DCS Network Expansion Solution – Honeywell CC-INWE01 | Experion PKS C300 Series
Where This Product Is Used
The Honeywell CC-INWE01 Network Expansion Module is deployed in Experion PKS (Process Knowledge System) distributed control architectures wherever engineers need to extend the Fault-Tolerant Ethernet (FTE) network reach of a C300 Controller chassis. Typical installation environments include:
- Oil & Gas Refineries – expanding I/O node connectivity across large process units (CDU, HDS, FCC)
- Petrochemical & Chemical Plants – linking remote CIOM/CHARM cabinets to the main controller ring
- Power Generation Facilities – integrating boiler management and turbine control I/O segments
- Pulp & Paper Mills – extending network segments across geographically distributed process areas
- Pharmaceutical Manufacturing – supporting validated DCS topologies requiring redundant network paths
- LNG & Offshore Platforms – harsh-environment installations requiring certified, compact modules
Wherever a C300 controller must communicate with additional CIOM-A or CHARM I/O Link modules beyond the base chassis capacity, the CC-INWE01 provides the certified, plug-and-play network expansion path.
Technical Specifications
| Part Number | CC-INWE01 |
| Manufacturer | Honeywell Process Solutions |
| Series | Experion PKS – C300 Controller Platform |
| Module Type | Network Expansion Module (FTE / I/O Link) |
| Compatible Controller | C300 Process Controller |
| Network Interface | Fault-Tolerant Ethernet (FTE) – dual-port |
| I/O Link Ports | Expands available CIOM-A / CHARM I/O Link connections |
| Mounting | C300 Controller Chassis (Series C backplane) |
| Power Supply | Supplied via chassis backplane |
| Operating Temperature | 0 °C to +60 °C |
| Weight | 140 g (approx.) |
| Certifications | CE, UL, FM (refer to Honeywell datasheet for full listing) |
| Firmware | Compatible with Experion PKS R400 and above |
Why Engineers Specify This Model
- Seamless FTE Integration – Maintains the dual-redundant Ethernet topology required for SIL-rated and high-availability loops without additional switches or media converters.
- Plug-and-Play Chassis Fit – Slots directly into the C300 chassis backplane; no external wiring or configuration files required for hardware recognition.
- Scalable I/O Architecture – Allows engineers to add CIOM-A or CHARM I/O Link segments incrementally, protecting capital investment as process requirements grow.
- Reduced Engineering Risk – Factory-tested and Honeywell-certified; eliminates compatibility uncertainty common with third-party network adapters.
- Compact Form Factor – Minimizes cabinet real estate in space-constrained marshalling rooms and offshore enclosures.
- Long Product Lifecycle – Supported under Honeywell’s Extended Lifecycle Program, ensuring spare parts availability for 10+ year plant lifecycles.
Complete System Bill of Materials
The CC-INWE01 is typically ordered alongside the following Experion PKS C300 platform components:
- CC-PCF901 – C300 Process Controller Module
- CC-PWR001 – Controller Power Supply Module
- CC-TCNT01 – C300 Controller Chassis (8-slot)
- CC-CIOB01 / CC-CIOB02 – CIOM-A I/O Base Module
- CC-TAIX01 / CC-TAOX01 – Analog Input / Output Termination Assemblies
- CC-TDIL01 / CC-TDOL01 – Digital Input / Output Termination Assemblies
- 51309512-175 – FTE Network Cable (shielded Cat5e, 1 m)
- CC-SCMB01 – Series C Mounting Bracket Kit
Contact support@konmask.com for complete BOM pricing and availability on multi-part orders.
Compliance & Industry Standards
- IEC 61511 – Functional Safety for Process Industry Sectors (SIL-capable architecture)
- IEC 61784 – Industrial Communication Networks (FTE protocol compliance)
- ATEX / IECEx – Suitable for use in associated apparatus configurations (verify zone rating with Honeywell)
- CE Marking – EU Electromagnetic Compatibility Directive 2014/30/EU
- UL 508 – Industrial Control Equipment (UL Listed)
- ISA-18.2 – Management of Alarm Systems for the Process Industries
- NAMUR NE 107 – Self-Monitoring and Diagnosis of Field Devices
Quality Assurance & Sourcing
Every CC-INWE01 unit supplied by Konmask.com undergoes the following verification process before dispatch:
- ✔ Visual inspection against Honeywell OEM cosmetic and label standards
- ✔ Part number and date-code verification against Honeywell product documentation
- ✔ Functional power-on test where test fixtures are available
- ✔ Anti-static packaging with humidity indicator card
- ✔ Traceable documentation provided on request (COC, test report)
We source exclusively from authorized distributors, certified surplus channels, and direct OEM overstock. Counterfeit-free guarantee backed by our 12-month warranty.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly on Konmask.com.
- Request a Quote – Email support@konmask.com with your required quantity and delivery timeline for volume pricing.
- Urgent Requirement – Call or WhatsApp +0086 19859288691 for same-day stock confirmation and expedited shipping options.
- Cross-Reference – If you are sourcing a replacement for a legacy Honeywell part, share your existing part number and we will confirm compatibility.
Typical lead time: 1–3 business days for in-stock units. International DDP/DAP shipping available to most regions.
Application-Specific FAQ
Q: Is the CC-INWE01 compatible with Experion PKS R500 and later releases?
A: Yes. The module is backward and forward compatible across Experion PKS R400 through R500+ releases. Always verify firmware revision requirements in the Honeywell release notes for your specific R-level.
Q: Can the CC-INWE01 be used with the C200 or C200E controller?
A: No. The CC-INWE01 is designed exclusively for the C300 controller chassis backplane. C200/C200E systems use a different network expansion architecture.
Q: How many CC-INWE01 modules can be installed per C300 chassis?
A: Refer to the Honeywell C300 Controller Hardware Planning Guide (document 51-52-25-109) for the maximum number of expansion modules per chassis slot configuration.
Q: Does this module support redundant network paths?
A: Yes. The CC-INWE01 participates in the FTE dual-ring topology, providing automatic failover at the network layer with no process interruption.
Q: What is the warranty on units supplied by Konmask.com?
A: All units carry a 12-month warranty from date of shipment. Extended warranty and on-site support contracts are available on request.
