HYUNDAI DOM16 – 16-Point Transistor Digital Output Module | HD1000 Series PLC
Engineering Background
The HYUNDAI DOM16 is a high-density transistor digital output module engineered for the HD1000 Series Programmable Logic Controller platform. Designed to meet the demanding requirements of industrial automation environments, it delivers reliable, high-speed discrete output control for machinery, process lines, and motion systems.
Product Positioning
Targeted at OEM machine builders, system integrators, and MRO procurement engineers who require a proven, drop-in compatible output expansion card for existing HD1000 PLC installations. The DOM16 eliminates relay-based output bottlenecks and supports high-frequency switching applications where relay life and response time are critical constraints.
Complete Technical Specifications
- Model: DOM16
- Manufacturer: HYUNDAI
- Series / Platform: HD1000 PLC
- Output Type: Transistor (NPN/Sink)
- Number of Output Points: 16
- Rated Output Voltage: 24 VDC
- Max Load Current per Point: 0.5 A
- Max Total Load Current: 4 A (all points ON)
- Output Isolation: Photocoupler
- Response Time (OFF→ON): ≤ 1 ms
- Response Time (ON→OFF): ≤ 1 ms
- Protection: Short-circuit protection, overload protection
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: -20 °C to +70 °C
- Humidity: 5% to 95% RH (non-condensing)
- Enclosure Rating: IP20
- Mounting: DIN rail / backplane slot
- Weight: approx. 500 g
- Certifications: CE
Proven Application Environments
- Conveyor and material handling systems
- Injection molding machine control
- Packaging and labeling lines
- CNC auxiliary I/O expansion
- HVAC and building automation panels
- Water treatment and pump station control
- Automotive assembly line actuator control
Engineering Advantages
- High-speed switching: Sub-millisecond response eliminates timing lag in high-frequency output cycles.
- Photocoupler isolation: Protects the PLC backplane from field-side voltage transients and ground loops.
- 16-point density: Maximizes I/O per slot, reducing panel footprint and wiring complexity.
- Short-circuit protection: Built-in hardware protection prevents module damage from field wiring faults.
- Direct HD1000 compatibility: No adapter or firmware update required — plug-and-play slot insertion.
System Architecture & Signal Flow
The DOM16 interfaces directly with the HD1000 PLC backplane via the proprietary I/O bus. The CPU writes output data to the module’s internal register on each scan cycle. The photocoupler stage isolates the logic-side signal before driving the transistor output stage. Each output channel drives an external load (solenoid, relay coil, indicator lamp, etc.) connected between the output terminal and the 24 VDC common. The module’s onboard protection circuit monitors each channel for overcurrent conditions and latches off the affected point to prevent thermal damage.
Sourcing & Quality Verification
- All units sourced through authorized HYUNDAI industrial distribution channels.
- Each module undergoes incoming inspection: visual check, label verification, and functional I/O test prior to dispatch.
- Original manufacturer packaging and documentation preserved.
- Traceability records maintained for B2B procurement compliance.
- Counterfeit-risk mitigation: hologram labels, date codes, and PCB markings verified against OEM references.
Procurement Process
- Confirm compatibility with your HD1000 PLC chassis slot count and firmware version.
- Submit RFQ or place order directly via Konmask.com product page.
- Receive order confirmation and lead-time estimate within 1 business day.
- Shipment with tracking number provided; export documentation available on request.
- Post-delivery technical support available via email or phone.
Technical FAQ
Q: Is the DOM16 compatible with HD1000S and HD1000H chassis variants?
A: Yes. The DOM16 is compatible with all HD1000 Series backplane variants. Verify slot type (standard I/O slot) before installation.
Q: Can the DOM16 drive inductive loads such as solenoid valves directly?
A: Yes, with a flyback diode installed across the inductive load to suppress voltage spikes. This is standard practice and does not affect module warranty.
Q: What is the maximum switching frequency?
A: The transistor output supports switching frequencies up to 1 kHz under rated load conditions.
Q: Is a replacement available if the module is discontinued?
A: Konmask.com maintains buffer stock of legacy HYUNDAI I/O modules. Contact us for long-term supply agreements.
Q: Do you provide a test report or incoming inspection certificate?
A: Yes. Inspection reports are available upon request for orders of 3 units or more.
