Honeywell TC-FXX172 Slot Rack | Replacement, Equivalent & Selection Guide
The Honeywell TC-FXX172 is a 7-slot modular rack chassis designed for the TotalPlant Solution (TPS) Distributed Control System. It provides the physical and electrical backplane for mounting I/O, controller, and communication modules in process automation environments. Konmask.com supplies new, surplus, and tested TC-FXX172 units with full traceability and fast global shipping.
Technical Specifications
- Part Number: TC-FXX172
- Manufacturer: Honeywell Process Solutions
- Series: TotalPlant Solution (TPS) / TDC 3000
- Type: 7-Slot Modular Rack / Chassis
- Backplane: Integrated passive backplane with keyed module slots
- Mounting: 19-inch rack panel mount
- Weight: ~900 g (bare chassis)
- Operating Temperature: 0 °C to 60 °C
- Compatibility: TPS I/O modules, HPM controllers, NIM communication modules
- Condition Available: New surplus / Tested & refurbished
Compatible Replacement & Equivalent Models
If the TC-FXX172 is unavailable or end-of-life in your region, the following models may serve as functional equivalents depending on your system configuration. Always verify slot count, backplane pinout, and power requirements before substitution.
| Model | Slots | Series | Notes |
|---|---|---|---|
| TC-FXX172 (this unit) | 7 | TPS | Original OEM part |
| TC-FXX132 | 3 | TPS | Smaller chassis; same backplane standard |
| TC-FXX152 | 5 | TPS | Mid-size alternative |
| 51304485-100 | 7 | TDC 3000 / TPS | Earlier revision; confirm firmware compatibility |
| 51304485-150 | 7 | TPS | Revised BOM; functionally equivalent |
Contact Konmask for cross-reference verification before ordering a substitute.
Why Choose the Original TC-FXX172
- OEM Guaranteed Fit: Exact backplane pinout — no adapter or re-wiring required.
- Firmware Compatibility: Validated with all TPS HPM and NIM module firmware revisions.
- Reduced Commissioning Risk: Drop-in replacement minimises plant downtime during maintenance windows.
- Long Service Life: Passive backplane design with no active components — proven 15+ year field reliability.
- Traceability: Each unit shipped with inspection report and serial number documentation.
Typical Applications
- Refinery and petrochemical DCS cabinet upgrades
- Power generation plant control system maintenance
- Pharmaceutical batch process automation (TPS-based)
- Pulp & paper mill distributed I/O expansion
- Spare parts inventory for TPS / TDC 3000 installed base
System Compatibility
- Honeywell TotalPlant Solution (TPS) — primary platform
- Honeywell TDC 3000 — with appropriate module revision
- HPM (High-Performance Process Manager) controller modules
- NIM (Network Interface Module) communication cards
- FTA (Field Termination Assembly) wiring panels via standard cable sets
Selection Guide
Use the table below to select the correct rack size for your expansion or replacement project:
| Required Slots | Recommended Model | Notes |
|---|---|---|
| 1–3 | TC-FXX132 | Compact; lower cost |
| 4–5 | TC-FXX152 | Mid-density I/O |
| 6–7 | TC-FXX172 | Standard full-size rack |
| 8+ | Multiple TC-FXX172 units | Cascade via UCN/LCN |
Key selection criteria: slot count needed, available cabinet rail space (19-inch), power supply capacity (TC-PSXX series), and existing module inventory.
Quality Assurance & Sourcing
- All units inspected for physical integrity, backplane continuity, and slot keying.
- Sourced from decommissioned plant upgrades, authorised distributors, and OEM surplus channels.
- Anti-static packaging with humidity indicator card for international shipment.
- Certificate of conformance available on request.
- 12-month warranty on tested & refurbished units; 90-day warranty on surplus-as-is.
How to Order
- Confirm your required quantity and preferred condition (new surplus / tested refurbished).
- Add to cart or contact support@konmask.com for bulk pricing.
- Provide your shipping address for freight quote (DHL / FedEx / sea freight available).
- Payment via T/T bank transfer, PayPal, or credit card.
- Lead time: in-stock units ship within 2 business days; sourced units 5–15 business days.
Replacement & Compatibility FAQ
Q: Can TC-FXX172 replace TC-FXX152 directly?
A: Only if your application uses 5 or fewer modules. The TC-FXX172 has 7 slots vs. 5 on the TC-FXX152 — it is a physical superset, but verify cabinet space.
Q: Is TC-FXX172 compatible with Experion PKS?
A: No. Experion PKS uses a different chassis family (e.g., CC-PCNT01). TC-FXX172 is specific to TPS/TDC 3000 architecture.
Q: What power supply is required?
A: The TC-PSXX series power supplies are designed for this rack. Confirm voltage (24 VDC or 120/240 VAC) with your site specification.
Q: Do you provide installation support?
A: Konmask provides technical documentation and pre-sales consultation. On-site installation is the responsibility of the end user’s qualified engineering team.
Q: Can I return a unit if it does not fit?
A: Yes — unused units in original packaging may be returned within 30 days. Contact support@konmask.com to initiate an RMA.
