokogawa EJA) — Field instrument
- 24 VDC Power Supply — For loop power (if not HART-powered)
Contact support@konmask.com to source any of the above companion components.
Compliance & Industry Standards
- CE Marking — Compliant with EU EMC and Low Voltage Directives
- UL/cUL Listed — North American safety certification
- IEC 61131-2 — Programmable controller hardware requirements
- ISA-5.1 — Instrumentation symbols and identification (loop documentation)
- IEC 61508 / SIL — Consult Honeywell SIL documentation for functional safety applications
- RoHS Compliant — Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask.com specializes in the procurement of industrial automation components for MRO (Maintenance, Repair & Operations) and capital project requirements. Our sourcing process for the CC-TAID11 includes:
- Authenticity Verification: Each unit is inspected for genuine Honeywell labeling, date codes, and firmware revision markings prior to dispatch.
- Functional Pre-check: Where test fixtures are available, modules undergo power-on verification.
- Traceability Documentation: Certificate of conformance and inspection records provided upon request.
- Packaging: ESD-safe anti-static bags with foam cushioning; original OEM packaging preserved where available.
- Warranty: 90-day Konmask warranty against DOA (Dead on Arrival) defects; extended warranty available on request.
How to Source This Part
Konmask maintains stock of Honeywell Experion PKS components for rapid dispatch. To place an order or request a quotation:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Online: Add to cart directly on this page — or contact us for bulk/project pricing.
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders subject to availability confirmation.
- Export: We support international shipping with full commercial invoice and packing list documentation for customs clearance.
Application-Specific FAQ
Q: Is the CC-TAID11 compatible with Experion PKS R500 and later releases?
A: Compatibility depends on your specific Experion release and C300 firmware. We recommend verifying against Honeywell’s Experion PKS Compatibility Matrix or contacting your Honeywell account manager. Konmask can assist with revision identification.
Q: Can this IOTA be used with HART-enabled transmitters?
A: The CC-TAID11 is a differential analog input IOTA. HART pass-through capability depends on the associated FIM/FTA configuration. Consult the Honeywell Experion I/O module documentation for your specific topology.
Q: What is the difference between an IOTA and an FTA in Honeywell’s architecture?
A: In Experion PKS, the IOTA (I/O Termination Assembly) is the field-wiring termination point that connects to the C300 controller via a cable. The FTA (Field Termination Assembly) is used in the Series C architecture. The CC-TAID11 is specifically an IOTA for the C300 platform.
Q: Do you supply the mating cable for the CC-TAID11?
A: Yes. Contact us with your cabinet layout details and we can source the appropriate Honeywell interconnect cable. Include your Experion revision and C300 chassis configuration in your inquiry.
Q: Can I use a refurbished unit in a safety-instrumented system (SIS)?
A: SIS applications require components with full traceability and SIL certification documentation. Contact us to discuss your functional safety requirements before ordering for SIS use.
