Thermocouple Temperature Measurement Solution — HONEYWELL FTA-T-20 | Field Termination Assembly Series
Where This Product Is Used
The HONEYWELL FTA-T-20 is a Field Termination Assembly (FTA) engineered for thermocouple (TC) analog input signal conditioning within Honeywell distributed control systems. It is deployed across mission-critical process industries where accurate, high-density temperature measurement is non-negotiable:
- Oil & Gas Processing: Furnace outlet temperature monitoring, crude distillation column profiling, and fired heater control loops.
- Petrochemical & Refining: Reactor temperature measurement, heat exchanger performance monitoring, and catalytic cracker control.
- Power Generation: Boiler flue gas temperature sensing, turbine exhaust monitoring, and steam header control.
- Pulp & Paper: Dryer section temperature profiling and digester process control.
- Pharmaceutical & Fine Chemical: Autoclave and sterilization cycle temperature validation in GMP-regulated environments.
- Water & Wastewater Treatment: Incinerator and thermal oxidizer temperature control.
The FTA-T-20 interfaces directly with Honeywell’s Low-Level Analog Input (LLAI) I/O modules within the TotalPlant Solution (TPS), PlantScape, and Experion PKS control architectures, providing reliable cold-junction compensation and signal isolation at the field cabinet level.
Technical Specifications
| Part Number | FTA-T-20 |
| Manufacturer | Honeywell Process Solutions |
| FTA Type | Thermocouple (TC) Analog Input |
| Compatible DCS Platform | TPS (TotalPlant Solution), PlantScape, Experion PKS |
| Compatible I/O Module | LLAI / TC Input Card (e.g., MC-TAIH02, MC-TAIH12) |
| Number of Channels | 20 channels (thermocouple inputs) |
| Thermocouple Types Supported | J, K, T, E, R, S, B (per IEC 60584 / ANSI MC96.1) |
| Cold Junction Compensation | Automatic, on-board |
| Signal Isolation | Channel-to-channel and channel-to-ground isolation |
| Mounting | DIN rail or panel mount (cabinet-side) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | Approx. 500 g |
| Certifications | CE, UL Listed (refer to Honeywell product datasheet for full listing) |
Note: Always cross-reference with the official Honeywell FTA-T-20 datasheet and your system’s I/O card compatibility matrix before installation.
Why Engineers Specify This Model
- 20-Channel Density: Consolidates up to 20 TC inputs on a single FTA, reducing cabinet footprint and wiring complexity versus discrete terminal blocks.
- Integrated Cold-Junction Compensation (CJC): On-board CJC eliminates the need for external compensation hardware, improving measurement accuracy and reducing BOM cost.
- Direct DCS Integration: Plug-and-play compatibility with Honeywell LLAI I/O cards ensures zero signal conditioning gaps and simplifies loop checkout.
- Robust Isolation: Channel-to-channel isolation prevents ground loops — a critical requirement in high-noise industrial environments such as motor control centers and substations.
- Long Product Lifecycle: Honeywell’s TPS/Experion platform has a multi-decade installed base; the FTA-T-20 remains a supported spare for brownfield maintenance and life-extension projects.
- Simplified Maintenance: Modular FTA design allows field replacement without disturbing the I/O card or DCS configuration, minimizing process downtime.
Complete System Bill of Materials
For a fully functional thermocouple input loop using the FTA-T-20, engineers typically specify the following complementary components:
- Honeywell LLAI / TC I/O Card (e.g., MC-TAIH02 or MC-TAIH12)
- Honeywell I/O Link Cable (FTA-to-card ribbon or shielded cable assembly)
- Honeywell Cabinet Power Supply (24 VDC, appropriately rated)
- Thermocouple field sensors (Type K / J / T per process requirement)
- Compensating extension cable (matching TC type, shielded)
- DIN rail and cabinet mounting hardware
- Surge/transient protection modules (recommended for long field cable runs)
Contact support@konmask.com for assistance sourcing any of the above complementary parts.
Compliance & Industry Standards
- IEC 60584: Thermocouple type definitions and tolerance classes
- IEC 61511 / ISA-84: Functional safety requirements for process industry SIS (where applicable)
- IEC 61000-4 Series: EMC immunity standards for industrial environments
- CE Marking: Conformity with EU Low Voltage and EMC Directives
- UL Listing: Per applicable UL standards (verify current listing status with Honeywell)
- RoHS: Compliance status per Honeywell product documentation
Quality Assurance & Sourcing
At Konmask.com, all automation components including the FTA-T-20 are subject to the following quality controls:
- Verified Supply Chain: Parts sourced from authorized distributors, OEM surplus channels, and vetted industrial resellers — not grey-market or counterfeit sources.
- Pre-Shipment Inspection: Visual inspection for physical damage, label authenticity, and firmware/revision marking verification.
- Traceability Documentation: Certificate of conformance (CoC) and sourcing records available upon request for critical applications.
- Packaging Integrity: ESD-safe packaging with desiccant for moisture-sensitive components; original OEM packaging preserved where available.
- Warranty: 90-day functional warranty against defects in materials and workmanship. Extended warranty options available — contact us for details.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly.
- Request a Quote — For bulk orders (>5 units), OEM project requirements, or urgent delivery, email support@konmask.com with your project details and required delivery date.
- Verify Compatibility — Share your DCS I/O card part number and revision; our technical team will confirm FTA-T-20 compatibility before shipment.
- Expedited Shipping — DHL Express, FedEx International Priority, and sea freight options available. Lead time: typically 3–7 business days for in-stock units.
- Export Documentation — Commercial invoice, packing list, and HS code documentation provided for all international shipments.
Application-Specific FAQ
Q: Is the FTA-T-20 compatible with Experion PKS R500 and later?
A: The FTA-T-20 is designed for the TPS/PlantScape/Experion PKS LLAI I/O architecture. Compatibility with specific Experion PKS software releases depends on the paired I/O card revision. Contact us with your system revision details for confirmation.
Q: Can the FTA-T-20 be used with RTD (resistance temperature detector) inputs?
A: No. The FTA-T-20 is specifically designed for thermocouple inputs. For RTD inputs, the correct FTA is the Honeywell FTA-R series (e.g., FTA-R-20). We stock both — contact us if you need the RTD variant.
Q: What is the difference between FTA-T-20 and FTA-T-10?
A: The FTA-T-20 supports 20 thermocouple input channels, while the FTA-T-10 supports 10 channels. Selection depends on your I/O card channel count and cabinet layout requirements.
Q: Do you provide installation and commissioning support?
A: Konmask.com specializes in parts supply. For on-site commissioning, we can refer you to qualified Honeywell system integrators in your region.
Q: Is this a new or refurbished unit?
A: Stock condition (new, factory-refurbished, or tested surplus) is specified at the time of quotation. All units pass pre-shipment functional inspection regardless of condition grade.
Q: Can I return the part if it is incompatible with my system?
A: Yes, within 14 days of receipt, provided the unit is unused and in original packaging. Please contact support@konmask.com before returning any item.
