Honeywell FSC-PMP10.24A-SIC – 24VDC Switched Power Supply | FSC Fail Safe Controller Platform
Engineering Background: The Honeywell FSC (Fail Safe Controller) platform is a proven safety instrumented system (SIS) widely deployed in oil & gas, petrochemical, power generation, and process industries. The FSC-PMP10.24A-SIC is the dedicated switched power supply module engineered to deliver stable, regulated 24VDC power to the FSC controller chassis, I/O modules, and field devices under demanding industrial conditions.
Product Positioning: Designed for procurement engineers and system integrators requiring a certified, drop-in replacement or expansion power supply for existing Honeywell FSC safety systems. The PMP10.24A-SIC supports redundant power configurations, ensuring uninterrupted operation in safety-critical loops where power failure is not an option.
Complete Technical Specifications
- Part Number: FSC-PMP10.24A-SIC
- Manufacturer: Honeywell Process Solutions
- Platform / Series: FSC Fail Safe Controller
- Module Type: Switched Power Supply (PSU)
- Output Voltage: 24 VDC (regulated)
- Output Current: 10 A (nominal)
- Output Power: 240 W
- Input Voltage: 85–264 VAC / 100–370 VDC (wide-range universal input)
- Input Frequency: 47–63 Hz
- Efficiency: ≥ 88% at full load
- Isolation: Input-to-output galvanic isolation
- Safety Integrity Level: SIL 2 capable (IEC 61508)
- Redundancy: Supports 1+1 redundant PSU configuration
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5–95% RH, non-condensing
- Protection Class: IP20 (chassis-mounted)
- Dimensions (W × H × D): Refer to FSC chassis slot specification
- Weight: 1,650 g (approx.)
- Certifications: CE, UL, cUL, ATEX (zone 2 when installed per FSC guidelines)
- Compliance: IEC 61508, IEC 61511, NFPA 72
- Mounting: FSC backplane slot (DIN rail chassis)
- Connector Type: Backplane edge connector (keyed)
- Status Indicators: Power OK LED, Fault LED
- MTBF: > 200,000 hours at 40°C ambient
Proven Application Environments
- Oil & Gas: Emergency Shutdown (ESD) and Fire & Gas (F&G) systems
- Petrochemical & Refinery: Burner Management Systems (BMS) and process safety interlocks
- Power Generation: Turbine protection and boiler safety systems
- Offshore Platforms: Safety-critical control in hazardous area Zone 2
- Chemical Processing: Reactor safety and pressure relief interlock systems
- Water & Wastewater: Critical pump and valve safety control
- Pulp & Paper: High-availability process safety loops
Engineering Advantages
- Redundancy-Ready Architecture: Hot-swap capable in 1+1 redundant configurations — zero downtime during PSU replacement.
- Wide-Range Universal Input: Accepts 85–264 VAC globally, eliminating the need for external voltage transformers.
- SIL 2 Certified: Fully validated for use in IEC 61508 / IEC 61511 safety instrumented functions.
- Galvanic Isolation: Protects sensitive FSC logic from field-side transients and ground loops.
- Integrated Fault Diagnostics: Onboard Power OK and Fault LEDs with backplane fault signaling to FSC CPU for immediate alarm annunciation.
- Long MTBF: >200,000 hours design life reduces lifecycle maintenance costs.
- OEM-Equivalent Quality: Sourced from verified Honeywell-authorized channels — not grey market.
System Architecture & Signal Flow
The FSC-PMP10.24A-SIC installs directly into the FSC power supply slot on the FSC chassis backplane. AC mains input is converted via a high-efficiency switching topology to regulated 24 VDC. The output is distributed across the backplane to the FSC CPU module, I/O modules, and optionally to field device loops. In a redundant configuration, two PMP10.24A-SIC units share the load; upon failure of one unit, the second assumes full load without interruption. The FSC CPU continuously monitors PSU health via the backplane diagnostic bus and generates a system alarm if a PSU fault is detected, enabling predictive maintenance before a safety function is compromised.
