Process Control Solution — Honeywell CC-TDIL51 51307083-175 | C300 Series Digital Input Module
Where This Product Is Used
The Honeywell CC-TDIL51 (P/N 51307083-175) is a 32-channel Digital Input Module designed for the Experion PKS C300 Distributed Control System (DCS). It is deployed across high-reliability process industries where deterministic digital signal acquisition is critical:
- Oil & Gas: Wellhead monitoring, pipeline SCADA, compressor station control
- Petrochemical & Refining: Reactor interlock sensing, valve position feedback, pump status monitoring
- Power Generation: Turbine control panels, boiler management systems, switchgear status acquisition
- Pulp & Paper / Chemical: Batch process sequencing, conveyor status, level switch inputs
- Pharmaceutical & Food & Beverage: CIP/SIP cycle monitoring, clean-room equipment status
- Water & Wastewater: Pump run/fail feedback, valve open/close confirmation, alarm inputs
Technical Specifications
| Part Number | CC-TDIL51 / 51307083-175 |
| Manufacturer | Honeywell Process Solutions |
| Series | Experion PKS C300 Series |
| Module Type | Digital Input (DI) |
| Channel Count | 32 Channels |
| Input Voltage | 24 VDC (nominal) |
| Signal Type | Discrete / Digital (dry contact or sourcing) |
| Communication | C300 FIM backplane bus |
| Isolation | Channel-to-bus optical isolation |
| Mounting | C300 I/O chassis / carrier |
| Weight | 1,220 g (approx.) |
| Compliance | CE, UL, CSA (refer to Honeywell datasheet) |
Why Engineers Specify This Model
- Native C300 Integration: Plug-and-play compatibility with Experion PKS C300 Field Interface Modules (FIMs) — no additional gateways or signal converters required.
- High Channel Density: 32 DI channels per module reduce cabinet footprint and wiring costs in large-scale DCS installations.
- Optical Isolation: Protects the controller backplane from field-side transients, ground loops, and surge events common in industrial environments.
- Hot-Swap Capable: Supports module replacement under power (with appropriate carrier), minimizing process downtime during maintenance.
- Proven Reliability: Honeywell’s C300 I/O platform is installed in thousands of facilities globally with a documented MTBF exceeding 10 years in typical process environments.
- Firmware Compatibility: Supported across multiple Experion PKS software revisions — confirm revision compatibility with your site’s FIM firmware before ordering.
Complete System Bill of Materials
The CC-TDIL51 operates within the Honeywell C300 I/O subsystem. A complete field I/O node typically includes:
- C300 Controller (CC-PCF901 or equivalent)
- Field Interface Module — FIM (CC-FIM001 or CC-FIM401)
- I/O Carrier / Chassis (CC-TCNT01 or series-compatible carrier)
- CC-TDIL51 Digital Input Module (this item)
- Terminal Block / Field Wiring Assembly (CC-TAIX01 or equivalent)
- Power Supply Module (24 VDC, appropriately rated)
- Redundancy Module (optional, for high-availability configurations)
Contact support@konmask.com for BOM assistance and compatible part sourcing.
Compliance & Industry Standards
- CE Marking — EMC Directive compliance
- UL Listed / CSA Certified (industrial control equipment)
- IEC 61131-2 — Programmable controllers: equipment requirements and tests
- ISA-5.1 — Instrumentation symbols and identification
- NAMUR NE 21 — EMC requirements for process control equipment
- RoHS compliant (verify specific revision with Honeywell documentation)
Quality Assurance & Sourcing
Konmask.com specializes in genuine, traceable industrial automation components for DCS, PLC, and process control applications. Every unit of the CC-TDIL51 we supply is:
- Sourced from authorized distributors or verified surplus channels with documented chain of custody
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped with anti-static packaging and appropriate cushioning for international freight
- Supported by our technical team for pre-sale compatibility verification
How to Source This Part
- Add to Cart — Proceed directly if your revision and quantity are confirmed.
- Request a Quote — Email support@konmask.com with your PO number, required quantity, and delivery timeline for volume pricing.
- Expedited Orders — Call or WhatsApp +0086 19859288691 for urgent requirements. We support same-day quotation for stocked items.
- Global Shipping — We ship to North America, Europe, Southeast Asia, the Middle East, and beyond via DHL, FedEx, and UPS with full tracking.
Application-Specific FAQ
Q: Is the CC-TDIL51 compatible with Experion PKS R500 and later?
A: The CC-TDIL51 is designed for the C300 I/O platform. Compatibility with specific Experion PKS software revisions depends on your FIM firmware version. Contact us with your system revision for confirmation.
Q: Can this module be used in a Safety Instrumented System (SIS)?
A: The CC-TDIL51 is a standard DCS I/O module and is not rated for SIL-certified SIS applications. For safety loops, Honeywell’s Safety Manager SC or FSC platform modules should be specified.
Q: What is the difference between CC-TDIL51 and CC-TDIL01?
A: The suffix revision (51 vs. 01) typically denotes hardware revision changes. Always cross-reference the full part number including the 8-digit suffix (51307083-175) with your system’s compatibility matrix or contact our technical team.
Q: Do you supply the matching terminal block / field wiring assembly?
A: Yes. We stock a range of compatible C300 I/O accessories. Provide your full BOM and we will quote the complete assembly.
Q: What is the lead time for the CC-TDIL51?
A: Lead time depends on current stock levels. Contact us for real-time availability. Stocked items typically ship within 1–3 business days.
