Honeywell CC-GDIL11 Digital Input Module | Replacement, Equivalent & Selection Guide
The Honeywell CC-GDIL11 is a 24 VDC Digital Input (DI) module designed for the Honeywell Experion PKS C300 Controller platform. It provides reliable field-signal acquisition for process automation environments in oil & gas, chemical, power, and manufacturing industries. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing the CC-GDIL11 or its functional equivalents.
Technical Specifications
- Part Number: CC-GDIL11
- Manufacturer: Honeywell Process Solutions
- Series: Experion PKS C300 / CIOM-A Series
- Module Type: Digital Input (DI)
- Input Channels: 32 channels (16 per terminal board)
- Input Voltage: 24 VDC
- Signal Type: Dry contact / Wet contact (configurable)
- Isolation: Optical isolation per channel group
- Communication: FTE (Fault Tolerant Ethernet) via C300 backplane
- Mounting: DIN rail via CIOM-A chassis
- Operating Temperature: 0°C to 60°C
- Certifications: CE, UL, FM (Class I Div 2)
- Weight: ~300 g
- Firmware: Compatible with Experion PKS R400 and above
Compatible Replacement & Equivalent Models
The following modules are functionally equivalent or drop-in replacements for the CC-GDIL11 in most C300 DCS configurations. Always verify firmware revision and terminal board compatibility before substitution.
- CC-GDIL01 — Earlier revision of CC-GDIL11; same channel count, verify firmware compatibility
- CC-PDIL11 — 120 VAC Digital Input variant; use when field wiring is AC-powered
- CC-TDIL11 — HART-enabled DI module for smart field devices
- Emerson DeltaV MD Plus DI — Cross-platform alternative for DeltaV migrations; requires I/O marshalling redesign
- ABB S800 DI810 — Functional equivalent for ABB 800xA systems; not a direct plug-in replacement
- Siemens ET 200SP DI 16x24VDC — Comparable 24 VDC DI module for Siemens TIA Portal environments
Note: Third-party equivalents require engineering validation. Konmask.com recommends using genuine Honeywell modules for safety-critical loops.
Why Choose the Original CC-GDIL11
- ✅ Seamless Integration — Plug-and-play with existing C300 CIOM-A chassis; no re-engineering required
- ✅ Proven Reliability — Designed for 24/7 continuous operation in SIL-rated environments
- ✅ Firmware Continuity — Fully supported under Honeywell Experion PKS lifecycle program
- ✅ Regulatory Compliance — FM Class I Div 2 and ATEX Zone 2 certified for hazardous areas
- ✅ Reduced Commissioning Risk — Factory-tested and pre-configured for rapid deployment
Typical Applications
- Process status monitoring (valve open/close, pump run/stop)
- Emergency Shutdown (ESD) system input acquisition
- Discrete field device feedback in oil & gas upstream/downstream
- Boiler and turbine control systems
- Water treatment and utilities automation
- Pharmaceutical batch process control
System Compatibility
- Controller: Honeywell C300 Process Controller
- Chassis: CIOM-A (CC-CIOM01, CC-CIOM11)
- Terminal Board: CC-TBDI11 / CC-TBDI01 (32-channel DI terminal board)
- Software: Honeywell Experion PKS R400, R410, R430, R500+
- Redundancy: Supports 1:1 redundant I/O configuration with CC-GDIL11 pair
- Network: FTE (Fault Tolerant Ethernet) — dual-ring topology
Selection Guide
Use the table below to select the correct Honeywell C300 Digital Input module for your application:
- 24 VDC dry/wet contact inputs → CC-GDIL11 (this model)
- 120 VAC field inputs → CC-PDIL11
- HART-enabled smart devices → CC-TDIL11
- High-density 64-channel DI → CC-GDIL11 × 2 modules on dual CIOM-A
- SIL 2 safety loops → Consult Honeywell Safety Manager series (SM-DI)
- Replacement for CC-GDIL01 → CC-GDIL11 (direct upgrade, verify terminal board)
Quality Assurance & Sourcing
All CC-GDIL11 modules supplied by Konmask.com are:
- Sourced from authorized distributors or verified surplus channels
- Inspected for physical integrity, label authenticity, and firmware version
- Tested for basic I/O functionality prior to shipment
- Shipped with anti-static packaging and full traceability documentation
- Backed by our 90-day quality guarantee
We specialize in hard-to-find and long-lead-time industrial automation components for MRO and capital project procurement teams.
How to Order
- Part Number: CC-GDIL11
- Minimum Order: 1 unit
- Lead Time: In stock — ships within 1–3 business days (subject to availability)
- Payment: T/T, PayPal, credit card accepted
- Shipping: DHL / FedEx / UPS worldwide express
- RFQ: Email support@konmask.com for bulk pricing or urgent requirements
Replacement & Compatibility FAQ
Q: Can CC-GDIL01 replace CC-GDIL11?
A: In most cases yes — both are 32-channel 24 VDC DI modules. Verify firmware revision compatibility with your Experion PKS version before swapping.
Q: Is CC-GDIL11 compatible with the C200 controller?
A: No. CC-GDIL11 is designed exclusively for the C300 platform and CIOM-A chassis. C200 uses a different I/O bus architecture.
Q: Can I use CC-GDIL11 in a redundant I/O configuration?
A: Yes. Pair two CC-GDIL11 modules in the CIOM-A chassis with the appropriate redundancy jumper settings and Experion PKS configuration.
Q: What terminal board is required?
A: CC-TBDI11 (preferred) or CC-TBDI01. Ensure the terminal board revision matches your chassis generation.
Q: Does Konmask.com provide a warranty?
A: Yes — all units carry a 90-day quality guarantee. Contact us for extended warranty options on larger orders.
