Honeywell 900RTC-3410 HC900 Remote Terminal Cable – High-Voltage RTP Wiring Solution | HC900 Hybrid Control Platform
Engineering Background
The Honeywell HC900 Hybrid Control Platform is a proven distributed process control architecture widely deployed in refining, chemical processing, power generation, and advanced manufacturing. Reliable field wiring is the backbone of any HC900 installation — signal integrity between Remote Terminal Panels (RTPs) and I/O modules directly determines loop stability, alarm accuracy, and system uptime.
Product Positioning
The Honeywell 900RTC-3410 is the OEM-specified high-voltage Remote Terminal Panel (RTP) cable engineered exclusively for HC900 system architectures. It provides a secure, shielded, plug-and-play interconnect between HC900 I/O modules and their corresponding RTPs, eliminating field-wiring errors and ensuring full EMC compliance in high-noise industrial environments. Procurement engineers specify this cable as a mandatory BOM line item for any HC900 RTP-based I/O expansion.
Complete Technical Specifications
- Part Number / SKU: 900RTC-3410
- Manufacturer: Honeywell Process Solutions
- Product Series: HC900 Hybrid Control Platform
- Cable Type: High-Voltage Remote Terminal Panel (RTP) Cable
- Compatible Modules: HC900 I/O modules with RTP interface (900 Series)
- Connector Type: Pre-terminated, keyed RTP connectors (both ends)
- Shielding: Overall foil shield with drain wire for EMI/RFI rejection
- Voltage Rating: High-voltage rated per HC900 RTP specification
- Weight: 1,850 g (approx.)
- Country of Origin: United States
- Compliance: CE, UL, RoHS (per Honeywell HC900 platform certification)
- Replacement / Cross-Reference: OEM Honeywell; no approved third-party substitute
Proven Application Environments
- Petroleum refining and upstream oil & gas process control
- Chemical and petrochemical batch/continuous process loops
- Power generation plant distributed control systems
- Pharmaceutical manufacturing with validated control architectures
- Pulp & paper and water/wastewater treatment automation
- Any HC900 installation requiring RTP-based I/O field termination
Engineering Advantages
- Zero field-wiring errors: Pre-terminated, keyed connectors prevent mis-wiring during commissioning and maintenance.
- EMC-hardened: Foil shield + drain wire suppresses induced noise in high-voltage cabinet environments.
- Plug-and-play integration: Designed to Honeywell HC900 mechanical and electrical tolerances — no adaptation required.
- Reduced commissioning time: Eliminates point-to-point field termination labor; direct module-to-RTP connection.
- Long service life: Industrial-grade jacket and connector materials rated for continuous duty in panel environments.
- OEM traceability: Genuine Honeywell part with full manufacturer documentation and warranty support.
System Architecture & Signal Flow
In the HC900 architecture, I/O modules reside in the controller rack while field instruments terminate at Remote Terminal Panels (RTPs) located near the process. The 900RTC-3410 cable bridges these two points, carrying analog and discrete I/O signals from the RTP back to the corresponding HC900 I/O module. The high-voltage rating accommodates the elevated common-mode voltages present in industrial field wiring environments, while the shielded construction maintains signal integrity across the full cable run.
Signal flow: Field Instrument → RTP Terminal Block → 900RTC-3410 Cable → HC900 I/O Module → HC900 Controller
Sourcing & Quality Verification
- All units sourced from authorized Honeywell distribution channels or verified surplus with full traceability documentation.
- Pre-shipment inspection: visual, connector integrity, and continuity verification.
- Original manufacturer labeling and part markings preserved and authenticated.
- Certificate of Conformance (CoC) available upon request.
- Anti-counterfeit verification: Honeywell holographic labels and date codes inspected.
Procurement Process
- Step 1: Confirm quantity and delivery timeline with our sales team.
- Step 2: Request a formal quotation — email support@konmask.com or call +0086 19859288691.
- Step 3: Review CoC and inspection report (provided with every order).
- Step 4: Place order via secure checkout or purchase order (PO accepted for qualified accounts).
- Step 5: Worldwide express shipping — DHL / FedEx / UPS with full tracking.
Lead time: In-stock items ship within 1–3 business days. Contact us for urgent or large-volume requirements.
Technical FAQ
Q: Is the 900RTC-3410 compatible with all HC900 I/O module types?
A: It is designed for HC900 I/O modules that use the RTP interface. Please verify your specific module part number against the HC900 I/O Module and Termination Panel Specification Sheet (document 51-52-25-107) before ordering.
Q: Can this cable be used with non-Honeywell RTPs?
A: No. The 900RTC-3410 uses Honeywell-proprietary keyed connectors and is not compatible with third-party termination panels.
Q: What is the maximum cable run length?
A: Maximum run length is defined by the HC900 system specification. Refer to Honeywell document 51-52-25-107 for distance limits based on I/O type and signal level.
Q: Do you provide documentation with the shipment?
A: Yes — every shipment includes a packing list, Certificate of Conformance, and inspection report. Honeywell datasheet available on request.
Q: Can I order in bulk or on a blanket PO?
A: Yes. Contact our B2B sales team for volume pricing, blanket purchase orders, and scheduled delivery arrangements.
