Discrete Input Monitoring Solution – Honeywell MC-TD1D12 | TDC 3000 Series
Where This Product Is Used
The Honeywell MC-TD1D12 Digital Input Module is purpose-built for process industries that demand deterministic, high-integrity discrete signal acquisition within a distributed control system (DCS) architecture. Typical deployment environments include:
- Oil & Gas Refineries – Monitoring valve open/close status, pump run/stop feedback, and ESD trip signals across process units.
- Chemical & Petrochemical Plants – Acquiring discrete inputs from field instruments, limit switches, and interlock circuits in hazardous-area control loops.
- Power Generation Facilities – Capturing breaker status, relay feedback, and turbine protection signals in boiler and turbine control systems.
- Pulp & Paper Mills – Integrating conveyor status, motor run feedback, and safety interlock signals into centralized DCS supervisory control.
- Water & Wastewater Treatment – Reading pump status, level switch contacts, and valve position feedback for SCADA-integrated DCS loops.
- Pharmaceutical Manufacturing – Monitoring clean-room equipment status and batch process interlocks under cGMP-compliant control architectures.
Wherever a Honeywell TDC 3000 or compatible DCS backbone is installed, the MC-TD1D12 provides the reliable discrete input channel density engineers depend on for safe, continuous operation.
Technical Specifications
- Part Number: MC-TD1D12
- Manufacturer: Honeywell Process Solutions
- Series: TDC 3000 / Modular Controller (MC) Series
- Module Type: Digital (Discrete) Input Module
- Number of Input Channels: 12 channels
- Input Signal Type: Discrete / Digital (dry contact or 24 VDC wet contact)
- Input Voltage Range: 24 VDC nominal
- Isolation: Optical isolation between field inputs and backplane bus
- Communication Bus: TDC 3000 Local Control Network (LCN) / Universal Control Network (UCN)
- Mounting: Card cage / rack-mount (TDC 3000 compatible chassis)
- Form Factor: Single-slot module card
- Weight: 900 g (approx.)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Relative Humidity: 5% to 95% non-condensing
- Certifications: CE, UL Listed
Why Engineers Specify This Model
- Proven TDC 3000 Compatibility – Drop-in replacement for existing Honeywell TDC 3000 installations; no firmware or configuration changes required on the controller side.
- 12-Channel Density – Higher channel count per slot reduces chassis footprint and lowers per-point wiring cost compared to lower-density alternatives.
- Optical Isolation – Field-side optical isolation protects the DCS backplane from ground loops, transient surges, and field-side faults common in industrial environments.
- Deterministic Scan Cycle – Synchronized with the TDC 3000 scan cycle for predictable, low-latency discrete input updates critical to safety interlock logic.
- Long Service Life – Honeywell’s modular card design supports hot-swap maintenance procedures, minimizing process downtime during module replacement.
- Broad Industry Acceptance – Specified by process engineers across oil & gas, power, and chemical sectors as the standard discrete input card for TDC 3000 legacy system maintenance and life extension projects.
Complete System Bill of Materials
For a fully operational TDC 3000 discrete input subsystem, engineers typically specify the following alongside the MC-TD1D12:
- Honeywell TDC 3000 Card Cage / Chassis (compatible rack)
- Honeywell MC-TAIX12 or equivalent Analog Input Module (for mixed I/O loops)
- Honeywell MC-TD1D08 Digital Output Module (for paired output control)
- Honeywell TDC 3000 Power Supply Module (24 VDC backplane power)
- Honeywell LCN/UCN Network Interface Card (for DCS communication)
- Field terminal blocks and shielded twisted-pair field wiring
- Surge protection devices (SPDs) for field cable entries
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive for industrial control equipment.
- UL Listed – Recognized under UL standards for industrial control equipment.
- IEC 61131-2 – Compatible with programmable controller hardware interface standards for discrete input modules.
- ISA-5.1 – Field wiring and signal identification consistent with ISA instrumentation symbology standards.
- RoHS Compliant – Manufactured in accordance with EU Restriction of Hazardous Substances directives.
Quality Assurance & Sourcing
Konmask.com sources the Honeywell MC-TD1D12 through established industrial automation supply channels. Each unit offered undergoes the following quality checks before dispatch:
- Visual inspection for physical damage, bent pins, and label integrity.
- Verification of part number markings against Honeywell OEM labeling standards.
- Functional power-on test where applicable for refurbished or pull-out units.
- Anti-static packaging with humidity indicator cards for safe international transit.
Units are clearly described as new surplus, refurbished, or used/tested in the listing. Contact us to confirm current stock condition before ordering.
How to Source This Part
To place an order or request a quotation for the Honeywell MC-TD1D12:
- Online: Add to cart directly on this page for immediate checkout.
- Email RFQ: Send your purchase order or RFQ to support@konmask.com with quantity, required delivery date, and destination country.
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days. Ex-stock international shipments via DHL Express, FedEx, or UPS.
- Minimum Order Quantity: 1 unit. Volume pricing available for orders of 5+ units.
Application-Specific FAQ
Q: Is the MC-TD1D12 compatible with Honeywell Experion PKS systems?
A: The MC-TD1D12 is designed for the TDC 3000 platform. Experion PKS uses a different I/O architecture (Series C / CIOM). Confirm your chassis and controller type before ordering.
Q: Can this module accept 120 VAC discrete inputs?
A: No. The MC-TD1D12 is rated for 24 VDC discrete inputs. For 120 VAC field signals, an interposing relay or signal conditioner is required before the module input terminals.
Q: What is the scan rate for discrete inputs on this module?
A: Scan rate is governed by the TDC 3000 controller scan cycle configuration, typically 100 ms to 500 ms depending on the controller load and network configuration.
Q: Do you provide a warranty on this module?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested/refurbished units and a 30-day DOA warranty on new surplus units. See our warranty policy for full terms.
Q: Can you supply multiple units for a plant-wide spares program?
A: Yes. Contact us with your total quantity requirement and we will provide a consolidated quotation with volume pricing and consolidated shipping options.
