Honeywell 2MLR-AC13-CC – AC Power Supply Module | 2MLR Safety Relay Platform
Engineering Background
The Honeywell 2MLR series is a modular safety relay platform engineered for machine safety and process control applications requiring IEC 61508 / EN 954-1 compliance. The 2MLR-AC13-CC is the dedicated AC-input power supply module that energizes the 2MLR backplane, converting line-voltage AC power into the regulated DC bus required by all logic, I/O, and communication modules in the rack.
Product Positioning
Designed for procurement engineers specifying safety-rated power infrastructure in automotive assembly, packaging machinery, material handling, and process industries. The 2MLR-AC13-CC eliminates the need for an external 24 VDC power supply, simplifying panel design and reducing BOM complexity while maintaining full CE / UL certification.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 2MLR-AC13-CC |
| Manufacturer | Honeywell Sensing & Safety Technologies |
| Series / Platform | 2MLR Modular Safety Relay System |
| Module Function | AC Power Supply Module |
| Input Voltage | 100–240 V AC (auto-ranging) |
| Input Frequency | 47–63 Hz |
| Output Voltage | 24 V DC (regulated, backplane bus) |
| Output Current | 1.3 A (continuous) |
| Output Power | ~31 W |
| Inrush Current | < 20 A peak (cold start) |
| Isolation | Reinforced, input-to-output |
| Mounting | DIN Rail (EN 60715 TS35) |
| Enclosure / Housing | Snap-fit modular housing, 2MLR rack-compatible |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5–95 % RH (non-condensing) |
| Protection Class | IP20 (IEC 60529) |
| Certifications | CE, UL Listed, cUL |
| Safety Standard | IEC 61508, EN 954-1 Cat. 4 (system level) |
| Weight | ~240 g |
| HS Code (Reference) | 8504.40 – Static converters |
Proven Application Environments
- Automotive Manufacturing – Robot cell safety interlocks, press guarding, and E-stop monitoring panels powered by 2MLR racks
- Packaging & Palletizing – High-cycle safety relay systems requiring stable 24 VDC bus without external PSU
- Material Handling & Conveyors – Zone control panels with multiple 2MLR I/O modules sharing a single AC-fed power rail
- Process & Chemical Plants – SIL-rated safety loops where reinforced isolation between AC mains and control bus is mandatory
- Machine Tool & CNC – Spindle and axis safety monitoring with 2MLR logic modules requiring clean, regulated DC supply
- Food & Beverage – Washdown-adjacent control panels (IP20 module inside sealed enclosure) with wide-range AC input for global deployment
Engineering Advantages
- Wide-Range AC Input (100–240 V) – Single SKU supports global voltage standards; no tap selection or transformer required
- Integrated Backplane Power – Eliminates external 24 VDC PSU and wiring, reducing panel footprint and potential failure points
- Reinforced Isolation – Meets IEC 60950 / IEC 62368 reinforced insulation requirements, protecting low-voltage control circuits from mains transients
- Hot-Swap Compatible Housing – Snap-fit DIN rail design allows module replacement without full rack disassembly (verify with system documentation)
- CE + UL Dual Certification – Accepted by both European and North American safety authorities; simplifies global machine compliance
- Compact Form Factor – Narrow-profile module maximizes rack density; compatible with full 2MLR module ecosystem
System Architecture & Signal Flow
The 2MLR-AC13-CC occupies the leftmost slot of the 2MLR base/rack assembly. AC line voltage (L/N/PE) is wired directly to the module’s screw terminals. Internally, the switching power supply converts AC to a regulated 24 V DC bus distributed across the backplane connector to all downstream 2MLR modules (logic relays, I/O expanders, fieldbus gateways). The module provides LED status indication for power-good and fault conditions. No external DC wiring between the PSU and other modules is required — all power distribution is handled via the backplane bus.
Typical rack order: [2MLR-AC13-CC] → [2MLR Logic Module(s)] → [2MLR I/O Expander(s)] → [2MLR Communication Module]
Sourcing & Quality Verification
- All units sourced through authorized Honeywell distribution channels or verified surplus with full traceability documentation
- Each module inspected for: label integrity, connector condition, housing cracks, and date code consistency
- Functional test available on request (24 VDC output verification under load)
- Certificate of Conformance (CoC) and original Honeywell packaging provided where available
- Counterfeit-prevention: serial number and date code cross-referenced against Honeywell production records upon request
Procurement Process
- Step 1 – Confirm Compatibility: Verify your 2MLR rack/base part number accepts the AC13 power supply variant (vs. DC input variants)
- Step 2 – Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation
- Step 3 – Place Order: Purchase directly via this listing or submit a PO to our sales team
- Step 4 – Shipping: Ships within 1–3 business days; DHL / FedEx international express available; export documentation provided for cross-border shipments
- Step 5 – After-Sales: 12-month warranty on verified new units; 90-day warranty on tested surplus units
Technical FAQ
Q: Can the 2MLR-AC13-CC power a full 2MLR rack with multiple modules?
A: Yes. The 1.3 A / 24 VDC output is sized to power the standard 2MLR base plus multiple logic and I/O modules. Consult the 2MLR system manual for maximum module count per power supply.
Q: Is this module compatible with 2MLR-DC input variants?
A: No. The AC13 variant accepts AC input only. For 24 VDC input applications, the corresponding DC power supply module (e.g., 2MLR-DC13-CC) is required.
Q: What is the “CC” suffix in the part number?
A: “CC” typically denotes the connector/configuration variant within the 2MLR family. Always order by full part number to ensure exact fit.
Q: Does this module require any configuration or firmware?
A: No. The 2MLR-AC13-CC is a passive power supply module with no programmable parameters. It is plug-and-play within the 2MLR rack.
Q: Can I use this module outside the 2MLR rack as a standalone 24 VDC power supply?
A: Not recommended. The output is designed to feed the 2MLR backplane bus. For standalone 24 VDC applications, use a standard DIN rail PSU.
