Honeywell CC-TDOR01 (51308376-175) Digital Output Relay Module | Replacement, Equivalent & Selection Guide
The Honeywell CC-TDOR01 (Part No. 51308376-175) is a Digital Output Relay Module designed for the Honeywell Experion PKS distributed control system, compatible with the C300 Controller platform. It provides reliable relay-contact digital outputs for industrial process control applications requiring isolated switching of field devices.
At Konmask.com, we supply genuine, tested, and refurbished CC-TDOR01 modules with full traceability — serving OEMs, system integrators, and plant maintenance teams worldwide.
Technical Specifications
- Part Number: CC-TDOR01 / 51308376-175
- Manufacturer: Honeywell Process Solutions
- Series: Experion PKS — C300 I/O Series
- Module Type: Digital Output — Relay Contact
- Output Channels: 8 relay output channels (SPDT or SPST, refer to datasheet)
- Output Voltage Range: Up to 250 VAC / 30 VDC
- Output Current Rating: 2 A per channel (resistive load)
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication Bus: C300 FIM (Field Interface Module) backplane
- Mounting: DIN rail / Experion PKS I/O chassis
- Operating Temperature: 0°C to 60°C
- Certifications: CE, UL (refer to product datasheet for full listing)
- Weight: Approx. 1,130 g
- Country of Origin: USA
Compatible Replacement & Equivalent Models
If the CC-TDOR01 is unavailable or end-of-life in your region, the following models may serve as functional equivalents or drop-in replacements (subject to system configuration verification):
| Model | Brand | Type | Compatibility Note |
|---|---|---|---|
| CC-TDOB01 / 51308376-150 | Honeywell | Digital Output — 24 VDC Solid State | Same C300 platform; solid-state vs. relay output |
| CC-TDOB11 / 51308376-175 | Honeywell | Digital Output — 120 VAC Solid State | Higher voltage solid-state alternative |
| CC-TDIL01 / 51308376-125 | Honeywell | Digital Input — 24 VDC | Input counterpart for system pairing reference |
| 51309288-175 | Honeywell | Relay Output Module (legacy) | Older generation; verify firmware compatibility |
Note: Always verify hardware revision, firmware version, and system configuration before substituting modules. Contact Konmask.com for pre-sales compatibility assessment.
Why Choose the Original CC-TDOR01
- Relay Contact Output: Provides true galvanic isolation — ideal for switching motors, solenoids, and high-inrush loads that solid-state outputs cannot handle reliably.
- Native Experion PKS Integration: Plug-and-play with C300 FIM; no additional configuration adapters required.
- Proven Field Reliability: Widely deployed in oil & gas, refining, power generation, and chemical processing plants globally.
- Long Service Life: Mechanical relay rated for millions of operations under rated load.
- OEM Traceability: Genuine Honeywell part with full documentation and firmware compatibility guarantee.
Typical Applications
- Motor starter and contactor control in process plants
- Solenoid valve switching in oil & gas and chemical facilities
- Alarm annunciator and shutdown relay outputs
- Pump and compressor start/stop control
- Burner management system (BMS) digital outputs
- Safety instrumented system (SIS) auxiliary relay outputs
System Compatibility
- DCS Platform: Honeywell Experion PKS (Process Knowledge System)
- Controller: C300 Process Controller
- Interface Module: FIM (Field Interface Module) — CIOM-A chassis
- Software: Experion R400 and above (verify with your site’s release)
- Redundancy: Supports redundant I/O configurations with appropriate FIM pairing
Selection Guide
Use the table below to select the correct Honeywell C300 Digital Output module for your application:
| Requirement | Recommended Model | Part Number |
|---|---|---|
| Relay contact output (isolated switching) | CC-TDOR01 | 51308376-175 |
| 24 VDC solid-state output | CC-TDOB01 | 51308376-150 |
| 120 VAC solid-state output | CC-TDOB11 | 51308376-175 (alt) |
| High-density relay output (16-ch) | Consult Konmask | — |
Not sure which module fits your system? Send us your I/O list or system drawing — our engineers will recommend the correct part.
Quality Assurance & Sourcing
- Condition Options: New (factory-sealed), Refurbished (tested to OEM spec), Used (functional, inspected)
- Testing: All modules undergo power-on functional testing and relay contact verification before shipment
- Warranty: 12-month warranty on all units supplied by Konmask.com
- Traceability: Full documentation available — serial number, test report, and certificate of conformance on request
- Anti-Counterfeit: Sourced from authorized channels and verified distributors only
How to Order
- Add CC-TDOR01 / 51308376-175 to your cart and proceed to checkout, or
- Email your purchase order or RFQ to support@konmask.com
- For bulk orders (>5 units) or urgent requirements, contact us via WhatsApp/phone for priority processing
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
Accepted Payment: T/T (Wire Transfer), PayPal, Credit Card (via Shopify Payments)
Shipping: DHL / FedEx / UPS Express worldwide | EXW Xiamen, China available
Replacement & Compatibility FAQ
Q: Can CC-TDOB01 replace CC-TDOR01 directly?
A: Functionally similar but not identical — CC-TDOB01 uses solid-state transistor output (24 VDC), while CC-TDOR01 uses relay contacts. Relay outputs are required for AC loads or applications needing galvanic isolation. Consult your system engineer before substituting.
Q: Is CC-TDOR01 compatible with Experion R500?
A: Yes, CC-TDOR01 is compatible with Experion PKS R400 through R500 and later releases. Verify your FIM firmware version for full compatibility.
Q: What is the difference between 51308376-175 and other 51308376-xxx part numbers?
A: The suffix (-175, -150, -125, etc.) denotes the specific module variant within the CC-T series. Each suffix corresponds to a different I/O type or voltage rating. Always order by the full part number.
Q: Do you supply the termination assembly (TBAR) for CC-TDOR01?
A: Yes. The compatible termination assembly is CC-TAIX01 or CC-TAOX01 depending on wiring configuration. Please specify when ordering.
Q: Can I get a datasheet or wiring diagram?
A: Yes — email support@konmask.com with your part number and we will provide the official Honeywell documentation.
