Honeywell CC-PAIH02 HART Analog Input Module – Experion C300 Series
Imagine a critical process loop in your refinery or chemical plant suddenly losing its field instrument signal. Without a reliable HART-capable analog input module, your DCS becomes blind — operators lose visibility, alarms go unacknowledged, and the risk of unplanned shutdown escalates within minutes. The Honeywell CC-PAIH02 (P/N 51405038-376) exists precisely to prevent this scenario. It serves as the trusted bridge between your HART-enabled field instruments and the Experion PKS control system, ensuring continuous, high-integrity signal acquisition even in the most demanding process environments.
Within the Honeywell Experion PKS C300 Controller Series, the CC-PAIH02 occupies a specialized role as a dual-channel HART Analog Input module. It is engineered to handle 4–20 mA analog signals while simultaneously supporting HART digital communication — a combination that enables advanced diagnostics, device configuration, and predictive maintenance without interrupting the primary control loop. Honeywell’s Experion PKS platform is deployed across thousands of facilities worldwide in oil & gas, petrochemical, power generation, and pharmaceutical industries, making the CC-PAIH02 one of the most widely trusted I/O modules in global industrial automation.
Technical Specifications
- Part Number: CC-PAIH02 / 51405038-376
- Manufacturer: Honeywell Process Solutions
- Series: Experion PKS C300 Controller I/O
- Module Type: HART Analog Input
- Signal Type: 4–20 mA with HART protocol overlay
- HART Revision: HART 5 / HART 7 compatible
- Isolation: Channel-to-channel and channel-to-bus isolation
- Mounting: C300 I/O Link chassis / IOLIM compatible
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Weight: Approx. 200 g
- Compliance: CE, UL, FM (refer to Honeywell datasheet for full certifications)
Note: All specifications are sourced from Honeywell official documentation. Konmask.com does not fabricate or alter manufacturer specifications.
Key Features & Benefits
- Dual HART Channel Support: Simultaneously reads two HART field devices, reducing module count and cabinet footprint.
- Non-Intrusive Device Diagnostics: HART secondary variable access enables predictive maintenance without process interruption.
- High Signal Integrity: Galvanic isolation protects against ground loops and electrical noise common in heavy industrial environments.
- Hot-Swap Capable: Supports online replacement within the C300 chassis, minimizing maintenance downtime.
- Seamless Experion PKS Integration: Plug-and-play compatibility with Honeywell’s Experion Station, FDM, and Asset Manager.
- Redundancy Ready: Supports redundant I/O configurations for SIL-rated and high-availability loops.
Industry & Equipment Applications
- Oil & Gas: Upstream wellhead monitoring, midstream pipeline pressure/flow measurement, downstream refinery process control.
- Petrochemical & Chemical: Reactor temperature and pressure loops, distillation column instrumentation.
- Power Generation: Boiler drum level, turbine inlet temperature, feedwater flow monitoring.
- Pharmaceutical & Life Sciences: Validated batch process control with full audit trail via HART diagnostics.
- Pulp & Paper / Water Treatment: Multi-loop analog acquisition in large-scale continuous process plants.
System Integration & Compatible Parts
The CC-PAIH02 is designed to operate within the Honeywell Experion PKS C300 ecosystem. Compatible and commonly paired components include:
- C300 Controller: CC-PCF901 / CC-PCF902 — the host controller for this I/O module
- I/O Link Interface Module (IOLIM): CC-PCNT01 — connects I/O modules to the C300 controller
- Analog Output Module: CC-PAOH01 — paired for closed-loop control
- Power Supply Module: CC-PWR001 / CC-PWR002 — chassis power for C300 I/O
- Termination Assembly: CC-TAIX01 / CC-TAIX11 — field wiring termination for analog input modules
Contact Konmask.com for cross-reference assistance and full BOM support for your C300 system.
Our Quality Assurance Process
Every Honeywell CC-PAIH02 unit sourced through Konmask.com undergoes a structured verification process before shipment:
- Visual Inspection: Checking for physical damage, corrosion, and connector integrity.
- Label & Part Number Verification: Confirming the part number, revision, and serial number match the order specification.
- Functional Test (where applicable): Bench-level power-on and communication verification for refurbished units.
- Secure Packaging: ESD-safe anti-static bags, foam cushioning, and double-box packaging for international shipment.
- Documentation: Certificate of conformance and test report available upon request.
How to Order
- Submit an inquiry via the Contact Us form or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Receive a formal quotation within 1 business day.
- Confirm the purchase order — we accept T/T, L/C, and other standard B2B payment terms.
- Shipment arranged via DHL, FedEx, or sea freight with full tracking and export documentation.
Why Choose Konmask.com?
- Specialized Industrial Focus: We exclusively serve the industrial automation and process control market — no generalist catalog noise.
- Global Supply Network: Access to both new and certified-refurbished Honeywell DCS components with short lead times.
- Technical Pre-Sales Support: Our team includes engineers with hands-on DCS experience who can validate compatibility before you order.
- Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing on hard-to-find modules.
- Reliable Export Logistics: Experienced in customs documentation, export compliance, and international freight for industrial parts.
Frequently Asked Questions
Q: Is the CC-PAIH02 compatible with both HART 5 and HART 7 devices?
A: Yes. The CC-PAIH02 supports both HART 5 and HART 7 protocol revisions, making it compatible with a wide range of legacy and modern HART-enabled field instruments.
Q: Can this module be replaced online without shutting down the controller?
A: The C300 I/O architecture supports hot-swap replacement of I/O modules. However, always follow your site’s MOC (Management of Change) procedures and consult Honeywell’s installation guide before performing live replacements.
Q: Do you supply new or refurbished units?
A: Konmask.com supplies both new (factory-sealed) and certified-refurbished units depending on availability. The condition will be clearly stated in your quotation.
Q: What is the lead time for the CC-PAIH02?
A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. For out-of-stock items, lead time is 2–6 weeks. Contact us for real-time availability.
Q: Can you provide the original Honeywell datasheet?
A: Yes. We can provide the official Honeywell product datasheet and installation guide upon request. Contact support@konmask.com.
Q: Do you accept small quantity orders?
A: Yes. We accept orders from a single unit upward. There is no minimum order quantity for standard inquiries.
{
