Honeywell FC-CPCHAS-0002 – Multi-Slot PLC Rack Chassis | Experion PKS Platform
Engineering Background: The FC-CPCHAS-0002 is a core structural and electrical backbone component within Honeywell’s Experion PKS (Process Knowledge System) distributed control architecture. Designed to house and interconnect C300 Controller modules and associated I/O interface cards, this chassis provides the high-integrity backplane bus required for deterministic process control in continuous and batch manufacturing environments.
Product Positioning: Procurement engineers sourcing replacement or expansion chassis for existing Experion PKS installations will find the FC-CPCHAS-0002 to be a direct, verified-compatible solution. Konmask.com maintains surplus and refurbished stock with full part-number traceability, supporting both emergency replacement and planned capital projects.
Complete Technical Specifications
- Part Number: FC-CPCHAS-0002
- Manufacturer: Honeywell Process Solutions
- Platform: Experion PKS (Process Knowledge System)
- Series: C300 Controller Series
- Component Type: PLC / DCS Rack Chassis (Backplane)
- Form Factor: DIN-rail / panel-mount rack chassis
- Slot Configuration: Multi-slot backplane for C300 and I/O modules
- Backplane Bus: Proprietary Experion high-speed serial bus
- Power Input: Supplied via Honeywell-compatible power supply module
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Weight: Approx. 5.8 kg (bare chassis)
- Compliance: CE, UL, cUL listed; IEC 61131-2 compatible platform
- Country of Origin: United States
- HS Code: 8537.10
Proven Application Environments
- Oil & Gas upstream/downstream process control panels
- Petrochemical and refinery DCS cabinet expansions
- Power generation plant automation upgrades
- Pharmaceutical batch process control systems (FDA 21 CFR Part 11 environments)
- Pulp & paper and chemical plant Experion PKS migrations
- Water treatment and utilities SCADA integration racks
Engineering Advantages
- Direct OEM Compatibility: Designed exclusively for Honeywell Experion PKS — no adaptation or firmware modification required.
- Backplane Integrity: Rigid chassis construction minimizes vibration-induced connector wear in industrial cabinet environments.
- Scalable Architecture: Supports incremental I/O expansion without controller replacement.
- Reduced Downtime Risk: Stocking a spare FC-CPCHAS-0002 eliminates lead-time exposure on critical chassis failures.
- Long Service Life: Passive backplane design with no active components — inherently high MTBF.
System Architecture & Signal Flow
Within the Experion PKS cabinet, the FC-CPCHAS-0002 chassis mounts vertically or horizontally in a standard 19″ or DIN enclosure. The C300 Controller module occupies the primary slot and communicates with adjacent I/O Link Interface modules (IOLI) via the backplane bus. Field signals enter through I/O termination assemblies (FTAs), traverse the backplane, and are processed by the C300 for real-time control output. Redundant power feeds can be applied via dual power supply slots where chassis configuration permits.
Sourcing & Quality Verification
- All units inspected for physical integrity: backplane connector pins, chassis rail alignment, and label legibility.
- Part number and date code verified against Honeywell documentation prior to listing.
- Units shipped in anti-static packaging with foam protection.
- Certificate of conformance (CoC) available upon request for regulated industries.
- Traceability documentation provided for MRO and capital project procurement records.
Procurement Process
- Submit RFQ via support@konmask.com or WhatsApp +0086 19859288691.
- Receive availability confirmation and lead time within 24 business hours.
- Review and approve proforma invoice.
- Payment via T/T bank transfer, PayPal, or approved credit terms.
- Shipment via DHL / FedEx / UPS with full tracking and export documentation.
Technical FAQ
- Q: Is FC-CPCHAS-0002 compatible with C200 controllers?
- A: No. This chassis is designed for the C300 controller series within Experion PKS R400 and later. C200 systems use a different chassis form factor.
- Q: Can I mix C300 and IOLI modules in the same chassis?
- A: Yes, subject to Honeywell’s slot assignment rules defined in the Experion PKS Hardware Planning Guide (document EP-DS-0001).
- Q: What power supply is required?
- A: Honeywell FC-PSU series power supply modules are required. Consult your system BOM for the correct PSU part number.
- Q: Do you provide warranty on surplus units?
- A: Konmask provides a 90-day functional warranty on all tested surplus units. Extended warranty options available on request.
- Q: Can you source other Experion PKS components?
- A: Yes. Contact us with your full BOM and we will provide consolidated availability and pricing across all line items.
