Industrial Control Solution – Honeywell DO-1224 | Digital Output Module
Where This Product Is Used
The Honeywell DO-1224 is a 24-channel digital output module engineered for deployment in distributed control systems (DCS) across the most demanding industrial environments. Engineers specify this module in:
- Oil & Gas Processing Plants – Controlling solenoid valves, motor starters, and shutdown actuators in upstream/downstream facilities
- Chemical & Petrochemical Plants – Driving discrete field devices in safety-critical process loops
- Power Generation Facilities – Managing turbine auxiliary systems, breaker control, and alarm annunciators
- Pulp & Paper Mills – Coordinating conveyor drives, pump starters, and valve actuators
- Water & Wastewater Treatment – Activating pumps, blowers, and dosing systems via DCS command
- Pharmaceutical Manufacturing – Controlling cleanroom HVAC dampers and process isolation valves under GMP conditions
Technical Specifications
- Part Number: DO-1224
- Manufacturer: Honeywell Process Solutions
- Module Type: Digital Output (Discrete Output)
- Number of Channels: 24
- Output Voltage: 24 VDC (nominal)
- Output Type: Solid-state / relay-compatible discrete outputs
- Communication: Compatible with Honeywell TDC / TPS / Experion DCS backplane
- Isolation: Channel-to-backplane optical isolation
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Weight: 440 g
- Form Factor: Standard Honeywell I/O card format
- Mounting: DCS I/O chassis / card cage
Why Engineers Specify This Model
The DO-1224 is a proven workhorse in Honeywell DCS architectures. Key reasons it remains the preferred choice for control engineers:
- High Channel Density: 24 discrete outputs per card minimizes chassis slots and reduces total system footprint
- Direct Backplane Integration: Plug-and-play compatibility with Honeywell TDC 3000, TPS, and Experion PKS platforms — no additional interface hardware required
- Optical Isolation: Protects the controller backplane from field-side voltage transients and ground loops
- Proven Field Reliability: Widely deployed in brownfield plants with 10–20+ year operational histories
- Hot-Swap Capable: Supports live replacement in redundant DCS configurations to minimize process downtime
- Diagnostic Support: On-card LED status indicators for rapid field troubleshooting without test equipment
Complete System Bill of Materials
For a complete Honeywell DCS digital output subsystem, engineers typically pair the DO-1224 with:
- Honeywell I/O Card Cage / Chassis (TDC or Experion series)
- Honeywell Field Termination Assembly (FTA) – matching DO-1224 pinout
- Honeywell Power Supply Module (24 VDC field power)
- Honeywell Controller Module (e.g., HPM, C200, C300)
- Marshalling Cabinet / Terminal Blocks for field wiring
- Surge Protection Devices (SPDs) for field cable protection
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- Designed and tested to Honeywell internal quality and EMC standards
- Compatible with IEC 61131-2 discrete I/O signal specifications
- Suitable for use in SIL-rated safety loops when integrated per Honeywell SIS guidelines
- CE marking applicable for EU installations
- RoHS-compliant manufacturing (verify with current Honeywell datasheet for specific revision)
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for DCS, PLC, and process control applications. Every Honeywell DO-1224 module we supply is:
- Sourced from verified industrial supply channels
- Inspected for physical integrity and label authenticity prior to dispatch
- Shipped with appropriate ESD-protective packaging
- Supported by our technical team for pre-sale compatibility verification
We serve MRO buyers, system integrators, and plant engineering teams globally.
How to Source This Part
To place an order or request a quote for the Honeywell DO-1224:
- Online: Add to cart directly on this page
- Email: support@konmask.com with your PO or RFQ
- Phone/WhatsApp: +0086 19859288691
- Lead Time: Contact us for current stock availability and lead time
- Shipping: Worldwide DHL / FedEx / UPS express available
Application-Specific FAQ
Q: Is the DO-1224 compatible with Experion PKS?
A: The DO-1224 is a legacy Honeywell I/O card designed for TDC 3000 / TPS platforms. Compatibility with Experion PKS depends on the I/O chassis and FTA configuration — contact us to confirm your system revision.
Q: Can this module be used in a Safety Instrumented System (SIS)?
A: The DO-1224 is a standard process I/O card. For SIL-rated SIS applications, Honeywell’s Safety Manager platform with certified I/O modules is recommended. Consult your functional safety engineer.
Q: What is the difference between DO-1224 and DO-1216?
A: The DO-1224 provides 24 output channels versus 16 on the DO-1216, offering higher density for applications with more discrete field devices per chassis slot.
Q: Do you supply the matching Field Termination Assembly (FTA)?
A: Yes. Contact us with your DO-1224 revision and we will identify the correct FTA part number for your installation.
Q: What warranty applies to this module?
A: We offer a standard 90-day functional warranty on all modules. Extended warranty options are available — inquire at time of order.
